LED CURTAIN LIGHTS
LED CURTAIN LIGHTS
Operation and safety notes
IAN 283548
6 hour timer with automatic repetition
on a daily basis
Suitable for in- and outdoor use.
8 energy-saving LEDs
(For HG01361A-BS /
HG01361B-BS / HG01361C-BS)
30 energy-saving LEDs
(for HG02838-BS)
LED CURTAIN LIGHTS
˜ Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product. They
contain important information concerning safety, use
and disposal.
GB/IE/NI
HG01361A-BS / B-BS
4
3
2
1
HG01361C-BS
4
3
2
1
Before using the product, please familiarise yourself
with all of the safety information and instructions for
Use. Only use the product as described and for the
specified applications. If you pass the product on to
anyone else, please ensure that you also pass on all
the documentation with it.
˜ Proper use
This product is suitable for use indoors and
outdoors. This product is intended for use in private,
domestic environment only and not for commercial
purposes.
Plugs for indoor use only.
˜ Description of parts and
features
LED light chain
Mains adapter
1
3
Timer-button
Suction cup
2
4
GB/IE/NI
HG02838-BS
4
- +
3
2
1
˜ Included items
1 LED light chain
8 Suction cups
1 Mains adapter
1 Operating instructions
˜ Technical data
LED light chain + Mains adapter:
Total power consumption: approx. 1.1 W
LED light chain:
Operating voltage:
3.2 V
LED:
For model A-BS–C-BS:
8 x 3 V
, 20 mA
For model HG02838-BS:
30 x 3 V
, 20 mA
(not replaceable)
Protection system:
IP44 (splashproof)
Mains adapter:
Nom. voltage input:
220–240 V ~ , 50–60 Hz
Nom. voltage output:
3.2 V
, 0.6 W
Protection class:
Protection system:
IP44 (splashproof)
GB/IE/NI
Mains adapter:
JT-DC3.2V0.6W-0-IP44)

Safety information

BEFORE USING THE PRODUCT, PLEASE
FAMILIARISE YOURSELF WITH ALL OF THE
SAFETY INFORMATION AND INSTRUCTIONS
FOR USE! WHEN PASSING THIS PRODUCT ON
TO OTHERS, PLEASE ALSO INCLUDE ALL THE
DOCUMENTS!
In the case of damage resulting from non-
compliance with these operating instructions the
guarantee claim becomes invalid! No liability is
accepted for consequential damage! In the case
of material damage or personal injury caused by
incorrect handling or non-compliance with the safety
instructions, no liability is accepted!
WARNING!
DANGER OF
DEATH AND ACCIDENTS FOR
TODDLERS AND CHILDREN!
GB/IE/NI
List of pictograms used
Direct current
Alternating current
Splashproof
Safety class II
Short-circuit-proof safety
Isolating transformer
Independent lamp control gear
Polarity of output terminal
GB/IE/NI
Never leave children unsupervised with the
packaging material. The packaging material
represents a danger of suffocation. Children
frequently underestimate the dangers. Please
keep children away from the product at all times.
This product is not a toy and should not be

played by children. Children are not able to
understand the dangers that can occur when
handling this product.
This product can be used by children aged from

8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the product in a safe way and understand the
hazards involved. Children shall not play with
the product. Cleaning and user maintenance
shall not be made by children without
supervision.
Ensure that the product is installed by suitably

experienced or qualified persons only.
GB/IE/NI
