Summary of Contents for CYP CH-306TXA & RXA
- Page 1 CH-306TXA & RXA Multi-functioning HDMI/USB/RS-232 & IR over single CAT5e/6 Transmitter and Receiver Extender Box Operations Manual Operations Manual...
- Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
CONTENTS 1. INTRODUCTION ..........1 2. APPLICATIONS ..........1 3. PACKAGE CONTENTS ........2 4. SYSTEM REQUIREMENTS ......... 2 5. FEATURES ............2 6. SPECIFICATIONS ..........3 7. OPERATION CONTROLS AND FUNCTIONS ... 4 7.1 Transmitter’s Front Panel ......4 7.2 Transmitter’s Rear Panel ...... -
Page 5: Introduction
1. INTRODUCTION With HDMI & USB over CAT5e/6 connectivity are becoming popular nowadays. The growing need for their flexibility has likewise risen in demand. The HDMI & USB over a CAT5e/6 transmitter and receiver box solution is developed for any household and/or commercial environment. -
Page 6: Package Contents
3. PACKAGE CONTENTS • HDMI & USB over single CAT5e/6 Transmitter • HDMI & USB over single CAT5e/6 Receiver • 5V / 2.6A DC power supply x 1 • 5V / 3A DC power supply x 1 • IR Blaster x 2 •... -
Page 7: Specifications
6. SPECIFICATIONS Transmitter Input Port 1 x USB (B type) 1 x HDMI 1 x RS-232 1 x 3.5Ø Audio Jack Output Port 1 x RJ45 1 x DVI-I 1 x 3.5Ø Audio Jack 1 x IR Blaster Receiver Input Port 1 x RJ45 1 x 3.5Ø... -
Page 8: Operation Controls And Functions
7. OPERATION CONTROLS AND FUNCTIONS 7.1 Transmitter’s Front Panel LINK POWER RS232 IN BLASTER PAIR SEL LINK HDMI / USB / IR / RS232 TO CAT5e/6 TRANSMITTER USB LED This LED will illuminate when the transmitter has linked with receiver's USB signal. User are only able to control the USB in (the source device) when this LED is not illuminated. -
Page 9: Transmitter's Rear Panel
7.2 Transmitter’s Rear Panel HDMI IN DVI OUT AUDIO USB IN DC 5V CAT5e/6 CAT5e/6 OUT This slot is to connect with CAT5e/6 cable with receiver side’s CAT5e/6 input. HDMI IN This slot is to connect with input source such as DVD or Blu-Ray player with connection cable. -
Page 10: Receiver's Front Panel
7.3 Receiver’s Front Panel LINK POWER RS232 OUT BLASTER PAIR SEL LINK CAT5e/6 TO HDMI / VGA / USB / IR / RS232 RECEIVER USB LED This LED will illuminate when the transmitter has linked with receiver's USB signal. User are only able to control the USB in (the source device) when this LED is not illuminated. -
Page 11: Receiver's Rear Panel
7.4 Receiver’s Rear Panel VIDEO HDMI OUT VGA OUT AUDIO DC 5V MODE LINK CAT5e/6 CAT5e/6 IN This slot is to connect with CAT5e/6 cable with transmitter side’s CAT5e/6 output. VIDEO MODE USB LINK HDMI OUT This slot is to connect with output display such as HD TV or monitor with connection cable. -
Page 12: D-Sub 9 Pin Definitions
8. D-SUB 9 PIN DEFINITIONS Define * RS-232 transmission format: Baud Rate: 115200bps Data Bit: 8 bits Parity: None Stop Bit: 1 bit Flow Control: None... -
Page 13: Connection Diagram
9. CONNECTION AND INSTALLATION HDMI IN DVI OUT AUDIO USB IN DC 5V CAT5e/6 Transmitter's Rear Panel Notebook Notebook Blu-ray IP Router VIDEO HDMI OUT VGA OUT AUDIO DC 5V MODE LINK CAT5e/6 Receiver's Rear Panel Microphone Active TV/Monitor Speaker LINK POWER RS232 OUT... -
Page 14: Acronyms
10. ACRONYMS ACRONYM COMPLETE TERM CAT6 Catergory 6 Cable HDCP High-bandwidth Digital Content Protection HDMI High-Definition Television Universal Serial Bus... - Page 16 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw...
