C8051F96x/Si102x
5. UDP C8051F960/Si1020 MCU Card with EMIF Overview
The C8051F96x MCU card enables application development on the C8051F960 MCU. The card connects to the
MCU Card expansion slot on the UDP motherboard and provides complete access to the MCU resources. Each
expansion board has a unique ID that can be read out of an EEPROM or MCU on the board, which enables
software tools to recognize the connected hardware and automatically select the appropriate firmware image. The
target MCU card can also be detached from the UDP and used alone as a development or demonstration tool.
Figure 9 shows the C8051F96x MCU card.
Figure 9. C8051F96x UDP MCU Card
Figure 10 highlights some of the features of the UDP C8051F960/Si1020 MCU Card with EMIF.
