SleepSafer Hi Lo
Thank you for purchasing the SleepSafer Hi Lo Safety Bed. With proper care, your bed will
provide years of safe use. We strongly recommend that this bed be assembled using two
people. Everything necessary to assemble your bed is included in a special box marked
"Additional Parts Inside" which is located in the box containing the headboard and footboard.
Carefully unpack the contents of your bed and verify that all parts are included using the dia-
gram and chart below. Be sure to save two of the foam shipping blocks used to
package the electric frame. They will be needed to aid in assembly of your bed.
Parts List
Item Qty
1
1
Electric Frame Assembly
2
1
Headboard Assembly
3
1
Footboard Assembly
4
1
Front Panel
5
1
Back Bottom Panel
6
1
Back Top Panel
7
2
Alignment Pins
8
2
Safety Rails
9
4
Casters
10
16
90mm Allen Bolts
11
8
1" Hex Bolts
12
4
Foam Shipping Block
13
1
4mm Allen Wrench
14
1
1/4" Allen Wrench
15
1
#15 Torx Wrench
16
1
#10 Torx Wrench
17
16
Extra Barrel Nuts
Note: For clarity, all diagrams shown in these instructions show decking removed from
PLEASE CHECK ALL BOXES FOR HARDWARE BEFORE DISCARDING
DO NOT DISCARD FOAM BLOCKS WHICH ARE REQUIRED FOR ASSEMBLY
Warranty AND USER INFORMATION CAN BE FOUND AT THE END OF THESE INSTRUCTIONS
Assembly Instructions
Description
(High Bed)
electric frames.
3135 Dillons Mill Road • Callaway, VA 24067
Toll Free • 866.852.2337 Fax • 540.334.2100
www.sleepsafebed.com
12
Advertisement
Table of Contents
Related Manuals for SleepSafe Beds SleepSafer Hi Lo
Summary of Contents for SleepSafe Beds SleepSafer Hi Lo
- Page 1 Toll Free • 866.852.2337 Fax • 540.334.2100 www.sleepsafebed.com Thank you for purchasing the SleepSafer Hi Lo Safety Bed. With proper care, your bed will provide years of safe use. We strongly recommend that this bed be assembled using two people. Everything necessary to assemble your bed is included in a special box marked “Additional Parts Inside”...
- Page 2 SleepSafer Hi Lo Assembly Instructions Continued... STEP 1 Set electric frame (#1) upright with foam spacer blocks (#12) underneath each cor- ner of the mounting brackets as shown. Using the 8 silver hex bolts (#11), attach front panel (#4) and back panel (#5) to brackets on frame.
- Page 3 SleepSafer Hi Lo Assembly Instructions Continued... STEP 3 Install the safety rails (#9) by inserting the black hex bolt pivot pins into the lower plastic strikes installed on each leg as indicated by “A” in the diagram. The rails can then be tilted up into the locked position.
- Page 4 SleepSafer Hi Lo Assembly Instructions Continued... SAFETY RAIL ADJUSTMENT Each safety rail is pre-adjusted at our factory, but it may become necessary to adjust the safety rail height over time to provide the best performance. To determine if your safety rails...
- Page 5 SleepSafer Hi Lo (High Bed) Use & Care Guide Operation Plug in your new electric frame into a standard wall outlet. electric frame is operated using a corded handset. Fig. 1 at right shows the basic operation of all functions on your handset. You’ll note also that a lockout key is pro- vided (attached to the cord).
- Page 6 SleepSafer Hi Lo (High Bed) Warranty Information 3135 Dillons Mill Road • Callaway, VA 24067 Toll Free • 866.852.2337 Fax • 540.334.2100 www.sleepsafebed.com Attention Safety rails are intended to hinder or discourage the possibility of roll-out. This product does not take the place of proper client supervision and monitoring.
