Connections of the Components in the Drive System

13.1

System Connections of the Components

13.1.1

General Information

In the System Environment
Within the Drive System
Connections of the Components in the Drive System
Electrical connections for operating the drive system Rexroth IndraDrive:
Connection X3 or PE to equipment grounding system
Connection X3 to supply with power voltage
Connection X13 or terminal block 0V / +24V to supply with control volt‐
age
Connection to control unit and/or master communication
Equipment grounding conductor connections PE to X3 or joint bars at
the devices
DC bus connections L+ with bars
DC bus connections L- with bars
Control voltage connections 0V with bars
Control voltage connections +24V with bars
Module bus connections X1 with ribbon cable
Motor power connections via motor power cable at X5
Connections for motor temperature monitoring and motor holding brake
via motor power cable at X6
