CHARGE THE 3.7V 130MAH LIPO BATTERY
Do not use the charge feature while flying the Super Cub!

INSTALL THE WING STRUTS

Peel the paper backing from the
adhesive tabs at the ends of the
wing struts.
Leave the TTX402
unpowered.
Insert battery to charge.
Make sure the battery
plug is oriented properly
before inserting.
Illuminated green light
indicates charging and will
go out when charging is
complete (approximately
20-30 minutes).
Press the tabs onto the indents on
the underside of the wing, making
sure that the struts align with the
indents on the fuselage.
5
Push in and slide
to open the charge
port cover.
Press the other ends of the struts
onto the indents on the fuselage,
being careful not to affect the
angle of the wing.
