Extech Instruments CG206 User Manual page 6

WORKING MODE
1. Press the LEFT button (SEL) to access the menu.
2. Scroll to WORKING MODE (if necessary) using up/down buttons.
3. Press the LEFT button (SELECT) to open WORKING MODE.
4. Use the UP and DOWN buttons to scroll through the groups and to see the number of saved
readings in each group. Group 0 does not have memory.
5. Press the LEFT button (SELECT) to select the group and exit Working mode and return to the
main menu or press the RIGHT button (
MEASURE MODE
1. Press the LEFT button (SEL) to access the programming menu
2. Use the UP/DOWN buttons to scroll to the Measure Mode
3. Press the LEFT button (SELECT) to select the Measure Mode
4. Use the UP/DOWN buttons to scroll to Auto, FE, or NFE.
Press the LEFT button (SELECT) to make a selection.
AUTO mode ‐ the meter automatically recognizes the metal that is being measured.
Ferrous (FE) Mode ‐ the Magnetic induction measurement mode is used.
Non‐Ferrous (NFE) Mode ‐ the eddy current measurement mode is used.
5. Press the RIGHT button (
SET
Press the LEFT button (SEL) to access the menu.
1.
Use the UP/DOWN arrows to scroll to SET.
2.
Press the LEFT button (SELECT) to open the SET menu.
3.
Use the UP and DOWN buttons to scroll through the selections.
4.
Press the Left button (SELECT) to open the selected item.
5.
a. Units of measure selections
Select µm or mil using the arrow buttons (µm = micrometers; mils). Press the LEFT
button (SELECT) button to confirm and to return to the SET menu (otherwise press the
right button (
b. Backlight
Use the UP and DOWN arrows to adjust the brightness of the backlight.
Press the RIGHT button (
)
to return to the normal operating mode.
)
to abort the edit and return to the SET menu).
)
to confirm and return to the SET menu.
)
twice to return to the normal operating mode.
6
CG206‐en‐GB_v1.0 6/16
