CVM-BDM supply network analyzer
-----
The DELAY set value is applied either to the connection or the
disconnection when the alarm conditions occur.
The programming units for the different parameters are:
Parameter
Voltage
Current
Powers
Energies
Power factor
Frequency
Connections of the RELAY OUTPUTS :
a.- CVM-BDM-C2 ( 2 relays ) :
Out1 Terminals
27 - 26
RELAY1
b.- CVM-BDM-C420 ( 1relay ) :
- Maximum voltage between terminals = 250 V a.c.
Format
Without decimals = V
With decimals = kV (xxx.x)
A
kW, kvar, kVA
kW.h, kvar.h
x.xx
xx.x
Signal
N.O.
Out2 Terminals
RELAY1 25 - 24
--------
(xxxx) 0220 = 220 V
25.30 = 25.30 kV
0150 = 150 A
0.540 = 540 W
250.5 = 250.5 kW
- 0.7 = - 0.70
50.0 = 50 Hz
Out2 Terminals
25- 24
RELAY2
Signal
N.O.
--- Page Nº 35
Example
Signal
N.O.
