8.1.3 Mains Supply 525–600 V (FC 302 only)
Type designation
Typical shaft output [kW/(hp)]
Enclosure protection rating IP20, IP21
Enclosure protection rating IP55
Output current
Continuous (525–550 V) [A]
Intermittent (525–550 V) [A]
Continuous (551–600 V) [A]
Intermittent (551–600 V) [A]
Continuous kVA (525 V) [kVA]
Continuous kVA (575 V) [kVA]
Maximum input current
Continuous (525–600 V) [A]
Intermittent (525–600 V) [A]
Additional specifications
2),5)
Maximum cable cross-section
motor, brake, and load sharing [mm
Maximum cable cross-section 2),5)
2
[mm ] ([AWG])
Estimated power loss at rated maximum load
3)
[W]
Efficiency 4)
Table 8.7 Mains Supply 525–600 V (FC 302 only), PK75–P7K5
MG33AT02
Operating Guide
PK75 P1K1
0.75 (1) 1.1 (1.5)
A3 A3
A5 A5
1.8 2.6
2.9 4.2
1.7 2.4
2.7 3.8
1.7 2.5
1.7 2.4
1.7 2.4
2.7 3.8
for mains,
2
] ([AWG])
for disconnect
35 50
0.97 0.97
Danfoss A/S © 05/2018 All rights reserved.
P1K5 P2K2 P3K0
1.5 (2.0) 2.2 (3.0) 3 (4.0)
A3 A3 A3
A5 A5 A5
2.9 4.1 5.2
4.6 6.6 8.3
2.7 3.9 4.9
4.3 6.2 7.8
2.8 3.9 5.0
2.7 3.9 4.9
2.7 4.1 5.2
4.3 6.6 8.3
4, 4, 4 (12,12,12)
(minimum 0.2 (24))
6, 4, 4 (10,12,12)
65 92 122
0.97 0.97 0.97
P4K0 P5K5 P7K5
4 (5.0) 5.5 (7.5) 7.5 (10)
A3 A3 A3
A5 A5 A5
6.4 9.5 11.5
10.2 15.2 18.4
6.1 9.0 11.0
9.8 14.4 17.6
6.1 9.0 11.0
6.1 9.0 11.0
5.8 8.6 10.4
9.3 13.8 16.6
145 195 261
0.97 0.97 0.97
37
8 8
