Page 1 26cc Loop Handle Petrol Line Trimmer WELT26 193869001 Operator’s Manual & Parts List Please read & understand this manual, paying particular attention to the safety instructions, before use. 07 Feb 2017 WELT26 193869001 IM.indd 1 07/02/2017 15:43...
Page 2 WELT26 193869001 IM.indd 2 07/02/2017 15:43...
Page 3 MAINTENANCE, CLEANING & STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST DECLARATION OF CONFORMITY WARRANTY For Spares or Support of your Webb product, please contact us: Tel: 01793 333212 Mon – Fri 8.30am to 5.00pm (Excl. Bank Holiday) Email: customerservice@webbgardenpower.co.uk www.webbgardenpower.co.uk WELT26 193869001 IM.indd 3...
Page 4: Safety Instructions
Indicates a poten ally hazardous situa on which, if not avoided, may result in minor or moderate injury. CAUTION Used without the safety alert symbol indicates a poten ally hazardous situa which, if not avoided, may result in property damage. WELT26 193869001 IM.indd 4 07/02/2017 15:43...
Page 5 DO NOT STORE FUEL IN THE MACHINE, fuel over 30 days old can become stale and if used, damage the carburetor, which is not covered by the manufacturer’s warranty. WELT26 193869001 IM.indd 5 07/02/2017 15:43...
Page 6: Specifications
Instead it shall be handed over to the applicable colle on point for the recycling of electrical and electronic equipment. For more detailed informa on about recycling of this product, please contact your local council oﬃce, your household waste disposal service or shop where you purchased the product. WELT26 193869001 IM.indd 6 07/02/2017 15:43...
Page 7 2. Driveshaft 3. D-Handle 4. Harness Eyelet 5. Ignition Switch 6. Safety Lever 7. Throttle Trigger 8. Air Filter Cover 9. Fuel Tank Cap 10. Fuel Tank 11. Primer Bulb 12. Choke Lever 13. Guard/Shield WELT26 193869001 IM.indd 7 07/02/2017 15:43...
Page 8 1. Place the clasp of the harness, through the Harness Eyelet located on the driveshaft 2. Adjust the Harness to ensure it is comfortable, but tight enough to allow you to operate the machine appropriately. WELT26 193869001 IM.indd 8 07/02/2017 15:43...
Page 9: Operation
ﬁngers or any other body part, consult your doctor. Check local regulations for sound level and hours of operation constraints. Never transport the machine, whilst the engine is running. WELT26 193869001 IM.indd 9 07/02/2017 15:43...
Page 10: Cutting With A Nylon Head
WARNING DO NOT trim any area where there maybe strands of fencing wire. Do not cut where you cannot see what the cu ng tool is cu ng. WELT26 193869001 IM.indd 10 07/02/2017 15:43...
Page 11: Fuel & Oil Mixture
If the machine is not going to be used for a long period, drain the mixture from the fuel tank, start the engine and drain the carburetor of any remaining fuel. (See Maintenance for further instru on) Dispose of any unwanted 2-stroke mixture at an authorised recycling point. WELT26 193869001 IM.indd 11 07/02/2017 15:43...
Page 12 3. Whilst holding the machine down with your le hand, away from the engine and p ull the engine recoil starter rope vigorously, un the engine starts. STOPPING THE ENGINE 1. Move the stop switch to the “STOP” pos on Choke Closed Cold Start Posi Choke Open Warm Start or Run Posi WELT26 193869001 IM.indd 12 07/02/2017 15:43...
Page 13: Maintenance, Cleaning & Storage
Clean & adjust the electrode gap to 0.6-0.7mm If the Spark Plug is visibly damaged or worn, replace immediately (See Speci on for details) Install the new/cleaned Spark Plug to ﬁnger htness, before fully htening with the spanner. WELT26 193869001 IM.indd 13 07/02/2017 15:43...
Page 14: Air Filter
Make sure air ﬁlter elements are clean. Install a new, properly gapped spark plug. When there is serious trouble with the unit, do not try to repair it yourself, but have your local approved service dealer inspect it for you. WELT26 193869001 IM.indd 14 07/02/2017 15:43...
Page 15 NOTES WELT26 193869001 IM.indd 15 07/02/2017 15:43...
Page 16 INSTRUCTION MANUAL PARTS DIAGRAM - WELT26 Engine WELT26 193869001 IM.indd 16 07/02/2017 15:43...
Page 17 PARTS LIST - WELT26 Engine Item No. Part No. Description Item No. Part No. Description WE03010110121 Screw M5x12 WE70070030026 Cover WE70030030853 Engine Cowling WE70030030164 Guide Screw GB/T9074.4 WE03020020055 WE03040020012 Washer GB/T97.1 4 M4x12 WE03010010062 Screw M5x20 WE02070010048 Spacer WE70070130069 Cylinder...
Page 18 INSTRUCTION MANUAL PARTS DIAGRAM - WELT26 Machine WELT26 193869001 IM.indd 18 07/02/2017 15:43...
Page 19 PARTS LIST - WELT26 Machine Item No Part No. Description Item No Part No. Description WE02050080021 Driveshaft WE70030070164 Trigger Housing - Right WE02050080008 Support Shaft WE02080020053 Handle Cover WE02010010118 Shaft WE70030180090 Sleeve WE02020160039 Connector WE03010010022 Screw M5x20 WE03090010076 Bearing 608-2RS/P5...
Page 20: Ec Declaration Of Conformity
10 Huaxia Road(m), Dongting, Wuxi, Jiangsu, 214100 (P.R China) Zertiﬁzierselle, Ridlerstraße 65, 80339 München, Germany Authorised signatory and technical ﬁle holder Date: 17/11/2015 Signature: Name: Mr Simon Belcher Position: Managing Director Company: Handy Distribution Ltd Address: Murdock Rd, Swindon, Wiltshire, 5HY. WELT26 193869001 IM.indd 20 07/02/2017 15:43...
Page 21 INSTRUCTION MANUAL NOTES WELT26 193869001 IM.indd 21 07/02/2017 15:43...
Page 22 INSTRUCTION MANUAL INSTRUCTION MANUAL This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the 2 year conditional manufacturer domestic warranty*. * Commercial/Professional & Hire users receive a 90 day warranty Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
Page 23: Service Book
(c) Neither GJ Handy & Co Ltd nor any company affiliated with GJ Handy & Co Ltd shall be liable in any event or manner whatsoever for incidental or consequential damages or injuries, including, but not limited to, loss of crops, loss of profit, out of pocket expenses or profits, rental of substitute equipment or other commercial losses. WELT26 193869001 IM.indd 23 07/02/2017 15:43...
Page 24 It is the owner’s responsibility to ensure that their Webb machine is maintained at specific intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
Page 25 SERVICE BOOK Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 1st Service This must be stamped by an approved service dealer to qualify for a free second year warranty.
Page 26 INSTRUCTION MANUAL INSTRUCTION MANUAL 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date WELT26 193869001 IM.indd 26 07/02/2017 15:43...
Page 27: Warranty Registration
& services we provide, including information that we believe is relevant to your and/or your machine. We value your trust by giving us this information about yourself and we are committed to protecting your privacy. From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, offers, technical improvements or just opinions, which may be used for marketing, research or analysis purposes.
Page 28 INSTRUCTION MANUAL Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY WELT26 193869001 IM.indd 28 07/02/2017 15:43...
