Host Application Objects
Access
Attr ID#
Rule
Name
10
Get
Current
11
Get
Min Current
12
Get
Max Current
13
Get
Apparent Power
®
Anybus
CompactCom
™
40 PROFINET IRT Network Guide
Element
Data Type
number:description
UINT64
0: L1 TS
FLOAT
1: L1 Value
UINT32
2: Reserved
UINT64
3: L2 TS
FLOAT
4: L2 Value
UINT32
5: Reserved
UINT64
6: L3 TS
FLOAT
7: L3 Value
UINT32
8: Reserved
UINT64
9: Avg L TS
FLOAT
10: Avg L Value
UINT32
11: Reserved
UINT64
12: N TS
FLOAT
13: N Value
UINT32
14: Reserved
UINT64
0: L1 TS
FLOAT
1: L1 Value
UINT32
2: Reserved
UINT64
3: L2 TS
FLOAT
4: L2 Value
UINT32
5: Reserved
UINT64
6: L3 TS
FLOAT
7: L3 Value
UINT32
8: Reserved
UINT64
9: Avg L TS
FLOAT
10: Avg L Value
UINT32
11: Reserved
UINT64
12: N TS
FLOAT
13: N Value
UINT32
14: Reserved
UINT64
0: L1 TS
FLOAT
1: L1 Value
UINT32
2: Reserved
UINT64
3: L2 TS
FLOAT
4: L2 Value
UINT32
5: Reserved
UINT64
6: L3 TS
FLOAT
7: L3 Value
UINT32
8: Reserved
UINT64
9: Avg L TS
FLOAT
10: Avg L Value
UINT32
11: Reserved
UINT64
12: N TS
FLOAT
13: N Value
UINT32
14: Reserved
UINT64
0: L1 TS
FLOAT
1: L1 Value
UINT32
2: Reserved
UINT64
3: L2 TS
FLOAT
4: L2 Value
UINT32
5: Reserved
UINT64
6: L3 TS
FLOAT
7: L3 Value
UINT32
8: Reserved
UINT64
9: Total TS
FLOAT
10: Total Value
UINT32
11: Reserved
161 (258)
PROFIenergy
Measurement ID
7
8
9
33
-
76
77
78
94
-
46
47
48
64
-
10
11
12
36
SCM-1202-023 EN 1.8
