1 Quick Start

Assemble the MCU board, Powertrain board, motor mount board and motor as shown in the photo below.
Figure 1
BLDC Kit Setup
Connect the motor wiring as shown in the photo – incorrect connection can cause the motor to spin opposite of the
intended direction. Users can select one of two options of powering up the kit. Verify that the jumpers are installed
as shown in the photo below:
Figure 2
MCU Board with default jumper setting
Rev 0.2
