Danfoss FC 301 Operating Manual page 53

Specifications
8.7.2 UL Compliance
200–240 V
Power [kW Bussmann
(hp)]
Type RK1 1)
0.25–0.37 KTN-R-05
(0.34–0.5)
0.55–1.1 KTN-R-10
(0.75–1.5)
1.5 (2.0) KTN-R-15
2.2 (3.0) KTN-R-20
3.0 (4.0) KTN-R-25
3.7 (5.0) KTN-R-30
5.5 (7.5) KTN-R-50
7.5 (10.0) KTN-R-60
11.0 (15.0) KTN-R-80
15–18.5 KTN-R-125
(20.0–25.0)
22.0 (30.0) KTN-R-150
30.0 (40.0) KTN-R-200
37.0 (50.0) KTN-R-250
Table 8.17 200–240 V, Enclosure Sizes A, B, and C
Power [kW
SIBA
(hp)]
Type RK1
0.25–0.37 5017906-005
(0.34–0.5)
0.55–1.1 5017906-010
(0.75–1.5)
1.5 (2.0) 5017906-016
2.2 (3.0) 5017906-020
3.0 (4.0) 5017906-025
3.7 (5.0) 5012406-032
5.5 (7.5) 5014006-050
7.5 (10.0) 5014006-063
11.0 (15.0) 5014006-080
15–18.5 2028220-125
(20.0–25.0)
22.0 (30.0) 2028220-150
30.0 (40.0) 2028220-200
37.0 (50.0) 2028220-250
Table 8.18 200–240 V, Enclosure Sizes A, B, and C
1) KTS fuses from Bussmann may substitute KTN for 240 V frequency
converters.
2) FWH fuses from Bussmann may substitute FWX for 240 V
frequency converters.
3) A6KR fuses from Ferraz Shawmut may substitute A2KR for 240 V
frequency converters.
MG33AT02
Operating Guide
Recommended maximum fuse
Bussmann Bussmann
Type J Type T
JKS-05 JJN-05
JKS-10 JJN-10
JKS-15 JJN-15
JKS-20 JJN-20
JKS-25 JJN-25
JKS-30 JJN-30
KS-50 JJN-50
JKS-60 JJN-60
JKS-80 JJN-80
JKS-125 JJN-125
JKS-150 JJN-150
JKS-200 JJN-200
JKS-250 JJN-250
Recommended maximum fuse
Ferraz-
Littelfuse
Shawmut
Shawmut
Type RK1
Type CC
Type RK1
KLN-R-05 ATM-R-05 A2K-05-R
KLN-R-10 ATM-R-10 A2K-10-R
KLN-R-15 ATM-R-15 A2K-15-R
KLN-R-20 ATM-R-20 A2K-20-R
KLN-R-25 ATM-R-25 A2K-25-R
KLN-R-30 ATM-R-30 A2K-30-R
KLN-R-50 – A2K-50-R
KLN-R-60 – A2K-60-R
KLN-R-80 – A2K-80-R
KLN-R-125 – A2K-125-R
KLN-R-150 – A2K-150-R
KLN-R-200 – A2K-200-R
KLN-R-250 – A2K-250-R
Danfoss A/S © 05/2018 All rights reserved.
Bussmann
Type CC
FNQ-R-5
FNQ-R-10
FNQ-R-15
FNQ-R-20
FNQ-R-25
FNQ-R-30
–
–
–
–
–
–
–
Ferraz-
Bussmann
Littelfuse
2) JFHR2
Type JFHR2
3)
FWX-5
FWX-10
FWX-15
FWX-20
FWX-25
FWX-30
FWX-50
FWX-60
FWX-80
FWX-125
FWX-150 L25S-150
FWX-200 L25S-200
FWX-250 L25S-250
4) A50X fuses from Ferraz Shawmut may substitute A25X for 240 V
frequency converters.
Bussmann Bussmann
Type CC Type CC
KTK-R-5 LP-CC-5
KTK-R-10 LP-CC-10
KTK-R-15 LP-CC-15
KTK-R-20 LP-CC-20
KTK-R-25 LP-CC-25
KTK-R-30 LP-CC-30
– –
– –
– –
– –
– –
– –
– –
Ferraz-
Ferraz-
Shawmut
Shawmut
4) J
JFHR2
– – HSJ-6
– – HSJ-10
– – HSJ-15
– – HSJ-20
– – HSJ-25
– – HSJ-30
– – HSJ-50
– – HSJ-60
– – HSJ-80
– – HSJ-125
A25X-150 HSJ-150
A25X-200 HSJ-200
A25X-250 HSJ-250
8 8
51
