OutBack Power GS7048E Operator's Manual page 2

Radian Series
International Specifications
Models
Nominal DC Input Voltage
Continuous Output Power (@ 25°C)
AC Output Voltage (Selectable)
AC Output Frequency (Selectable)
Continuous AC Output Current (@ 25°C)
Idle Consumption (Invert Mode, No Load)
Typical Efficiency
CEC Weighted Efficiency
Total Harmonic Distortion
Output Voltage Regulation
Maximum Output Current
Overload Capacity
AC Input Voltage Range (Adjustable)
AC Input Frequency Range (Default)
Grid-Interactive Voltage Range (Default)
Grid-Interactive Frequency Range
Maximum AC Input Current
Maximum Utility Interactive Current
Continuous Battery Charge Output
DC Input Voltage Range
Temperature Range
Accessory Ports
Non-Volatile Memory
Field Upgradable Firmware
Chassis Type
Certifications
Warranty
Weight (lb/kg)
Dimensions H x W x D (in/cm)
Worldwide Corporate Offices
North America
Tel: +1 360.435.6030
Fax: +1 360.435.6019
GS7048E
48VDC
7000VA
230VAC (210-250VAC)
50Hz (60Hz)
30AAC
34W
92%
—
Max. Total Harmonic: <5%
Max. Single Voltage Harmonic: <2%
±2%
1ms Peak: 100AAC
100ms RMS: 70.7AAC
100ms Surge: 16.3kVA
5 seconds: 11.5kVA
30 minutes: 7.9kVA
(L-N) 170 to 290VAC
45 to 55Hz @ 50Hz (54 to 66Hz @ 60Hz)
(L-N) 208 to 252VAC
57.0 to 61.0Hz
50AAC
30A
100.0ADC
40 to 64VDC
Rated: -20 to 50°C (power derated above 25°C)
Maximum:-40 to 60°C
Remote Temperature Sensor, MATE3 & HUB Communications
Yes
Yes
Vented
IEC 62477-1, AS4777.2, AS477.3, EN61000-6-1, EN61000-6-3, EN61000-3-2, EN61000-3-3,
AS3100, CE, RoHS compliant per directive 2011/65/EU
Standard 5 year
Unit: 125.0 / 56.7
Shipping: 140.0 / 63.5
Unit: 28 x 16 x 8.7 / 71 x 40.6 x 22.1
Shipping: 34.5 x 21 x 14.5 / 87.6 x 53.3 x 36.8
Latin America
Tel: +1 561.792.9651
Fax: +1 561.792.7157
48VDC
3500VA
230VAC (210-250VAC)
50Hz (60Hz)
15.2AAC
34W
92%
—
Max. Total Harmonic: <5%
Max. Single Voltage Harmonic: <2%
±2%
1ms Peak: 50AAC
100ms RMS: 35.35 AAC
100ms Surge: 8.2kVA
5 seconds: 5.8kVA
30 minutes: 4.0kVA
(L-N) 170 to 290VAC
45 to 55Hz @ 50Hz (54 to 66Hz @ 60Hz)
(L-N) 208 to 252VAC
57.0 to 61.0Hz
50AAC
15A
50.0ADC
40 to 64VDC
Rated: -20 to 50°C (power derated above 25°C)
Maximum:-40 to 60°C
Remote Temperature Sensor, MATE3 & HUB Communications
Yes
Yes
Vented
IEC 62109-1, IEC 62477-1, AS4777.2, AS477.3, EN61000-6-1, EN61000-6-3, EN61000-3-2,
EN61000-3-3, AS3100, CE, RoHS compliant per directive 2011/65/EU
Standard 5 year
Unit: 81.0 / 36.7
Shipping: 93.0 / 42.1
Unit: 28 x 16 x 8.7 / 71 x 40.6 x 22.1
Shipping: 34.5 x 21 x 14.5 / 87.6 x 53.3 x 36.8
Europe Asia Pacific
Tel: +49 9122.79889.0 Tel: +852 2736.8663
Fax: +49 9122.79889.21 Fax: +852 2199.7988
06/2014
GS3548E
A v A i l A b l e F r o m
