Description
Meter Description
1. LCD display
2. Power and Select button
3. Up arrow
4. Zero Key
5. Micro USB connector
6. Back Key (
7. Down arrow
8. Sensor
Note: Battery compartment on rear of meter
Display Description
1. Data record memory group number
2. Record Number in current memory group
3. Battery status icon
4. Measurement units: µm or mils
5. DEL (Delete): Press the back (
button to delete the previous reading
6. Metal type (FE=ferrous, NFE=non‐ferrous)
7. Automatic (Auto) metal detect mode
)
)
1
2
3
4
7
6
3
5
1 2 3
CG206‐en‐GB_v1.0 6/16
