250W Electric
Line Trimmer
WEELT250
1938171001
Operator's Manual
Please read & understand this manual, paying particular attention to the safety instructions, before use.
The manufacturer reserves the right to change the product specifi cation and livery according to continues product improvements.
WEELT250 Instruction Manual.indd 1
16/11/2017 12:24
Advertisement
Table of Contents
Related Manuals for Webb WEELT250
Summary of Contents for Webb WEELT250
- Page 1 Operator’s Manual Please read & understand this manual, paying particular attention to the safety instructions, before use. The manufacturer reserves the right to change the product specifi cation and livery according to continues product improvements. WEELT250 Instruction Manual.indd 1 16/11/2017 12:24...
- Page 2 WEELT250 Instruction Manual.indd 2 16/11/2017 12:24...
-
Page 3: Specification
GUARANTEE DECLARATION OF CONFORMITY SPECIFICATION Model WEELT250 Product Number 1938171001 Motor Capacity 250W Rated Voltage 230–240 V~50 Hz Trimming Speed 13,000 min- Trimmer Line Diameter 1.2mm Trimming Cutting Width 230mm Protection Rating Guarantee Sound LWA 96 dB(A) Power Level Vibration 2.5m/s , K=1.5dB Weight N.W 1.3kg Consistent with our policy of continuous improvement, WEBB reserves the right to change the design and configuration of any of its products without notice or obligation. Therefore, please treat the text and images in this manual for illustrative purposes only. They may in no case serve as a basis for any legal claim. If you require any assistance with regards to the contents or operation of your machine, please call our Customer Service Team on 01793 333212 or email customerservice@webbgardenpower.co.uk (Monday to Friday 8.00am to 5.30pm excl. Bank Holidays) WEELT250 Instruction Manual.indd 3 16/11/2017 12:24... - Page 4 INSTRUCTION MANUAL IMPORTANT INFORMATION WARNING: Read this instruction manual carefully before operating this machine. Make sure that you are familiar with the controls and properly operate the machine. Following these instructions to reduce the risk of fire, electric shock and personal injury. IF NOT USED PROPERLY THIS MACHINE CAN BE DANGEROUS! This machine can cause serious injury to the operator and others, the warning and safety instructions must be followed to ensure reasonable safety and efficiency in using this product. The operator is responsible for following the warning and safety instructions in this manual and on the machine. Never use the product unless the fixing screws or guards are correctly positioned. DESIGNED FOR DOMESTIC USE ONLY. For use in private gardens are those with an annual use not generally exceeding 50 hours and that are primarily used for tending GRASS OR LAWN AREAS, but not in public facilities, parks or sports grounds and not for agricultural or forestry use. Compliance with the operating manual supplied by the manufacturer is a prerequisite for the proper usage of the lawn mower. The operating manual contains servicing and maintenance instructions as well as directions for use. TRAINING Read the instructions carefully: Be familiar with the controls and the proper use of the equipment. Never allow children or people unfamiliar with these instructions to use the product. Local regulations can restrict the age of the operator. Never operate while people, especially children, or pets are nearby. Keep in mind that the operator or user is responsible for accidents or hazards involving the machine that occur to other people or their property. WEELT250 Instruction Manual.indd 4 16/11/2017 12:24...
-
Page 5: General Safety Instructions
DANGER WARNING Used without the safety alert symbol, Indicates a potentially hazardous situation indicates a potentially hazardous situation CAUTION which, if not avoided, may result in minor or which, if not avoided, may result in moderate injury. CAUTION property damage. Sound Power Level (Image used for illustration purposes only, Class II Protection check machine and Declaration of Conformity for actual reading) According to the European directive 2012/19/EU for Waste Electrical & Separate collection of used products and Electronic Equipment and its packaging allow materials to be recycled & implementation into national law, electrical used again. Reuse of recycled materials and electronic equipment that are no longer helps prevent environmental pollution and usable must be collected separately & reduces the demand for raw material. disposed of in an environmentally correct manner. CE marking is a certification mark that indicates conformity with health, safety, and environmental protection standards for products sold within the European Economic Area. WEELT250 Instruction Manual.indd 5 16/11/2017 12:24... -
Page 6: Electrical Safety
Make sure to always wear the required • Unsuitable tools inserted; personal protective equipment. • Unsuitable material; The clothing of the operator should be close • Insufficient maintenance. fitting. Avoid wearing loosely fitting You can reduce the risks considerably by clothing. Wear sturdy footwear and long following the tips below: work trousers. • Maintain the device in accordance with the instructions within this manual. Avoid working at low temperatures. • • When it is cold, make sure your body and your hands in particular, are kept warm. Take regular breaks and move your • hands at the same time to promote circulation. ELECTRICAL SAFETY The device may only be connected to a Always wear appropriate footwear, such as socket that is correctly installed and work boots, and trousers when operating grounded. the mower. Do not operate the equipment WEELT250 Instruction Manual.indd 6 16/11/2017 12:24... -
Page 7: Device-Specific Safety Instructions
DEVICE-SPECIFIC SAFETY INSTRUCTIONS Keep the handle dry and free of grease. Symbols affixed to your tools may not be removed or covered. Information on the Make sure to always wear personal protective clothing when operating. device that is no longer legible must be Make sure the connection cable is always replaced immediately. kept out of the working range of the device. Read the operating manual before using the Make sure that cables always lead away device from the rear of the device. MAINTENANCE AND STORAGE Make sure you are positioned firmly and Keep all nuts, bolts and screws tight to be with a natural stance when working with sure the equipment is in safe working the device. condition. Always hold the unit tightly with both Replace worn or damaged parts for safety. hands. Keep the machine free of grass, leaves, or Before starting work, check the area for other debris build-up. animal and objects. Remove all objects that Allow the machine to cool before storing. may be blown away by the unit, or that the cutting blade/line may become caught on. WEELT250 Instruction Manual.indd 7 16/11/2017 12:24... - Page 8 Vibration during use may cause these to correct handles provided with the machine. MAINTAIN YOUR MACHINE WITH CARE loosen. Replace damaged, missing or failed parts Clean the machine immediately after use. before using. Keep the machine clean to ensure it Warning labels carry important information. operates to its full and safest performance. Replace any missing or damaged warning When maintaining this machine, only the labels. manufacturer’s original replacement parts DRESS PROPERLY should be used. The use of non-original Do not wear loose clothing, gloves, scarfs, manufacturer parts may invalidate your warranty. neckties or jewellery (rings, wrist watches), which can be caught in moving parts. STORE IDLE EQUIPMENT When not in use, the machine should be ALWAYS wear protective eye and ear wear. Appropriate gloves are also recommended. stored in a dry location. Keep the machine away from children and others not qualified Wear protective hair covering to contain long hair, preventing it from getting caught to use it. in machinery. WEELT250 Instruction Manual.indd 8 16/11/2017 12:24...
-
Page 9: Know Your Machine
KNOW YOUR MACHINE 1. Trimmer Head 2. Handle Assembly 3. Front Handle 4. On/Off Trigger 5. Electric Cable 6. Locking Screw 7. Lower Body Assembly 8. Guard WEELT250 Instruction Manual.indd 9 16/11/2017 12:24... -
Page 10: Protective Guard
INSTRUCTION MANUAL ASSEMBLY Remove the machine and contents from the carton. Be sure the carton is empty before discarding. If you require any assistance with regards to the contents or operation of your machine, please call our Customer Service Team on 01793 333212 or email customerservice@webbgardenpower.co.uk (Monday to Friday 8.00am to 5.30pm excl. Bank Holidays) PROTECTIVE GUARD CAUTION Risk of injury! On the under- side of the protective guard there is a sharp blade designed to cut the thread. Remove the transportation protection after mounting. Fit the protective guard (8) onto the trimmer and line up the fixing holes. Secure with 2x ST4.2x12BT Screws. MAIN BODY Match up the upper and lower body assemblies. Ensure the you line up with both sections facing the correct way. Insert the Upper Body into the Lower Body until you hear a click. Insert 2x ST4.2x12BT Screws to secure. WEELT250 Instruction Manual.indd 10 16/11/2017 12:24... -
Page 11: Operation
OPERATION DANGER Risk of injury! The device may only be put into operation if there are no defects. If a part is defective it must be replaced before the device is used again. WARNING Risk of injury! Before starting work check the area and remove all objects which may be kicked up by the unit. Check to make sure there are no visible defects. Check to make sure all device components are correctly mounted INTENDED USE The trimmer is designed for trimming grass on smaller areas of lawn. MAINS CONNECTION Check that the voltage indicated on the tools product/rating label corresponds with the mains voltage and connect the trimmer to an unearthed socket. Only use extension cables with maximum length of 25 metres and a cross section of at least 1.5mm². POWER CORD Note: Avoid the electric cable being pulled out of the mains socket. Always check the electric cable sits firmly on the cable restraint before using the trimmer. Make a loop in the electric cable and push it through the square hole below the On/Off trigger. Place the end of the loop around the cable restraint and ensure that it is tightened hard enough not to become loose during use. SWITCHING ON AND OFF Switching on: Pull the On/Off trigger upwards (1). Switching off: Release the On/Off trigger (1). WEELT250 Instruction Manual.indd 11 16/11/2017 12:24... -
Page 12: Cutting Tips
Feed out new line by pressing the trimmer head firmly on the ground with the trimmer turned on and the trimmer head spinning. Run the trimmer for a few seconds without trimming to allow the trimmer line to be cut to the correct length. CUTTING TIPS Only cut with the left (shown here as light grey) area of the cutting unit when the unit is being moved from right to left. In the right (dark grey) area, the threads rotate in your direction. This represents a high level of kickback risk and objects may be thrown in your direction by the rotation of the thread. You may be hurt as a result. When the unit is moved from left to right, ensure that the nylon line is kept away from the grass to ensure that the grass is not thrown up. Cut long grass from top to bottom to ensure that the grass does not get tangled around the spool. Only use the tip of the nylon line. This way you use less nylon line and avoid grass getting caught up in the spool. Only take the nylon line as close as necessary to posts, walls, fences etc. Solid objects will wear the nylon line. Tree trunks, young trees and bushes may be damaged by the nylon line. CLEANING & MAINTENANCE DANGER Prior to conducting maintenance or cleaning: Unplug from the power source. Note: Clean unit immediately after every use. Remains of dried grass is very hard, and are very difficult to remove. BEFORE EACH USE What? How? Check the power cable and connector for Conduct a visual inspection and have the cable damage. replaced by an electrician if necessary. IF NECESSARY What? How? Cleaning the device Wipe the unit with a damp cloth. Replace the thread if it is too short. Replace the spool WEELT250 Instruction Manual.indd 12 16/11/2017 12:24... -
Page 13: Replacing The Spool
REPLACING THE SPOOL Removing the thread spool Press together the two locking devices (14) on the spool cap (10) and remove it from the trimmer. Remove the spool from the cap. Remove any dirt or grass cuttings. Guide both ends of the trimmer line (13) on the replacement spool through the holes (15) in the spool cap (one on each side). Replace the spool firmly into the cap. Check that the trimmer lines are not stuck and pull them out to 9cm in length from the spool. Put the spool cap over the spot set on the spring (12) and press firmly on it until the spool caps locking devices firmly click into place. STORAGE & TRANSPORTATION STORAGE Store the tool in a dry and well-ventilated place. TRANSPORTATION When dispatching, try to use the original packaging, if possible. TROUBLE SHOOTING Error/Fault Cause Remedy No power supply. Check the cable, plug and fuse. Motor Not Working Defective connecting cable Contact the retailer Nylon Line used up Replace the spool Nylon line doesn’t unwind Spool blocked Remove the cause of the blockage. Please be aware that any improper repairs will also invalidate the manufacturer’s warranty. WEELT250 Instruction Manual.indd 13 16/11/2017 12:24... -
Page 14: Parts Diagram
INSTRUCTION MANUAL PARTS DIAGRAM WEELT250 Instruction Manual.indd 14 16/11/2017 12:24... -
Page 15: Parts List
WE130-103060069 Spring WE130-301992017 Insulating Cap WE130-301029347 Fan with inserts WE130-4070219 Motor Assembly WE130-105020003 Rubber Mat WE130-301021122 Right Housing WE130-104030136 Screw ST4.2*15 BT WE130-102080511 Connecting Line WE130-104030135 Screw ST4.2*12 BT WE130-301029540 Right Handle WE130-102020039 Micro Switch WE130-103060034 Trigger Spring WE130-301062081 Button WE130-102070754 BS Plug & Cable WE130-301029541 Left Handle WE130-301021125 Left Housing WE130-301029497 Guard with ST4 Blade WEELT250 Instruction Manual.indd 15 16/11/2017 12:24... -
Page 16: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Electric Grass Trimmer Model(s): WEELT250 Product Number: 1938171001 Type/Serial No. As per rating label on machine Voltage: 230-240V~50Hz Rated Power: 250W Protection: Class II Max Cutting Speed: 13,000 min- Cutting Width: 230mm This machine conforms to EU Directives, to which this declaration relates & corresponds to the relevant basic safety and health requirements of Directive: Machinery Directive 2006/42/EC Noise Directive 2000/14/EC amended by 2005/88/EC, Annex VI For the relevant implementation of the safety and health requirements mentioned in the Directives, the following standards and/or technical specification(s) have been respected: EN 60335-1:2012+A11:2014, EN 50636-2-91:2014 Guaranteed Sound Power Level: L = 96dB(A) Vibration Level: 2.5m/s² (Uncertainty – K=1.5m/s Notified Body: Intertek Testing Services Shanghai Addresses: Building No. 86, 1198 Qinzhou Road (North), Caohejing Development Zone, Shanghai 200233, China. Authorised signatory and technical file holder Date: 06/11/2017 Name: Mr Simon Belcher Position: Managing Director Company: Handy Distribution Ltd Address: Murdock Rd, Swindon, Wiltshire, SN3 5HY. Signature: WEELT250 Instruction Manual.indd 16 16/11/2017 12:24... - Page 17 NOTES WEELT250 Instruction Manual.indd 17 16/11/2017 12:24...
- Page 18 INSTRUCTION MANUAL This Service Book is provided with your Webb, to help you look after your purchase to our recommendations and enable you to take advantage of the conditional manufacturer domestic warranty*. Present this service book to your authorised Webb repair dealer, whenever a service or a warranty appraisal is required.
- Page 19 2. Period of Warranty Webb (excludes Electric Handheld) & Webb Pro, 2 year conditional warranty from the original date of sale to the fi rst domestic user. Webb Electric Handheld 1 year warranty from the original date of sale to the fi rst domestic user.
- Page 20 It is the owner’s responsibility to ensure that their Webb machine is maintained at specifi c intervals. Any approved Webb service dealer can undertake a service, which are specialised in our products and will be aware of your particular machine and any technical updates which will save valuable time &...
- Page 21 SERVICE BOOK Your servicing Webb approved dealer will stamp & date the below relevant sections, when the correct service actions have been completed. PLEASE ENSURE THE SERVICE BOOK IS AVAILABLE FOR THE DEALER, DURING SERVICE WORK. 1st Service This must be stamped by an approved service dealer to qualify for a free second year warranty.
- Page 22 Service Record INSTRUCTION MANUAL 48 Months 60 Months Date Date 72 Months 84 Months Date Date 96 Months 108 Months Date Date 120 Months 132 Months Date Date WEELT250 Instruction Manual.indd 22 16/11/2017 12:24...
- Page 23 & services we provide, including information that we believe is relevant to your and/or your machine. We value your trust by giving us this information about yourself and we are committed to protecting your privacy. From time to time Webb, its associated companies, authorised dealers or third parties working on our behalf may wish to contact you regarding our products, services, offers, technical improvements or just opinions, which may be used for marketing, research or analysis purposes.
- Page 24 Webb Lawnmowers Murdock Road Dorcan Swindon Wiltshire SN3 5HY WEELT250 Instruction Manual.indd 24 16/11/2017 12:24...
