650W Electric
Line Trimmer
WEELT650
1938173001
Operator's Manual
Please read & understand this manual, paying particular attention to the safety instructions, before use.
The manufacturer reserves the right to change the product specifi cation and livery according to continues product improvements.
WEELT650 Instruction Manual.indd 1
17/11/2017 10:11
Advertisement
Table of Contents
Related Manuals for Webb WEELT650
Summary of Contents for Webb WEELT650
-
Page 1: Line Trimmer
Operator’s Manual Please read & understand this manual, paying particular attention to the safety instructions, before use. The manufacturer reserves the right to change the product specifi cation and livery according to continues product improvements. WEELT650 Instruction Manual.indd 1 17/11/2017 10:11... - Page 2 WEELT650 Instruction Manual.indd 2 17/11/2017 10:11...
-
Page 3: Table Of Contents
Weight N.W 2.95kg Consistent with our policy of continuous improvement, WEBB reserves the right to change the design and configuration of any of its products without notice or obligation. Therefore, please treat the text and images in this manual for illustrative purposes only. They may in no case serve as a basis for any legal claim. -
Page 4: Important Information
Never operate while people, especially children, or pets are nearby. Keep in mind that the operator or user is responsible for accidents or hazards involving the machine that occur to other people or their property. WEELT650 Instruction Manual.indd 4 17/11/2017 10:11... -
Page 5: General Safety Instructions
CE marking is a certification mark that indicates conformity with health, safety, and environmental protection standards for products sold within the European Economic Area. WEELT650 Instruction Manual.indd 5 17/11/2017 10:11... - Page 6 The device may only be connected to a Always wear appropriate footwear, such as socket that is correctly installed and work boots, and trousers when operating grounded. the mower. Do not operate the equipment WEELT650 Instruction Manual.indd 6 17/11/2017 10:11...
- Page 7 Before starting work, check the area for other debris build-up. Allow the machine to cool before storing. animal and objects. Remove all objects that may be blown away by the unit, or that the cutting blade/line may become caught on. WEELT650 Instruction Manual.indd 7 17/11/2017 10:11...
- Page 8 Appropriate gloves are also recommended. stored in a dry location. Keep the machine Wear protective hair covering to contain away from children and others not qualified long hair, preventing it from getting caught to use it. in machinery. WEELT650 Instruction Manual.indd 8 17/11/2017 10:11...
-
Page 9: Know Your Machine
7. Head Rotating Button 8. Motor Housing 9. Edging Wheel 10. Plant Protector 11. Guard 12. Wheel Bracket 13. Spool 14. Spool Cover 15. Self-Tapping Screw ST4.2x15 x3 16. Cross Recess Head Screw M4x25 17. Cutting Blade WEELT650 Instruction Manual.indd 9 17/11/2017 10:11... -
Page 10: Assembly
(Fig 5 & 6). Carefully peel off the protection cover over the cutting blade. Fig 1 Fig 2 Fig 3 Fig 4 Fig 5 Fig 6 WARNING! Never use the Line Trimmer unless the safety guard is correctly fitted. WEELT650 Instruction Manual.indd 10 17/11/2017 10:11... -
Page 11: Operation
The line trimmer shaft can be adjusted to suit the height of the operator. Pull the adjusting knob (9). Adjust the telescopic shaft (14) up or down to the appropriate height. Tighten the telescopic shaft button once adjustment is complete. WEELT650 Instruction Manual.indd 11 17/11/2017 10:11... - Page 12 Rotate the edging knob button, ensuring the motor housing section firmly clicks to secure in place as it audibly snaps into position. Now the trimmer can be used as the edge cutter. WEELT650 Instruction Manual.indd 12 17/11/2017 10:11...
- Page 13 In the right (dark grey) area, the threads rotate in your direction. This represents a high level of kickback risk and objects may be thrown in your direction by the rotation of the thread. You may be hurt as a result. WEELT650 Instruction Manual.indd 13 17/11/2017 10:11...
- Page 14 Firmly place the spool in the spool holder. Make sure that the cutting lines are not caught and pull them approx. 9 cm out of the spool. Place the spool cover into the spool holder and press it firmly down until the locking devices of spool cover securely click into place. WEELT650 Instruction Manual.indd 14 17/11/2017 10:11...
-
Page 15: Cleaning & Maintenance
2. Plug is damaged. damage 2. Check the plug If you can’t fix the fault yourself, contact your retailer. Please be aware that any improper repairs will also invalidate the warranty and additional costs may be incurred. WEELT650 Instruction Manual.indd 15 17/11/2017 10:11... -
Page 16: Parts Diagram & List
INSTRUCTION MANUAL PARTS DIAGRAM WEELT650 Instruction Manual.indd 16 17/11/2017 10:11... -
Page 17: Parts List
301070624B 301070651 Assembly WE131- WE131- Button Spring Flange Nut 103060276 104020030 WE132- WE131- Right Connector Nut Cover 301029420 301029099 WE132- WE131- Housing Cover Right Spool & 1.5m Line 301029415 301100001 WE131- Spool Cover 301021041 WEELT650 Instruction Manual.indd 17 17/11/2017 10:11... -
Page 18: Product Number
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Electric Grass Trimmer Model(s): WEELT650 Product Number: 1938173001 Type/Serial No. As per rating label on machine Voltage: 230-240V~50Hz Rated Power: 650W Protection: Class II Idle Speed: 11000 min- Cutting Width: 290mm This machine conforms to EU Directives, to which this declaration relates & corresponds to the relevant basic safety and health requirements of Directive: Machinery Directive 2006/42/EC Low Voltage Directive 2006/95/EC Noise Directive 2000/14/EC amended by 2005/88/EC, Annex VI For the relevant implementation of the safety and health requirements mentioned in the Directives, the following standards and/or technical specification(s) have been respected: EN 60335-1:2012+A11:2014, EN 50636-2-91:2014, EN 62233:2008 Guaranteed Sound Power Level: L = 96dB(A) Vibration Level: 4.5m/s² (Uncertainty – K=1.5m/s Notified Body: Intertek Testing Services Shanghai Addresses: Building No. 86, 1198 Qinzhou Road (North), Caohejing Development Zone, Shanghai 200233, China Authorised signatory and technical file holder Date: 10/11/2017 Name: Mr Simon Belcher Position: Managing Director Company: Handy Distribution Ltd Address: Murdock Rd, Swindon, Wiltshire, SN3 5HY. Signature: WEELT650 Instruction Manual.indd 18 17/11/2017 10:11... - Page 19 NOTES WEELT650 Instruction Manual.indd 19 17/11/2017 10:11...
- Page 20 INSTRUCTION MANUAL This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the conditional manufacturer domestic warranty*. Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
- Page 21 2. Period of Warranty Webb (excludes Electric Handheld) & Webb Pro, 2 year conditional warranty from the original date of sale to the fi rst domestic user. Webb Electric Handheld 1 year warranty from the original date of sale to the fi rst domestic user.
- Page 22 It is the owner’s responsibility to ensure that their Webb machine is maintained at specifi c intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
- Page 23 SERVICE BOOK Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 1st Service This must be stamped by an approved service dealer to qualify for a free second year warranty.
- Page 24 Service Record INSTRUCTION MANUAL 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date WEELT650 Instruction Manual.indd 24 17/11/2017 10:11...
-
Page 25: Warranty Registration
& services we provide, including information that we believe is relevant to your and/or your machine. We value your trust by giving us this information about yourself and we are committed to protecting your privacy. From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, offers, technical improvements or just opinions, which may be used for marketing, research or analysis purposes. - Page 26 Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY WEELT650 Instruction Manual.indd 26 17/11/2017 10:11...
