INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Reverse Osmosis System
Models: RO-TFM-4SV-W50
!
WARNING
Read this Manual BEFORE using this equip-
ment.
Failure to read and follow all safety and use
information can result in death, serious per-
sonal injury, property damage, or damage to
the equipment.
Keep this Manual for future reference.
!
WARNING
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
WARNING
!
Discard small parts remaining after the installation.
NOTICE
If you are unsure about installing this product, consult a
professional plumber or call a WATTS representative.
Failure to follow instructions and install correctly may result
in leaks, property damage and/or product not performing
correctly, and voids warranty.
Handle all system parts and components carefully. Do not
drop, drag, or turn components upside down.
Be sure floor under the system is clean, level and strong
enough to support the unit, and that the Module is mounted
to a surface strong enough to support its weight.
System Tested and certified by WQA
against NSF/ANSI Standard 58 for the
reduction of the claims specified on the
performance data sheet and NSF/ANSI
Standard 372 for lead free.
Refer to enclosed warranty for operating parameters to ensure proper use with your water supply.
Watts Premier
www.premierh2o.com
199348
RO-TFM-5SV-W50
8716 W. Ludlow Drive Suite #1
Peoria, AZ 85381
USA: Tel. (800) 752-5582
Canada: Tel. (905) 332-4090
Manual Edition: 08/08/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RO-TFM-4SV-W50 and is the answer not in the manual?

Questions and answers

Summary of Contents for Premier RO-TFM-4SV-W50

  • Page 1 INSTALLATION, OPERATION AND MAINTENANCE MANUAL Reverse Osmosis System Models: RO-TFM-4SV-W50 RO-TFM-5SV-W50 WARNING Read this Manual BEFORE using this equip- ment. Failure to read and follow all safety and use information can result in death, serious per- sonal injury, property damage, or damage to the equipment.
  • Page 2: Overview

    Overview Thank you for your purchase of the Premier Reverse Osmosis (RO) water treatment system. This Premier water treatment system has been designed and tested to provide you with high quality drinking water when installed, maintained and used in accordance with the instructions in this Manual, and any requirements of local, state and federal law.
  • Page 3: Table Of Contents

    Table of Contents Overview ..........................................1 Before Installation Operational Parameters ......................................3 Contents of Under Counter Filter ....................................3 System Diagram ........................................4 Tools Recommended For Installation ..................................6 Using Quick-Connect Fittings ....................................6 Installation Step 1. Adapt-A-Valve Installation ..................................7 Step 2. Drill a Hole for the Faucet in a Sink ................................8 Step 3.
  • Page 4: Operational Parameters

    Premier supplies speciality filters that can be used if copper tubing follows the Reverse Osmosis unit. Be sure to follow any state or local regulations during installation.
  • Page 5: System Diagram

    System Diagram AIR-GAP FAUCET 303-STYLE OPTION AIR-GAP FAUCET OPTION RED - 1/4” 3/8” TUBE - BRINE BLACK - 3/8” DRAIN TUBE - DRAIN SADDLE BLACK - 3/8” TUBE - DRAIN GAC FINAL INLINE FILTER FLOW MEMBRANE HOUSING FLOW RESTRICTOR AUTO SHUT-OFF VALVE (IN RED TUBE) TANK VALVE...
  • Page 6 Part # Description 560010 GAC In-Line Filter - 10” (1/4” FPT) 1 ALT 560005 GAC In-Line Filter - 6” (1/4 FPT) 104017 Sediment Filter - 10” (5 micron) 101009 Carbon Block Filter- 10” (5 micron) 560018 50 GPD Reverse Osmosis Membrane 500017 Housing - White - (1/4”...
  • Page 7: Tools Recommended For Installation

    Tools Recommended For Installation Power Tools: Wrenches: Electric Drill 1 1/4” Adjustable Wrench ‰ ‰ 1/2” Open End Wrench ‰ Drill/Driver Bits ‰ 5/8” Open End Wrench Phillips Driver Bit ‰ 1/8” Diamond-tip Drill Bit (for pilot hole) Other Tools: ‰...
  • Page 8: Installation

    Step 1. Adapt-A-Valve Installation Water supply line to the system must be from the cold water supply line only. Hot water will NOTICE severely damage your system. Do not use Teflon tape with the Adapt-A-Valve™. NOTICE Faucet Line Faucet Connection Faucet Line Faucet Connection...
  • Page 9: Step 2. Drill A Hole For The Faucet In A Sink

    Step 2. Drill a Hole for the Faucet in a Sink Note: Some sinks have predrilled 1 ¼” or 1 ½” holes that are suitable for installation of your Drinking Water faucet. If so, please Skip to step Step 3. Drilling a hole in a sink or countertop for faucet installation is entirely out of the control of Watts.
  • Page 10: Step 3A. Standard Faucet Installation

    Step 3A. Standard Faucet Installation NOTE: A 1” to 1-1/4” mounting hole is required for the faucet installation Parts List for Faucet Item Description Escutcheon Plate & Rubber Washer Slotted Metal Washer Spacer Lock Washer Plain Washer Locking Nut Tube Insert Delrin Sleeve Compression Nut Blue 1/4”...
  • Page 11: Step 3B. Watts Top Mount Faucet Installation

    Step 3B. Watts Top Mount Faucet Installation This RO faucet is equipped with quick connect fittings for easy tube installation. To connect tubes, simply push them firmly into their corresponding fitting on the RO faucet until fully seated. NOTE: A 1” to 1-1/4” mounting hole is required for the faucet installation Step 3B-1: During shipping/handling the toggle bolt on your new faucet...
  • Page 12: Step 4. Blue Tube To In-Line Gac Filter

    Step 4. Blue Tube to In-line GAC Filter Step A: Insert the open end of the blue tube from the faucet into the fitting at the end of the GAC In-line Filter. Use a 5/8” wrench to tighten the white plastic nut securely.
  • Page 13: Step 7. Drain Saddle Installation

    The drain connection can instead be made at the dishwasher inlet port of the garbage disposal using a Garbage Disposal Drain Line Adapter which is available for purchase from Watts Premier (PN# 164020).
  • Page 14: Step 8. Red Tube Connection

    A connection from the RO to the refrigerator / ice maker system must have an in-line valve NOTICE installed in-between so it can easily be closed to prevent water flowing to the ice maker during start up and periodic maintenance. An Ice maker Connection Kit can be purchased through Premier Operation Page 13...
  • Page 15: Startup

    Startup If your RO system is connected to a refrigerator / ice maker, you must turn off the connection to NOTICE that appliance during the system startup. Do not re-open the connection until after the system has been completely flushed (as described below) and the tank is allowed to fill up completely in order for the appliance to work properly.
  • Page 16: Maintenance

    Part# 104017 5 micron Carbon Pre-Filter Part# 101009 (2 Needed for 5-Stage Unit) NOTE: A filter housing wrench (part #164002) may be purchased from Premier to aid with filter removal (not required) Step A: Close the tank ball valve. Step B:...
  • Page 17: Annual Maintenance

    Step D: For more leverage you may leave the RO module attached to wall of cabinet. If you are unable to access the module while it is mounted, remove it prior to changing filters. Starting with the First Bowl on the Filter Lid left (Stage 1), remove it by turning it clockwise (left), empty water, then discard filter.
  • Page 18 This reverse osmosis system contains a replaceable component (the RO membrane) which is NOTICE critical to the efficiency of the system. Replacement of this reverse osmosis membrane should be with one of identical specifications as defined by Premier to assure the same efficiency and contaminant reduction performance. Page 17...
  • Page 19: Membrane Replacement

    Premier recommends replacing the membrane when TDS reduction falls below 75%. NOTE: A water sample may be sent to Premier for a free diagnosis of your membrane performance. To send a water sample, use two (2) clean containers and fill ½ cup of tap water in one container and ½...
  • Page 20: Replacing The Faucet Battery

    Replacing the Faucet Battery Step A: Remove the battery tray at the bottom of the faucet. Note: Water may dribble out of the spout, use caution when handling the electronic components. Step B: Slide the old battery out and replace with new battery (“+” Positive Side Up).
  • Page 21: Troubleshooting

    1. Low/Slow Production Low Water pressure Make sure there is at least 40 psi of pressure for the incoming water pressure. Premier sells a booster pump if the home water pressure is low. Make sure water supply is completely opened.
  • Page 22 6. Leak at Fitting Damaged Tube Disconnect the tube (See Section “Using Quick-Connect Fittings” at beginning of manual) then cut about 1” from the tube or replace tube and then re-insert. Damaged Fitting Replace fitting 7. Unpleasant taste from water Tank needs to be sanitized Sanitize your system Bad Automatic Shut-Off (ASO)
  • Page 23: Performance Data Sheet

    58 for Specific Claims and NSF/ANSI Peoria, AZ 85381 Standard 372 for lead free Models: RO-TFM-4SV-W50, RO-TFM-5SV-W50 General Use Conditions 1. System to be used with municipal or well water sources treated and tested on regular basis to insure bacteriological safe quality. Systems certified for cyst reduction may be used on disinfected water that may contain filterable cysts.
  • Page 24: Arsenic Facts

    Influent Max Allowable Challenge Average Effluent Effluent Infl. Challenge concentration (mg/L) (mg/L) Reduction Pressure (mg/L) concentration (mg/L) Selenium 0.10 < 0.001 99.0% 50 psi < 0.001 0.10 ± 10% 0.05 88.0% 5.94 50 psi 750 ± 40mg/L Turbidity 81 NTU 0.15 NTU 99.8% 50 psi...
  • Page 25 arsenic to under 0.010 mg/L (ppm) (the USEPA standard for drinking water). Actual performance of the system may vary depending on specific water quality conditions at the consumer’s installation. In addition to the independent laboratory standard testing conditions we have conducted additional field testing on our reverse osmosis units to determine trivalent arsenic reduction capabilities.
  • Page 26: Service Record

    Service Record Date of Purchase: _______________ Model Number: _______________ Serial Number: _______________ Date of Install: _________________ Installed by: __________________ Date Sediment Carbon Block Carbon Block GAC Final TFM RO (6 Months) (6 Months) (6 Months) Inline Membrane (2-5 (5-Stage Only) Years) Page 25...
  • Page 27: Limited Warranty

    Limited Warranty WHAT YOUR WARRANTY COVERS: Watts Regulator Co. (“WATTS”) warrants its Reverse Osmosis System to be free from defects in workmanship (excluding replaceable filters and membranes), for a period of 1 year from the date of original retail purchase. In the event of such defects, return the unit (less tank) after obtaining a return authorization (see below) within the 1 year warranty period, and Watts will repair or, at Watts’s option, replace the unit at no charge.
