v
50cm Pole Hedge Trimmer
with 20V 2Ah Lithium-Ion Battery & Charger
WEV20PHT
1938202001
en - Original Instructions
Sales & Support: 01793 333212
Before use please read & understand this manual; paying particular attention to the safety instructions.
The manufacturer reserves the right to change the product specifi cation and livery according to continues product improvements.
Advertisement
Table of Contents
Related Manuals for Webb WEV20PHT
Summary of Contents for Webb WEV20PHT
- Page 1 50cm Pole Hedge Trimmer with 20V 2Ah Lithium-Ion Battery & Charger WEV20PHT 1938202001 en - Original Instructions Sales & Support: 01793 333212 Before use please read & understand this manual; paying particular attention to the safety instructions. The manufacturer reserves the right to change the product specifi cation and livery according to continues product improvements.
- Page 2 INSTRUCTION MANUAL 18 March 19 Copyright Notice Copyright © Handy Distribution Permission is granted to reproduce this publication for personal & educational use only. Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Handy Distribution.
-
Page 3: Table Of Contents
Weight without Battery N.W 3.5 kg Consistent with our policy of continuous improvement, WEBB reserves the right to change the design and configuration of any of its products without notice or obligation. Therefore, please treat the text and images in this manual for illustrative purposes only. They may in no case serve as a basis for any legal claim. -
Page 4: Important Information
INSTRUCTION MANUAL IMPORTANT INFORMATION WARNING Read this instruction manual carefully before operating this machine. Make sure that you are familiar with the controls and properly operate the machine. Following these instructions to reduce the risk of fire, electric shock and personal injury. IF NOT USED PROPERLY THIS MACHINE CAN BE DANGEROUS! This machine can cause serious injury to the operator and others, the warning and safety instructions must be followed to ensure reasonable safety and efficiency in using this product. -
Page 5: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS It is important that you read and understand the owner’s manual and labels affixed to the machine. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product. - Page 6 INSTRUCTION MANUAL GENERAL SAFETY WARNINGS connecting to battery, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power WARNING: tools that have the switch on invites Read all safety warnings and all accidents.
- Page 7 surface only, because the cutter blade may instructions, taking into account the working conditions and the work to be contact hidden wiring. Cutter blades contacting a “live” wire may make exposed performed. Use of the power tool for operations different from those intended metal parts of the power tool “live”...
- Page 8 INSTRUCTION MANUAL where they could get pinched or cut. NEVER For transportation, secure the machine touch blade or service unit unless the against movement or falling to prevent injury to persons or damage to the battery pack is removed. Switch off and remove the battery pack off machine.
- Page 9 practices are all thought to contribute to Check all nuts, bolts and screws at frequent intervals for proper tightness to ensure the the development of these symptoms. There are measures that can be taken by the product is in safe working condition. Any part that is damaged should be properly operator to possibly reduce the effects of repaired or replaced by an authorised...
- Page 10 INSTRUCTION MANUAL OPERATING TIMES SAFE DISPOSAL OF BATTERIES Please check noise abatement regulations prevailing in your country. Our batteries are designed according to the latest state of technology and optimised for the use in electric tools. Lithium ion cells contain hazardous substances and may therefore not be disposed off with normal household waste.
-
Page 11: Know Your Machine
KNOW YOUR MACHINE 1. Rear Handle 2. Trigger 3. Front Handle 4. Safety Button 5. Shoulder Strap 6. Blade Assembly & Guard 7. Head Adjuster 8. Battery 2Ah 9. Charger 10. Telescopic Adjuster... -
Page 12: Assembly
INSTRUCTION MANUAL ASSEMBLY INSTALLING THE TELESCOPIC HANDLE 1. Slide the telescopic handle into the head motor housing, until you reach the stop position. 2. Tighten the Collar. COLLAR... -
Page 13: Battery
BATTERY CARE There will be some charge present in the Battery on delivery, but to ensure maximum • running time, charge your Battery for 4-hours before first use. • If over a period of time the Battery quickly runs down after a full 4-hour charging period, a replacement Battery is needed. -
Page 14: Operation
INSTRUCTION MANUAL WINTER STORAGE • Fully charge for 4-hours before winter storage. • Re-charge the Battery every 3 to 4 months for a full 4-hour charging period to top up the battery during winter storage. • Avoid extended storage without re-charge. Store in a cool dry place. - Page 15 Switching on: 1. Remove the blade guard from the blade assembly. 2. Ensure the battery is correctly housed in the handle. 3. Push the safety button with your thumb. 4. Pull the On/Off trigger upwards with your hand. Switching off: Release the On/Off trigger.
- Page 16 INSTRUCTION MANUAL TILTING THE MOTOR HEAD When trimming at high or low level, the motor head can be tilted at an angle of 90 to -45 in 45 increments. 1. Remove the battery from the handle. 2. Press the Head Adjuster button. 3.
-
Page 17: Cleaning & Maintenance
CLEANING & MAINTENANCE DANGER Prior to conducting maintenance or cleaning: Remove the battery from the machine. The trimmer blade could still move after being switched off! Always remove battery before performing any work on the trimmer! Note: Clean unit immediately after every use. Hedge debris when dry is very hard and are very difficult to remove. -
Page 18: Trouble Shooting
INSTRUCTION MANUAL TROUBLE SHOOTING Switch off the trimmer and disconnect the battery before inspecting, cleaning or working on the thread. Error/Fault Cause Remedy Lubricate blades with rust Dry, corroded blades. preventative solution or light machine oil. Straighten blade or blade support. Slow running, noisy or hot Blades or blade support To be actioned by an approved... - Page 19 Notes...
-
Page 20: Parts Diagram & List
PARTS DIAGRAM... - Page 21 PARTS LIST Item Item Part No. Webb Description Part No. Webb Description WE144- WE145- Blade Cover Left Connection 301062752 301062922 WE144- WE145- Motor Assembly Copper Insert 102010429 103040105 WE144- WE145- Hex Bolts Plug Sheath 104040178 301062924 WE144- WE145- Spring Washer...
-
Page 22: Product Number 1938202001
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Lithium-ion Battery Hedge Trimmer Model(s): WEV20PHT Product Number: 1938202001 Type/Serial No. As per rating label on machine Battery: 18Vd.c (20Vd.c Max) No Load Speed: 1200 rpm Max. - Page 23 Notes...
- Page 24 INSTRUCTION MANUAL This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the conditional manufacturer domestic warranty*. Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
- Page 25 Webb (excludes Electric Handheld) & Webb Pro, 2 year conditional warranty from the original date of sale to the fi rst domestic user. Webb Electric Handheld & Dynamic, Legacy & Heritage 1 year warranty from the original date of sale to the fi rst domestic user.
- Page 26 It is the owner’s responsibility to ensure that their Webb machine is maintained at specifi c intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
- Page 27 Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 1st Service This must be stamped by an approved service dealer to qualify for a free second year warranty.
- Page 28 Service Record INSTRUCTION MANUAL 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date...
- Page 29 Email From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, off ers or just opinions, which may be used for marketing, research or analysis purposes.
- Page 30 Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY...
Need help?
Do you have a question about the WEV20PHT and is the answer not in the manual?
Questions and answers
Battery not charging. Red light on charger but when I unplug battery light goes green
The Webb WEV20PHT battery may not be charging when the charger shows a red light due to one or more of the following reasons:
1. The charger is not plugged into a working outlet. Check the outlet by plugging in another device.
2. The battery is not properly inserted into the charger. Reinsert the battery until the green LED appears.
3. The surrounding air temperature is too hot or too cold. Move the charger and tool to an area with a temperature between 40°F (4.5°C) and 105°F (40.5°C).
If these steps do not fix the issue, contact your retailer.
