- Page 1 COH-TX2 & COH-RX2 4k x 2k HDMI to Optical Transmitter and Receiver Operation Manual Operation Manual...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ..........1 3. Package Contents ........1 4. System Requirements ......... 1 5. Features ............1 6. Operation Controls and Functions .... 2 6.1 Transmitter Front and Rear Panels ..2 6.2 Receiver Front and Rear Panels ..3 7. -
Page 6: Introduction
1. INTRODUCTION Many consumers have been searching for a way to transmit HDMI signals over very long distances. The 4k x 2k HDMI to Optical Transmitter and Receiver set which uses fiber optical cables will give you longer transmission distances (up to 300m) while also providing you with thinner, lighter cables for easier installation. -
Page 7: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter Front and Rear Panels OPTICAL LINK HDMI IN POWER DC 5V HDMI OPTICAL LINK 1 2 3 POWER LED: When connect the power adaptor to the AC wall outlet, the LED will illuminate. OPTICAL LINK LED: The LED will illuminate when the optical cable is connected and has successfully detected and communicated data between the... -
Page 8: Receiver Front And Rear Panels
6.2 Receiver Front and Rear Panels OPTICAL LINK HDMI OUT POWER DC 5V HDMI OPTICAL LINK 1 2 3 POWER LED: When connect the power adaptor to the AC wall outlet, the LED will illuminate. OPTICAL LINK LED: The LED will illuminate when the optical cable is connected and has successfully detected and communicated data between the Transmitter and Receiver. -
Page 9: Specifications
7. SPECIFICATIONS Optical Fiber OM3 50/125um, SC-SC connector Transmitter Input Port 1 x HDMI Output Port 1 x Multi-mode Fiber Optical Receiver Input Port 1 x Multi-mode Fiber Optical Output port 1 x HDMI Resolution Supports VGA ~ WUXGA, 3D & 4k x 2k Optical In/Out Cable Up to 300 Meters with OM3 50/125um Distance... -
Page 10: Connection And Installation
8. CONNECTION AND INSTALLATION DVD or Blu-ray Player IR Blaster HDMI OPTICAL LINK HDMI INPUT Power POWER HDMI Supply LINK DC 5V OPTICAL Fibre Optical Cable Power Supply DC 5V OPTICAL OPTICAL LINK HDMI OUT POWER HDMI LINK HDMI Display... -
Page 11: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM CAT5e Category 5 Cable CAT6 Category 6 Cable Consumer Electronics Control Digital Visual Interface HDCP High-bandwidth Digital Content Protection HDMI High-Definition multimedia Interface Infrared... - Page 12 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-COHTX2RX2...
