1394 Dual-Port Bay Hub
Quick Installation Guide
Introducing the 1394 Dual-Port Bay Hub
The 1394 Dual-Port Bay Hub is designed to support 1394
equipped PC computers. This 1394 hub expands 1394
connectivity to your computer.
Features and Benefits
•
Unique drive bay design adds ports to the front of
your computer for convenient device connection
•
Fits into either 3.5" or 5.25" (with included mounting
rack) drive bay
•
IEEE 1394-1995, P1394a (rev. 1.1) and OHCI
Interface specification 1.0 compliant
•
Supports serial bus data transfer rates of 100, 200,
and 400 Mbps
•
Provides one 6-Pin and one 4-Pin 1394 ports for
easy device connections
•
Hot-swapping feature allows you to connect/
disconnect devices without first turning your
system off
•
Works with various types of 1394 devices including
DV camcorders/cameras, hard disk drives, CD-
RWs, DVD-ROMs, removable drives, scanners,
and other audio/video devices
System Requirements
•
PC computer with one available 1394 port
•
One available 3.5" or 5.25" drive bay
•
Windows 98SE/ME/2000/XP/Server 2003
04-0253B
1
Advertisement
Table of Contents
Related Manuals for SIIG 1394
Summary of Contents for SIIG 1394
- Page 1 1394 Dual-Port Bay Hub Quick Installation Guide Introducing the 1394 Dual-Port Bay Hub The 1394 Dual-Port Bay Hub is designed to support 1394 equipped PC computers. This 1394 hub expands 1394 connectivity to your computer. Features and Benefits • Unique drive bay design adds ports to the front of your computer for convenient device connection •...
- Page 2 (1) 5.25 inch mounting rack • (1) 6-pin to 6-pin 1394 cable • (1) "Y" split power cable • (1) 1394 cable holding bracket (w/rubber holding ring) • (1) Bag assorted mounting screws • This quick installation guide Hub Layout Important: The bay hub is shown in white in this manual.
- Page 3 5.25" drive bay. Figure 2. 5.25" Mounting Rack Assembly Installing the 1394 Dual-Port Bay Hub Important: In order for the 1394 Dual-Port Bay Hub to work properly, the driver of your existing 1394 host adapter must be installed properly.
- Page 4 1394 Dual-Port Hub's power connector. Figure 3. Connecting the Power Cable Connect one end of the 1394 cable into the 1394 internal port on the 1394 Dual-Port Bay Hub. Figure 4. Connecting the 1394 Cable...
- Page 5 1394 cable from the 1394 Dual-Port Bay Hub to the outside 1394 port. Note: If there is an internal 1394 port on your 1394 host adapter, connect the cable to the internal port. The 1394 cable holding bracket is not needed in this case.
- Page 6 Figure 7. Connecting the Power Cable 10. Replace the computer's cover and reconnect the power cord, then turn the system on. 11. When Windows boots up, the 1394 Dual-Port Bay Hub automatically gets detected and installed. The hub is now ready for device connection.
-
Page 7: Technical Support
The 5-year manufacturer warranty supplied with this product is offered by SIIG, Inc. If you should happen to encounter any problems with this product, please follow the procedures below. - Page 8 Fremont, CA 94538-3152 1394 Dual-Port Bay Hub is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in publication are for identification only and may be trademarks of their respective companies.
