APPENDIX B: ASYNCHRONOUS PORT
CONNECTIONS (CONFIGURED AS "DCE")
Pin Name Description
1 FG
2 TXD
3 RXD
4 RTS
5 CTS
6 DSR
7 SG
8 CD
9 +DCV
10 -DCV
20 DTR
22 Rl
8
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
Frame Ground; connected straight to synchronous port
Transmit Data (to 2010); data input from asynchronous
port; input to the 2010 power supply
Receive Data (from 2010); data output to asynchronous
port
Request to Send (to 2010); input to the 2010 power
supply
Clear to Send (from 2010); connected straight through to
synchronous port
Data Set Ready (from 2010); connected straight through
to synchronous port
Signal Ground; connected straight through to
synchronous port
Carrier Detect (from 2010); connected straight through to
synchronous port
Connected straight through to synchronous port
Connected straight through to synchronous port
Data Terminal Ready (to 2010); input to 2010 power
supply
Ring Indicator (from 2010); connected straight through to
synchronous port
