If the Trouble Doesn't Clear

Overview

Normally, trouble points do not require acknowledgment of the cleared condition. If the system does
not clear, read the display. If the source of the trouble cannot be located, call a SimplexGrinnell
branch office to repair the system.

System Reset Key

Some troubles latch until they are reset manually, or are reset by pressing the SYSTEM RESET key.
Try pressing the SYSTEM RESET key if the trouble is any one of the following:
•
•
•
If pressing the SYSTEM RESET key does not clear the trouble, or if the trouble toggles (clears and
then reappears), you may choose to either disconnect the device or to disable the point, using the
procedure outlined in the next section.
Disabling a Point Keep the following in mind when disabling points:
with a Trouble
•
Condition
•
1.
2.
3.
Note:
Style D initiating device circuit trouble.
City Circuit trouble.
24 Point I/O trouble.
Disabling a point causes the point to NOT report alarm conditions or other status changes. A
point should not be disabled unless it is clearly understood that fire detection or security for the
area of the building covered by that point would be lost. Appropriate steps must be taken to
provide alternate means of protecting the area of the building covered by the disabled point.
Repair or replace the failed device or circuit as soon as possible. Once repaired, the disabled
point should be enabled as soon as possible.
Press the TROUBLE ACK key to display the point's information on the alphanumeric display.
For example:
Press the Disable key. The alphanumeric display shows the following message.
SECOND FLOOR EAST WING
PULL STATION
Press the ENTER key. The alphanumeric display shows the action taken.
The system indicates a trouble condition each time a point is disabled. It is important to repair
the disabled point as soon as possible. Once repaired, the disabled point should be enabled
as soon as possible. See the procedure in "Enabling and Disabling Points" in Chapter 6 of
this manual.
DISABLED TROUBLE
3-6
ROOM 16
