Appendix H: Backward Compatibility
H.2 Hardware Compatibility
Anybus CompactCom is available in three hardware formats; Module, Chip, and Brick.
H.2.1 Module
The modules in the 30-series and the 40-series share physical characteristics, like dimensions,
outline, connectors, LED indicators, mounting parts etc. They are also available as modules
without housing.
Fig. 24 Anybus CompactCom M30/M40
H.2.2 Chip
The chip (C30/C40) versions of the Anybus CompactCom differ completely when it comes to
physical dimensions.
®
Anybus CompactCom ™ 40 PROFINET IRT Network Guide
There is no way to migrate a chip solution from the 30-series to the 40-series
without a major hardware update.
