Flyzone SKYFLY Manual

Flyzone SKYFLY Manual

Model aircraft flyzone skyfly
Hide thumbs Also See for SKYFLY:

Advertisement

Requires 8 "AA" Batteries
(not included)
Please read through this instruction booklet to THOROUGHLY familiarize yourself with the assembly and flight
characteristics of this airplane before beginning to assemble this model. Please inspect all parts carefully before
starting assembly! If any parts are missing, broken or defective, or if you have any questions about the assembly
or flying of this airplane, please call us at (217) 398-8970 and we'll be glad to help.
Hobbico
, Inc. guarantees this kit to be free from defects in both material and workmanship at the date of
®
purchase. This warranty does not cover any component parts damaged by use or modification. In no case shall
Hobbico's liability exceed the original cost of the purchased model. Further, Hobbico reserves the right to change
or modify this warranty without notice. In that Hobbico has no control over the final assembly, no liability shall
be assumed nor accepted for any damage resulting from the use by the user of the final user-assembled product.
By the act of using the user-assembled product, the user accepts all resulting liability. If the buyers are not
prepared to accept the liability associated with the use of this product, they are advised to return this kit
immediately in new and unused condition to the place of purchase.
To make a warranty claim send the defective part or item to Hobby Services at the address below:
Hobby Services
3002 N. Apollo Dr. Suite 1
Champaign IL 61822
USA
READ THROUGH THIS MANUAL BEFORE STARTING
CONSTRUCTION. IT CONTAINS IMPORTANT
INSTRUCTIONS AND WARNINGS CONCERNING
THE ASSEMBLY AND USE OF THIS MODEL.
Entire Contents © Copyright 2006
ASSEMBLE ONLY WITH ADULT SUPERVISION
Include a letter stating your name, return shipping address, as much contact
information as possible (daytime telephone number, fax number, e-mail address),
a detailed description of the problem and a photocopy of the purchase receipt.
Upon receipt of the package the problem will be evaluated as quickly as possible.
WARRANTY
Printed in China
Champaign, Illinois
HCAZ3001 for HCAA1961 V1.2

Advertisement

Table of Contents
loading

Summary of Contents for Flyzone SKYFLY

  • Page 1 ™ ™ Requires 8 “AA” Batteries (not included) ASSEMBLE ONLY WITH ADULT SUPERVISION Please read through this instruction booklet to THOROUGHLY familiarize yourself with the assembly and flight characteristics of this airplane before beginning to assemble this model. Please inspect all parts carefully before starting assembly! If any parts are missing, broken or defective, or if you have any questions about the assembly or flying of this airplane, please call us at (217) 398-8970 and we’ll be glad to help.
  • Page 2: Important Safety Precautions

    We hope you Your SkyFly should not be considered a toy, but rather a enjoy flying your SkyFly airplane. sophisticated, working model that functions very much like a full-size airplane.
  • Page 3: Unpacking The Box

    AIRFRAME PARTS AND HARDWARE UNPACKING THE BOX Check the parts against the list below. If any parts are damaged or missing, give us a call at: (217) 398-8970. Part Name Qty. ❏ 1. Transmitter Antenna....1 ITEMS NOT SHOWN ❏ 2. Transmitter......1 ❏...
  • Page 4: Assemble The Tail

    ASSEMBLE THE TAIL Replace the metal tail skid wire; note the direction of the wire. Attach two nylon retaining nuts to the bolts on the fin. Tighten these nuts down to hold the tail assembly together. Do not over tighten as the elevator and rudder could become damaged.
  • Page 5: Install The Landing Gear

    Typical charge time for a depleted pack is approximately 1 hour. The actual time the Follow the same procedure to install the nose gear charger takes to fully charge the SkyFly battery pack may vary. as shown.
  • Page 6: Connect The Battery

    IMPORTANT! CONNECT THE BATTERY NEVER LEAVE A CHARGING BATTERY UNATTENDED Remove the canopy by turning the locking knob 90° either direction and lifting the rear of the canopy. Although the 12V DC Peak Charger automatically detects when the battery is full and terminates peak charge, the battery pack must not be left unattended during charging.
  • Page 7: Attach The Wing

    “balance”. If your fingertips are between the lines, the SkyFly is ready to fly. Slide the front of the wing under the canopy and position the wing flat and centered on the fuselage. Secure the wing with two rubber bands, straight from the front to rear pegs.
  • Page 8: Prepare The Transmitter

    Expert/Beginner switch. When this switch is in the "Beginner" position, the transmitter will automatically Note: The SkyFly transmitter is equipped with a charge combine or "mix" a small amount of up elevator when jack that allows NiCd or NiMH batteries to be charged rudder input is provided to help maintain altitude when without removing them from the transmitter.
  • Page 9 The SkyFly should be flown only when the wind speed is 5 mph or less. If the wind is calm or very light, the SkyFly will be docile and easy to control. Also, find an area clear of trees, power lines and other structures. A flying field for R/C planes is best.
  • Page 10 SkyFly reacts. This will give you an idea of how the Moving the stick to the right will make the airplane turn to airplane will react during a landing.
  • Page 11: After The Flight

    HCAL7554..CRYSTAL SET 27.195 HCAL7555..CRYSTAL SET 27.255 REPLACEMENT PARTS HCAL7575..TRANSMITTER To order replacement parts for your SkyFly, use the order HCAA3861 ..MAIN LANDING GEAR numbers in the parts list. Replacement parts are available HCAA3862 ..FRONT LANDING GEAR only as listed. Replacement parts are not available from HCAA3863 ..SCREW LANDING GEAR (2)
