Rack Mount Series
UL Listed CCTV Power Supplies
Installation Guide
Models Include:
• R615DC8UL
- 6-15VDC @ 4 amp.
- Eight (8) Fuse Protected
Outputs.
• R615DC416UL
- 6-15VDC @ 4 amp.
- Sixteen (16) Fuse Protected
Outputs.
• R615DC616UL
- 6-15VDC @ 6 amp.
- Sixteen (16) Fuse Protected
Outputs.
• R615DC8ULCB
- 6-15VDC @ 4 amp.
- Eight (8) PTC Protected
Outputs.
• R615DC416ULCB
- 6-15VDC @ 4 amp.
- Sixteen (16) PTC Protected
Outputs.
• R615DC616ULCB
- 6-15VDC @ 6 amp.
- Sixteen (16) PTC Protected
Outputs.
Rev. 050106
Advertisement
Related Manuals for Altronix R615DC8UL
Summary of Contents for Altronix R615DC8UL
-
Page 1: Installation Guide
Rack Mount Series UL Listed CCTV Power Supplies Installation Guide Models Include: • R615DC8UL • R615DC8ULCB - 6-15VDC @ 4 amp. - 6-15VDC @ 4 amp. - Eight (8) Fuse Protected - Eight (8) PTC Protected Outputs. Outputs. • R615DC416UL •... -
Page 2: Specifications
(blown fuse or tripped PTC), the corresponding LED will not be illuminated (Fig. 1, pg. 3). a. Blown fuse (R615DC416UL, R615DC616UL & R615DC8UL) - Set power switch on the back of unit to the OFF position (Fig. 1e, pg. 3). Remove front faceplate to access fuses. Replace with fuses rated @ 3.5A/250VA (Altronix model # Fuse1). - Page 3 Earth GND) LED's LED's LED's LED's Used on PTC Models PTC1 + AC -- + DC -- ALTRONIX CORP. BKLYN, NY 11220 MADE IN U.S.A. XFMR XFMR Power Supply Board Trimpot ALTRONIX CORP. BROOKLYN, NY 11220 MADE IN USA Removable Terminal...
- Page 4 486mm 0.75" 19.05mm Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. MEMBER IIR615DCUL Series J15M - 4 - R615DCUL Series...
