Web Server
7.2.1 Network Configuration
The network configuration page provides interfaces for changing TCP/IP and SMTP settings in
the Network Configuration Object.
Fig. 10
The module needs a reset for the changes to take effect.
Available IP Configuration Settings
Name
DHCP
IP address
Subnet mask
Gateway address
Host name
Domain name
Available SMTP Settings
Name
Server
User
Password
Safety Module Settings
Name
F-address
®
Anybus CompactCom ™ 40 PROFINET IRT Network Guide
Description
Checkbox for enabling or disabling DHCP
Default value: disabled
The TCP/IP settings of the module
Default values: 0.0.0.0Value ranges: 0.0.0.0 - 255.255.255.255
IP address or name
Max 64 characters
IP address or name
Max 48 characters
Description
IP address or name
Max 64 characters
Max 64 characters
Max 64 characters
Description
The F-address used for the Safety Module as PROFIsafe address
39 (258)
