Anybus Module Objects

Object Attributes (Instance #0)

# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance
number
Instance Attributes (Instance #1)
Extended
# Name
1 OnLineTrans
2 OffLineTrans
3 (reserved)
4 Last AbortInd
ReasonCode
5 AddedApis
6 ApiList
7 EstablishedArs
8 ArList
-
9
10 Port 1 MAC Address
11 Port 2 MAC Address
®
Anybus CompactCom ™ 40 PROFINET IRT Network Guide
Access Data Type Value
Get Array of "Network PROFINET IO"
Char
Get UINT8 01h
Get UINT16 0001h
Get UINT16 0001h
Access Type Value
Get UINT32 Diagnostic counters; keeps track of the number of on-line
transitions
Get UINT32 Diagnostic counters; keeps track of the number of off-line
transitions
Get UINT16 Reason code for most recent Abort indication
See command details for command AR_Abort
Get UINT16 Returns the number of APIs added (including API 0)
First element will always be zero and the second element will
Get Array of
UINT32 contain an additional API. Length of the array is determined by
parameter "AddedApis".
Get UINT16 The number of Application Relationships currently established
Get Array of Array of Application Relationship handles. Length of array is de-
UINT16 termined by parameter "EstablishedArs".
- - -
Get Array of 6 Byte PROFINET Port 1 MAC address
UINT8
See also...
Get Array of 6 Byte PROFINET Port 2 MAC address
UINT8
See also...
- Ethernet Host Object (F9h), p. 203
- Ethernet Host Object (F9h), p. 203
