Features and Benefits
•
Compliant with USB specifications rev.2.0
•
Works in PC or Mac computer
•
Adds 4 high-speed USB 2.0 downstream
ports to support simultaneous operation
of USB 2.0 and USB 1.1 devices
•
Supports 480, 12, 1.5Mbps data transfer
modes
•
Per port over-current detection and
protection
•
Hot-swapping feature allows you to
attach/detach USB devices without first
powering your computer off
NOTE: USB 1.1 devices are limited to USB
1.1 speeds even when they are connected
to USB 2.0 host adapter or USB 2.0 hubs.
04-0237D
USB 2.0 SlimHub 4000P
Quick Installation Guide
1
Advertisement
Related Manuals for SIIG USB 2.0 SlimHub 4000P
Summary of Contents for SIIG USB 2.0 SlimHub 4000P
- Page 1 USB 2.0 SlimHub 4000P Quick Installation Guide Features and Benefits • Compliant with USB specifications rev.2.0 • Works in PC or Mac computer • Adds 4 high-speed USB 2.0 downstream ports to support simultaneous operation of USB 2.0 and USB 1.1 devices •...
- Page 2 Layout USB 2.0 Ports 1 & 2 Power/Activity LEDs* Figure 1. Front Layout * NOTE: The Power/Activity LEDs will appear in one of three colors. Each color indicates the speed of the attached USB device. When connecting a high speed device (480Mbps) the LED will be Yellow.
- Page 3 USB 2.0 Ports Power Adapter Jack* 3 & 4 Figure 2. Rear Layout * NOTE: In most cases, the power adapter does not need to be plugged in. However, some USB devices may require additional power in order to work. Please plug in the power adapter if your device needs it.
-
Page 4: Installation
• Windows 98SE/ME/2000/XP • Mac OS 8.6 or later Package Contents • (1) USB 2.0 SlimHub 4000P • (1) Switching power adapter • This quick installation guide Installation Important: This hub only operates at USB 2.0 speed when connected to a USB 2.0 controller. - Page 5 In order for the USB 2.0 SlimHub 4000P to work as a USB 2.0 hub, the driver for your existing USB 2.0 host controller has to be properly installed. This hub will automatically be detected and installed when connected to the USB 2.0 port.
- Page 6 Mac OS Installation Boot up Mac OS and insert the hub to a USB port (USB 2.0 recommended). Mac OS will automatically detect and install the correct driver for this hub. The USB hub is now ready for device connection.
-
Page 7: Technical Support
The 5-year manufacturer warranty supplied with this product is offered by SIIG, Inc. If you should happen to encounter any problems with this product, please follow the procedures below. -
Page 8: Fcc Compliance Statement
PRODUCT COMPLIANCE SIIG, Inc. 6078 Stewart Ave. Fremont, CA 94538-3152 USB 2.0 SlimHub 4000P is a trademark of SIIG, Inc. All other names used in this publication are for identification only and may be trademarks of their respective companies. December, 2003...
