Vicon V900-358-24C Installation & Operation Manual

Roughneck v900 series impact-resistant dome cameras

Advertisement

Quick Links

X986
V900 IMPACT-RESISTANT
DOME CAMERAS
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet
your requirements or that the operation will be entirely error free or perform precisely as
described in the documentation. This system has not been designed to be used in life-critical
situations and must not be used for this purpose.
Copyright © 2001 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon part number 8006-8986-03-02
Rev 1001 Section 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V900-358-24C and is the answer not in the manual?

Questions and answers

Summary of Contents for Vicon V900-358-24C

  • Page 1 V900 IMPACT-RESISTANT DOME CAMERAS Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
  • Page 3: Table Of Contents

    Contents Contents ..........................i Quick Installation........................ ii Introduction......................... 1 Installation .......................... 2 Unpacking and Inspection ..........................2 Inspection for Visible Damage........................2 Inspection for Concealed Damage....................... 2 Roughneck V900 Dome Components......................2 Mounting the Unit ............................3 Cable Connections ............................4 Coaxial Video Cable .............................
  • Page 4: Quick Installation

    Quick Installation For experienced installers, use the installation diagram below, Figure 1A for indoor versions and Figure 1B for outdoor versions. For complete detailed instructions on how to install the V900, read the Installation section. Figure 1A Installation Diagram Exploded View – Indoor Version ii •...
  • Page 5 Figure 1B Installation Diagram Exploded View – Outdoor Version Quick Installation • • • • iii X986-03-02 Rev 1001 Roughneck V900 Dome Cameras...
  • Page 7: Introduction

    Indoor; 1/3-in. high-resolution monochrome camera and 2.8 mm lens; 24 VAC/VDC. EIA. V900-358HB-24/ 6526-04/6526-03 Indoor; 1/3-in. high-resolution monochrome camera and V900-358-24C 3.5 - 8 mm varifocal lens; 24 VAC/VDC. EIA/CCIR. V900-2.9HC-24 6514-04 Indoor; 1/4-in. high-resolution color camera and 2.9 mm lens;...
  • Page 8: Installation

    Installation Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver the equipment in the same condition as it left the factory. Inspection for Visible Damage Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the carrier’s freight bill.
  • Page 9: Mounting The Unit

    Vicon, part number 8004-9317-01. Screw the adapter clockwise into the fitting and tighten with a wrench. Vicon recommends the use of Teflon tape, wrapped clockwise around the threads of the adapter, to ensure a snug fit. Refer to Figure 3 for installation options.
  • Page 10: Cable Connections

    Note: To assure a watertight seal, apply silicone sealant around the area where the base meets the wall or ceiling. Figure 2 Mounting Hole Pattern Figure 3 Installation of NPT Adapter Cable Connections Both power and video connections are made to the printed circuit board (PC board) mounted to the camera mounting plate.
  • Page 11: Coaxial Video Cable

    Coaxial Video Cable Some Roughneck V900 offers two options for connecting video cables to the camera. The first method is to attach a customer-supplied male BNC connector to the video cable and then connect it to the mating BNC connector on the pendant cable on the PC board. As an alternative, there is a special video connector on the PC board.
  • Page 12: Camera Power Connections

    Cable Preparation Camera Power Connections Note: Vicon systems and components, like most electronic equipment, require a clean, stable power source. Voltage irregularities such as surges, drops, and interruptions can affect the operation of your equipment and, in severe cases, damage certain components. Vicon strongly recommends the use of line conditioners, voltage regulators, and uninterruptible power supply (UPS) systems.
  • Page 13: Heater Connections

    Power is connected through a three-position screw terminal connector on the PC board (P3). Refer to Table 2 for the input power connections. 1. Locate the power cable screw terminal on the PC board. 2. Strip approximately 1 in. (25 mm) of insulation off power cables. Then strip off approximately 0.25 in. (6 mm) of insulation off each individual wire.
  • Page 14: Camera Adjustments

    Camera Adjustments The lens can be manually adjusted for iris, focus and angle of view. On the lens, focus (near to infinity) is the front ring, the telephoto/wide adjustment is the middle ring and iris (open and close) is the end ring. On autoiris lenses, iris adjustment may be required if the picture appears dark or grainy or has poor color.
  • Page 15: Final Installation

    Figure 7 Accessing the DIP Switch Figure 8 Switch Settings Final Installation After all cable connections are made, test the camera/lens to see if any further adjustments are necessary. When the camera and lens adjustments are complete, replace the foam mask over the camera/lens assembly (if necessary).
  • Page 16 Any alignment of holes and screws is acceptable. The cover can be rotated 90° by aligning the screws/holes differently. Caution: For moisture protection, Vicon recommends that when the cover is reattached, it compress the gasket to a thickness of approximately 1/16 in. (1.6 mm).
  • Page 17: Operation

    Operation When power is applied to the camera, the Roughneck V900 views the selected scene. Maintenance The Roughneck V900 Impact-Resistant Cameras require no scheduled maintenance except for the occasional cleaning of the lower dome. Care and Cleaning of Lower Dome The inside surface of the smoked (gray-tinted) dome is easily scratched.
  • Page 18: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.
  • Page 19: Reference

    Caution: Careful selection of the proper cable is essential to obtain the best performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended are installed. In all cases, coaxial cable impedance should be 75 ohms.
  • Page 21: Technical Information

    Technical Information ELECTRICAL Input Voltage: 14 to 25 VAC (24 VAC nominal), nonisolated. 17 to 34 VDC (24 VDC nominal), nonisolated. Power Consumption: 13 W without heaters. 30 W with heaters. Current Rating: 0.9 A without heaters. 1.25 A with heaters. Maximum Operating Distance: Without Heaters...
  • Page 22 Specifications: Refer to Table 3. OPERATIONAL Tilt and Horizontal Adjustment: 2 axis adjustment, pan and tilt. MECHANICAL Application: Indoor and outdoor models. Mounting: Ceiling or wall. Dimensions: Height: 4.8 in. (122 mm). Total Diameter: 6.12 in. (155 mm). Dome Diameter: 3.5. in. (89 mm). Weight: Approximately 4 lb (1.8 kg).
