7.2.2 Ethernet Statistics Page
The Ethernet statistics web page contains the following information:
Current IP Configuration
DHCP:
Host Name:
IP Address:
Subnet Mask:
Gateway Address:
DNS Server #1:
DNS Server #2:
Domain Name:
Current Ethernet Configuration
MAC Address
Port 1
Port 2
Interface Counters
In Octets:
In Ucast Packets:
In NUcast packets:
In Discards:
In Errors:
In Unknown Protos:
Out Octets:
Out Ucast packets:
Out NUcast packets:
Out Discards:
Out Errors:
Media Counters
Alignment Errors
FCS Errors
Single Collisions
Multiple Collisions
SQE Test Errors
Deferred Transmissions
Late Collisions
Excessive Collisions
MAC Receive Errors
MAC Transmit Errors
Carrier Sense Errors
Frame Size Too Long
Frame Size Too Short
®
Anybus CompactCom ™ 40 PROFINET IRT Network Guide
Description
-
-
-
-
-
-
-
-
Description
-
Speed: The current link speed.
Duplex: The current duplex configuration.
Speed: The current link speed.
Duplex: The current duplex configuration.
Description
Received bytes.
Received unicast packets.
Received non-unicast packets (broadcast and multicast).
Received packets discarded due to no available memory buffers.
Received packets discarded due to reception error.
Received packets with unsupported protocol type.
Sent bytes.
Sent unicast packets.
Sent non-unicast packets (broadcast and multicast).
Outgoing packets discarded due to no available memory buffers.
Transmission errors.
Description
Frames received that are not an integral number of octets in length.
Frames received that do not pass the FCS check.
Successfully transmitted frames which experienced only one collision.
Successfully transmitted frames that experienced more than one
collision.
Number of times SQE test error messages are generated.
Frames for which first transmission attempt is delayed because the
medium is busy.
Number of times a collision is detected later than 512 bit-times into
the transmission of a packet.
Frames for which a transmission fails due to excessive collisions.
Frames for which reception of an interface fails due to an internal
MAC sublayer receive error.
Frames for which transmission fails due to an internal MAC sublayer
receive error.
Times that the carrier sense condition was lost or never asserted
when attempted to transmit a frame.
Frames received that exceed the maximum permitted frame size.
Frames received that are shorter than lowest permitted frame size.
