Ethernet Host Object (F9h)

Object Description
This object implements Ethernet features in the host application.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
Instance Attributes (Instance #1)
• If an attribute is not implemented, the default value will be used.
• The module is preprogrammed with a valid MAC address. To use that address, do not implement attrib-
ute #1.
• Do not implement attributes #9 and #10, only used for PROFINET devices, if the module shall use the
preprogrammed MAC addresses.
• If new MAC addresses are assigned to a PROFINET device, these addresses (in attributes #1, #9, and
#10) have to be consecutive, e.g. (xx:yy:zz:aa:bb:01), (xx:yy:zz:aa:bb:02), and (xx:yy:zz:aa:bb:03) with
the first five octets not changing.
# Name Ac-
cess
1 MAC address Get
2 Enable HICP Get
3 Enable Web Get
Server
4 (reserved)
5 Enable Web ADI Get
access
6 Enable FTP Get
server
7 Enable admin Get
mode
8 Network Status Set
®
Anybus CompactCom ™ 40 PROFINET IRT Network Guide
Get_Attribute
Get_Attribute
Set_Attribute
Access Data Type
Get Array of CHAR
Get UINT8
Get UINT16
Get UINT16
Data Type Default
Value
-
Array of
UINT8
BOOL True
(Enabled)
BOOL True
(Enabled)
BOOL True
(Enabled)
BOOL True
(Enabled)
BOOL False
(Disabled)
-
UINT16
Value
"Ethernet"
02h
0001h
0001h
Comment
6 byte physical address value; overrides the preprog-
rammed Mac address. Note that the new Mac address
value must be obtained from the IEEE.
Do not implement this attribute if the preprogrammed Mac
address is to be used.
Enable/Disable HICP
Enable/Disable Web Server
(Not used if Transparent Ethernet is enabled.)
Reserved for Anybus CompactCom 30 applications.
Enable/Disable Web ADI access
(Not used if Transparent Ethernet is enabled.)
Enable/Disable FTP server
(Not used if Transparent Ethernet is enabled.)
Enable/Disable FTP admin mode
(Not used if Transparent Ethernet is enabled.)
See below.
