CTI-100 Solar Panel Specs
Rated power (Pm)
Maximum power voltage (Vmp)
Maximum power current (Imp)
Open circuit voltage (Voc)
Short circuit current (Isc)
GP-PV-170M Solar Panel Specs
Rated power (Pm)
Maximum power voltage (Vmp)
Maximum power current (Imp)
Open circuit voltage (Voc)
Short circuit current (Isc)
GP-PWM-30 Specs (Detailed specs available in the manual)
Maximum Output Current
Maximum Solar Panel Wattage at STC
Maximum PV Open Circuit Voltage (Voc)
30A ATO Blade Fuse
Max DC Voltage
Trip Amps
Polarized
[page 18] | gpelectric.com

6. SPECIFICATIONS

100W
18.4V
5.43A
22.6V
5.75A
170W
19.35V
8.8A
22.78V
9.32A
30A at 104˚F (40˚C)
488W at 12V
28VDC absolute maximum at coldest conditions
32VDC
40.5A
No
