Alliance Laundry Systems HTEB17-N2802 Service Manual

Alliance Laundry Systems HTEB17-N2802 Service Manual

Commercial stacked washer / dryers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Commercial
Stacked Washer/
Dryers
Refer to Page 3 for Model Numbers
SWD445C
Part No. 801774R2
www.alliancelaundry.com
October 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTEB17-N2802 and is the answer not in the manual?

Questions and answers

Related Manuals for Alliance Laundry Systems HTEB17-N2802

Summary of Contents for Alliance Laundry Systems HTEB17-N2802

  • Page 1 Commercial Stacked Washer/ Dryers Refer to Page 3 for Model Numbers SWD445C Part No. 801774R2 www.alliancelaundry.com October 2015...

  • Page 3: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 4 84. Dryer Inner and Outer Door Panels and Door Pull ..........131 85. Dryer Door Strike ........131 86. Dryer Door Seal ..........132 87. Dryer Front Panel and Panel Seal ....133 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 5: Model Identification

    STEX17*N3300 Electric STEX17*N4064 Electric STEX17*N4350 Electric STEX17*N5754 Electric STEY17*N4064 Electric STEY17*N5754 Electric STGX19*N3000 STGX19*N3060 STGX19*N3069 * Add Letter To Designate Color. W – White Q – Bisque 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 6 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 7: Section 1 - Safety Information

    • Whenever ground wires are removed during servicing, these ground wires must be reconnected to ensure that the machine is properly grounded and to reduce the risk of fire, electric shock, serious injury, or death. W284 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 8: Locating An Authorized Servicer

    Locating an Authorized Servicer Alliance Laundry Systems is not responsible for personal injury or property damage resulting from improper service. Review all service information before beginning repairs. Warranty service must be performed by an authorized technician, using authorized factory parts. If service is required after the warranty expires, Alliance Laundry Systems also recommends contacting an authorized technician and using authorized factory parts.

  • Page 9: Section 2 - Introduction

    Nameplate Location When calling or writing about your product, be sure to mention model and serial numbers. Model and serial numbers are located on nameplate(s) as shown. Nameplate 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 10: How Your Stacked Washer/Dryer Works

    Electronic Mixing Control Valve (Mounted to back side of control panel) Inner Basket Outer Inverter Control (Mounted to base of washer) SWD645N Electric Drain Pump Motor © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 11 If this switch opens during a spin step, the inverter spins. Two of these rinse cycles will normally take control immediately stops and then restarts the place with a third extra rinse cycle being optional. spin. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 12 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 13: Section 3 - Troubleshooting

    Figure 1 for path that coin follows when working properly. Additional coins following path to sensor Coin in Coin Slot Coin Drop Sensor DRY2B Figure 1 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 14: Troubleshooting Coin Drop

    (Residue or Refer to Paragraph 113 lint build-up may prevent for instructions on coins from following through cleaning drop. required check stages of drop.) Replace coin drop. SWD1686S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 15: Washer Motor Circuit

    The knocking sound is made when the flat spot hits the pulley. The knocking may occur during a pulse spin and fade after reaching a higher RPM. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 16 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 17: Dryer

    • Firmly press connection block onto motor switch. Broken, loose, or incorrect wiring. • Refer to wiring diagram. Power cord is miswired. • Refer to wiring diagram for the correct wiring. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 18: Dryer Stops In Cycle; Quits After The First Few Loads; Has A Burning Smell; Cycles On Motor Thermal Protector

    Motor switch functions inoperative. • Refer to Paragraph 115 to check switch and windings. Short in motor winding. Clothes item caught in fan. • Check fan for obstruction. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 19: Dryer Motor Runs But Cylinder Does Not Turn

    Motor centrifugal switch sticky or plugged with • Remove dust or lint and spray with a cleaner and lubricant. lint. Inoperative door switch. • Test switch and replace if inoperative. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 20: Dryer Heating Assembly Does Not Heat Or Burner Does Not Ignite

    No power to power leads on valve. • Check thermostats, motor switch, and wiring. Sensor failed with contacts open. • Replace sensor. Igniter broken or open. • Replace igniter. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 21: Burner Ignites And Goes Out Repeatedly - Gas Dryer Models

    • Loosen screw and properly position igniter and bracket on tube assembly. burner tube assembly. Sensor installed improperly on burner housing. • Loosen screw and properly position the sensor on the burner housing. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 22: Dryer Heater Assembly Or Burner Shuts Off Prematurely

    • Check and replace seal if necessary. Air leak at cylinder seal(s). • Check and replace seal(s) if necessary. Air leak at front panel seal. • Check and replace seal if necessary. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 23: Dryer Heater Assembly Or Burner Does Not Shut Off

    4 inch water column, ask Gas Company to correct. Improper belt installation (Low RPM). • Check for proper installation. Refer to Figure 55. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 24: Clothes Are Too Hot When Removed From Dryer

    • If the abnormal operating noise is loudest at the vent exit, the problem is originating from the blower housing. Replace the current housing and cover. Refer to Figure 54. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 25: Netmaster And Mdc Models - Washer Control

    This error code occurs if the thermistor circuit opens while Open thermistor error. heating. This error code occurs if the thermistor circuit is shorted while Shorted thermistor error. heating. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 26: Microwand Does Not Communicate With Washer Control

    "E:OF" out properly. or "-C-"? E:OF Turn IR communication on Has IR communication (refer to been turned off? programming manual). Change electronic control and repeat procedure. FLW296S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 27: Coins Ignored When Entered In Washer Coin Drop

    Replace the coin drop. Properly reseat Properly reseat connection and connection and Replace electronic conduct diagnostic conduct diagnostic control. test again. test again. FLW1704S 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 28: No Visible Display On Washer Control

    Make sure "H1" Correct wiring connector is between Replace seated properly. transformer and transformer. Replace control. control board. FLW1695S *Refer to machine serial plate for correct voltage. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 29 Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) NO VISIBLE DISPLAY ON WASHER CONTROL 220-240 VAC (or 120 VAC) 50/60 Hz (SEE MACHINE SERIAL PLATE) (Models with 220- VAC) 801336 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 30 Correct wiring to the secondary door switch. FLW1696S *Refer to machine serial plate for correct voltage. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 31: Washer Will Not Start - "Door" Displayed

    Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) WASHER WILL NOT START – “DOOR” DISPLAYED 220-240 VAC (or 120 VAC) 50/60 Hz (SEE MACHINE SERIAL PLATE) (Models with 220- VAC) 801336 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 32 120 VAC)* across terminals control board. "H4-4" and "H6-5" on the electronic control? Replace the door lock assembly. *Refer to machine serial plate for correct voltage. FLW1697S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 33: Washer Will Not Start - E:dl On Display

    Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) WASHER WILL NOT START – E:DL ON DISPLAY 220-240 VAC (or 120 VAC) 50/60 Hz (SEE MACHINE SERIAL PLATE) (Models with 220- VAC) 801336 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 34: Washer Will Not Fill (Machine Empty, No E:sp On Display)

    (cold)? Is there 220-240 VAC Replace motor (or 120 VAC)* across control. mixing valve solenoid(s)? Replace mixing valve. *Refer to machine serial plate for correct voltage. FLW1698S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 35 Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) WASHER WILL NOT FILL (MACHINE EMPTY, NO E:SP ON DISPLAY) 220-240 VAC (or 120 VAC) 50/60 Hz (SEE MACHINE SERIAL PLATE) (Models with 220- VAC) 801336 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 36: Washer Overflows

    Replace inoperative water valve. *Refer to machine serial plate for correct voltage. FLW1699S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 37 Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) WASHER OVERFLOWS 220-240 VAC (or 120 VAC) 50/60 Hz (SEE MACHINE SERIAL PLATE) (Models with 220- VAC) 801336 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 38: Pump Or Drain Valve Does Not Operate

    220-240 VAC (or between pump 120 Volts)* from "H6-2" to "H6-5" on the machine control. machine control? Replace machine control. FLW1692S *Refer to machine serial plate for correct voltage. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 39: Washer Pump Does Not Operate

    Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) WASHER PUMP DOES NOT OPERATE 220-240 VAC (or 120 VAC) 50/60 Hz (SEE MACHINE SERIAL PLATE) (Models with 220- VAC) 801336 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 40: Serial Communication Error (E:sp On Washer Display)

    *Refer to machine serial plate for correct voltage. **NOTE: Machine must be restarted to check voltage. FLW1701S Voltage will be intermittently present during first 15 seconds until E:SP is displayed. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 41 Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) SERIAL COMMUNICATION ERROR (E:SP ON WASHER DISPLAY) 220-240 VAC (or 120 VAC) 50/60 Hz (SEE MACHINE SERIAL PLATE) (Models with 220- VAC) 801336 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 42 Tach. Circuit: Approx. 115 ohms (Terminals 4-5) Refer to values motor control. Windings: Approx. 4 - 5 ohms (Terminals 1-2, 1-3, 2-3) at right. Replace motor . FLW1702S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 43: Washer Motor Does Not Run (E:df On Display)

    Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) WASHER MOTOR DOES NOT RUN (E:DF ON DISPLAY) 220-240 VAC (or 120 VAC) 50/60 Hz (SEE MACHINE SERIAL PLATE) (Models with 220- VAC) 801336 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 44 500 and 35,000 ohms? Measure resistance at Replace thermistor/ thermistor. Is resistance heater assembly. value between 500 and 35,000 ohms? Check wiring to thermistor. FLW1705S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 45: Washer Will Not Heat ("Op" Or "Sh" Displayed)

    Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) WASHER WILL NOT HEAT (“OP” OR “SH” DISPLAYED) 801110R3 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 46 230 volts across the heat relay coil and terminals A1 - A2 on the electronic control the heat relay? or replace board. Check wiring or replace heat relay. FLW1703S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 47: Washer Will Not Heat (Models Equipped With Heater) (3 Phase Heater Machines Only)

    Section 3 Troubleshooting (NetMaster and MDC Models – Washer Control) WASHER WILL NOT HEAT (MODELS EQUIPPED WITH HEATER) (3 PHASE HEATER MACHINES ONLY) 801110R3 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 48 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 49: Netmaster Models - Dryer Control

    EC:09 Corrupted Data Error Communication error. Try card again. EC:0A Invalid Machine Type Wrong machine type. Before downloading, ensure data is for current machine type. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 50 Loyalty Purse Read Error Try card again. If error persists, card may be bad. EC:56 Loyalty Purse Write Error Try card again. If error persists, card may be bad. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 51 IR Communicator Programmed Off Reprogram infrared communicator on. Manually enable IR on control/Re-aim micro-wand and try again. Coin Error Inoperative coin sensor. Check coin drop area and remove obstructions. Possible tampering. Evaluate security procedures. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 52: Coins Ignored When Entered In Dryer Coin Drop

    Replace Are wires exiting coin electronic drop optical sensor control. cracked or broken? Replace coin drop. If problem still exists replace the control. DRY353S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 53: No Ir Communication With Dryer Control

    Communication Does the electronic “-C-” sequence checks control display “E:OF” out. or “-C-”? “E:OF” Check the following: -Was IR communication disabled by manual programming. DRY354S 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 54: No Display On Dryer Control

    Are there 120 or 240 transformer. Make volts AC to the primary sure the machine is of the transformer? plugged in and power is on. Replace the transformer. DRY351S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 55 Section 3 Troubleshooting (NetMaster Models – Dryer Control) NO DISPLAY ON DRYER CONTROL DRY352S_ 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 56: Dryer Door Open

    Check operation voltage on the of the door COM terminal of switch. the door switch to Replace if a neutral wire? necessary. Correct wiring to door switch. DRY1876S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 57 Section 3 Troubleshooting (NetMaster Models – Dryer Control) DRYER DOOR OPEN DRY356S_ 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 58 H2-4 and H2-6 on the the motor. control? Replace the Is there voltage across electronic H2-1 and H2-6 on the control. control? Refer to door open troubleshooting. DRY357S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 59: Dryer Motor Will Not Start

    Section 3 Troubleshooting (NetMaster Models – Dryer Control) DRYER MOTOR WILL NOT START DRY358S_ 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 60 Correct wiring between control Is there voltage on and thermo fuse FS-1 on the control to on the element. DRY359S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 61: No Heat (Electric Dryer Models)

    Section 3 Troubleshooting (NetMaster Models – Dryer Control) NO HEAT (ELECTRIC DRYER MODELS) DRY360S_ 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 62 Is there voltage across centrifugal on the terminal 1 of the motor motor. Replace and L1? motor if necessary. Correct wiring to the motor. DRY361S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 63: No Heat (Gas Dryer Models)

    Section 3 Troubleshooting (NetMaster Models – Dryer Control) NO HEAT (GAS DRYER MODELS) DRY362S_ 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 64 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 65: Mdc Models - Dryer Control

    (Card Reader Communication The control and the reader cannot communicate. Check reader, Machines) control and harness. NOTE: For all other Card Reader errors, consult the Card Reader manufacturer. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 66: Coins Ignored When Entered In Dryer Coin Drop

    Replace coin drop optical electronic sensor cracked control. or broken? Replace coin drop. If problem still exists replace the control. DRY353_S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 67 Section 3 Troubleshooting (MDC Models – Dryer Control) Notes 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 68: No Visible Display On Dryer Control

    240 (overseas) volts transformer. Make AC to the primary of sure the machine is the transformer? plugged in and power is on. Replace the transformer. DRY351_S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 69 Section 3 Troubleshooting (MDC Models – Dryer Control) NO VISIBLE DISPLAY ON DRYER CONTROL 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 70: Dryer Door Open

    Check operation voltage on the of the door COM terminal of switch. the door switch to Replace if a neutral wire? necessary. Correct wiring to door switch. DRY1876S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 71 Section 3 Troubleshooting (MDC Models – Dryer Control) DRYER DOOR OPEN 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 72 H2-4 and H2-6 on the the motor. control? Replace the Is there voltage across electronic H2-1 and H2-6 on the control. control? Refer to door open troubleshooting. DRY357S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 73: Dryer Motor Will Not Start

    Section 3 Troubleshooting (MDC Models – Dryer Control) DRYER MOTOR WILL NOT START 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 74 Correct wiring between control Is there voltage on and thermo fuse FS-1 on the control to on the element. DRY359S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 75: No Heat (Electric Dryer Models)

    Section 3 Troubleshooting (MDC Models – Dryer Control) NO HEAT (ELECTRIC DRYER MODELS) 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 76 Is there voltage across centrifugal on the terminal 1 of the motor motor. Replace and L1? motor if necessary. Correct wiring to the motor. DRY361_S © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 77: No Heat (Gas Dryer Models)

    Section 3 Troubleshooting (MDC Models – Dryer Control) NO HEAT (GAS DRYER MODELS) 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 78 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 79: Section 4 - Grounding

    0 Volts 50/60 Hz* electrician should correct the problem. *Refer to serial plate for 220-240 Volts correct voltage and Power 50/60 Hz* hertz. Cord W355SE3B Figure 2 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 80: Ground Wires From Terminal Block Or Power Cord To Rear Bulkhead And From Rear Bulkhead To Control Housing

    FROM REAR BULKHEAD TO CONTROL HOUSING Refer to Figures 3 and 4. 60 Hertz Models Ground Wires D442S Figure 3 50 Hertz Models Ground Wires D443S Figure 4 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 81: Washer Ground Connections

    Ground Power Cord to Control Cabinet Wrapper Grounding Hardware to Control Cabinet Wrapper Ground to Electric Drain Pump Ground to Outer Tub Ground to Outer Tub Front Ground to Outer Tub to Cabinet 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 82 Section 4 Grounding Ground Wire from Dryer SWD1G Figure 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 83: Washer Ground Connections - Washers With Suffix 4350 In Model No

    Ground Power Cord to Control Cabinet Wrapper Grounding Hardware to Control Cabinet Wrapper Ground to Electric Drain Pump Ground to Outer Tub Ground to Outer Tub Front Ground to Outer Tub to Cabinet 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 84 Section 4 Grounding Ground Wire from Dryer SWD2G Washers with Suffix 4350 in Model No. Figure 6 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 85: Dryer Ground Connections

    Motor Terminal Block to Base Motor to Base Terminal Block and Rear Bulkhead to Control Cabinet to Control Panel Ground to Electronic Controls Ground to Control Panel Assembly 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 86 Section 4 Grounding DRY976S Figure 7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 87: Section 5 - Service Procedures

    Open control panel service door and disconnect molex plug. e. Slide dryer forward, until leveling legs slide into notch on security cabinet. f. Lift dryer and place on level surface. SWD1658S Figure 8 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 88: Control Panel

    STEP 1. Move top of control panel Unlock control panel. Remove control panel away from control cabinet out of control cabinet. and lift up. H160SE3A Figure 9 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 89: Control Cabinet

    Refer to Figure 10. f. Carefully lift control cabinet assembly off washer. g. Remove screws holding left, right and rear control cabinets together. Refer to Figure 10. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 90: Electronic Control

    Contactor Control Shield Pressure Switch Rear Control Cabinet Control Cabinet Base Left Control Right Cabinet Control Cabinet Electronic Control Control Panel Overlay Control SWD1150P Panel Figure 10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 91 Remove four screws holding electronic control assembly to backside of control panel. Refer to Figure 11. f. Place the old control in the anti-static wrapping that the new control was supplied in. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 92 NOTE: DO NOT pull on wires. Instead, hold board control to dissipate any charge. near appropriate disconnect block and unplug by pulling on disconnect block. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 93: Non-Electronic Coin Drop

    Step 1. (2) Pull top of control panel away from control cabinet far enough to allow lifting control panel up and off the rail support of the 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 94 Drawer Housing Locknut 1/4 Inch Ratchet No. 310P4 1/4 Inch Ratchet Extension 3/8 Inch Tool Square Drive 7/16 Inch Disconnect Socket Block Coin H162SE3A Drop Figure 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 95: Electronic Coin Drop

    (1) Place coin drop into the control cabinet, align holes with guide wires, and slide into position. (2) Position the coin drop all the way to the front. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 96 Section 5 Service Procedures CK096 Mounting Tool Kit Mounting Tool Handle Mounting Tool Coin Drop Overlay Divider Guide DRY1970K Control Cabinet Front Figure 13 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 97: Card Reader

    Refer to Figure 14. Then tighten screws or nuts firmly. (3) Reconnect card reader harness. (4) Reinstall dryer. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 98 No. 310P4 1/4 Inch 1/4 Inch Ratchet Ratchet Extension Tool Card Reader Attaching 3/8 Inch Square Drive Card Reader Control Cabinet Front Control Cabinet Wrapper FLW1709S Figure 14 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 99 Then tighten screws firmly. Card Reader Control Cabinet Front Control Cabinet Front SWD1657S to Top Flange of Front Panel Attaching Screws Figure 15 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 100 Squeeze locking tabs in on pressure switch and push switch out toward rear of control shield. Refer to Figure 16. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 101: Pressure Switch

    Section 5 Service Procedures Pressure Switch Control Shield Screw Rear Access Panel Control Cabinet Wrapper SWD1140P Figure 16 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 102 Shield Control Coin Cabinet Drop Front Control Cabinet Overlay Wrapper Screw Screw Control Screw Cabinet Wrapper Tabs Control Cabinet Front Tabs Screw Panel Locator SWD1659S Figure 17 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 103: Control Cabinet Front

    Pull top of control panel away from control cabinet far enough to allow lifting control panel up and off the rail support of the control cabinet. Refer to Figure 9, Step 2. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 104 Section 5 Service Procedures Line Filter Terminal Block Panel Filter Network Varistor Terminal Block FLW861P Fitting Electrical Access Panel Figure 18 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 105: Washer Lower Access Panel

    Refer to Figure 19. b. Gently lower the access panel to disengage panel locators from bottom edge of front panel. Panel Locators Lower Access Panel Screws H202SE1A Figure 19 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 106: Inverter Control

    Remove screws holding inverter control to base of washer. Refer to Figure 20. h. Place old control in the anti-static wrapping that new control was supplied in. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 107: Electric Drain Pump

    NOTE: Refer to wiring diagram when rewiring drain pump. d. Remove three mounting screws holding pump to base and remove pump out through front of washer. Refer to Figure 21. FLW1684S Figure 21 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 108: Washer Belt

    Refer to Figure 22. NOTE: When installing belt, adjust belt tension. Refer to Paragraph 109. Pulley Rear Access Panel Belt Access Motor SWD1660S Figure 22 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 109: Mixing Valve

    Refer to Figure 23. solenoids. Mixing Valve-To- Dispenser Hose Hose Clamp Wire Harness Disconnect Mixing Blocks Valve Mixing Valve Plate Screws Inlet Hose H165SE3B Figure 23 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 110: Washer Front Panel

    If adjustment is panel. Refer to Figure 19. required, refer to Paragraph 110. f. Gently lower access panel to disengage panel locators from bottom edge of front panel. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 111 STEP 1: Pull seal up. STEP 2: Pull seal out. STEP 4: Pull seal out and remove STEP 3: Pull seal down. from front panel. FLW1190B Figure 25 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 112 Switch Door Latch Dispenser Switch Drawer Attaching Screws Screws Wire Harness SWD1661S and Wires Figure 26 Screw Wire Clamp Ring Spring Screw Door Seal H205SE1A Figure 27 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 113: Washer Loading Door

    Refer to Figure 28. Door Bezel Inner Door and Glass Hinge Assembly Lockwasher Door Glass Screw H212SE1A Figure 28 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 114: Washer Door Seal And Hose Assembly

    Refer to Figure 19. k. Gently lower access panel to disengage panel locators from bottom edge of front panel. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 115 Door Latch Switch Wire Harness Hose Clamp Hose Large Clamp Door Seal When Installing Door Seal, Align Connecting Hose in SWD1662S Vertical Position Large Clamp Figure 29 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 116: Washer Door Switch

    NOTE: To avoid damage to spring, use screwdriver on wire clamp ring to right or left of spring. c. Grasp loading door seal lip. Refer to Figure 25, Step 1. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 117: Washer Motor

    Refer to Figure 30. c. Install new wire tie holding small harness connector to motor frame. This is necessary to prevent future service calls. Refer to Figure 30. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 118 Section 5 Service Procedures Pivot Bolt Adjusting Bolt Rear Access To Motor Pivot Bolt Metal Adjusting Bolt SWD1663S Wire Harness Figure 30 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 119: Washer Heating Element (Models Equipped With Heater)

    Using a brass or wood rod, tap the threaded stud in toward washer about 1/4 inch to loosen heating element. Outer Tub Front Panel Washers Screw Heating Seal Element Clamp Ring FLW1742S Figure 31 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 120: Outer Tub Front Panel

    When seal releases from lip of front panel, pull out and remove the seal from front panel around door opening. Refer to Figure 25, Step 4. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 121 Screw Washers Outer Tub Front Panel Clamp Ring Seal SWD1664S Ground Wire Figure 32 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 122: Washer Inner Basket Pulley

    Remove cap screw (left hand thread) g. Grasp loading door seal lip. Refer to Figure 25, lockwasher and flat washer holding pulley to Step 1. inner basket shaft. Refer to Figure 36. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 123 Be sure to torque new cap screw to 240 minimum to 260 install seal with the tab in the 12 o’clock position. maximum inch pounds (27.5 to 29.7 Nm). 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 124 Attach three washers and three new nylon Rounded locknuts onto rods. Leave the nuts loose. FLW11K Corner IMPORTANT: Always use new nylon locknuts. Figure 34 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 125 NOTE: Torque new left hand thread screw to 240 minimum to 260 maximum inch pounds (27.5 to 29.7 Nm). 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 126 (Left Hand Thread) Washer Lockwasher Outer Flat Washer Inner Basket Pulley Inner Bolts Mounting Plate and Pressure Hose Clip Bearing Housing Assembly Pressure Hose SWD1665S Figure 36 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 127 Assembly Apply Anti-Seize Outer Compound to These Areas FLW1707S Inner Basket Figure 37 Left Hand Pulley Bolt Thread Tightening Screw Fixture Pulley FLW25K Flat Washer Figure 38 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 128: Bearing Housing

    Refer to Figure 17. l. While supporting the front panel assembly, remove the two bottom front corner screws. Refer to Figure 26. Remove front panel (with © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 129 240 minimum to 260 Figure 37. maximum inch pounds (27.5 to 29.7 Nm). w. After installing belt, adjust belt tension per Paragraph 109. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 130: Dryer Access Panel

    Push inner basket back into outer tub as far as possible. Figure 39 l. Tighten left hand thread screw. Be careful not to push the trunnion shaft forward while tightening the screw. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 131 • Whenever ground wires are removed during servicing, these ground wires must be reconnected to ensure that the machine is properly grounded. • Washer motor not grounded! Disconnect electric power before servicing motor. W502 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 132: Cabinet Top

    Front Panel Attaching Screws Rear 505617 Hold-Down Brackets D352SE1A DRY977S Figure 42 Figure 40 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 133: Lint Filter

    83. DRYER LOADING DOOR a. Open loading door. b. Remove screws holding loading door to hinges. Lint Refer to Figure 43. Filter Front Bulkhead SWD1666S Figure 43 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 134: Dryer Inner And Outer Door Panels And Door Pull

    Door Door Strike Strike Bracket Outer Door Panel Screw Wedge Door Pull Inner Door Panel and Seal Assembly Screw Door Hinge Front Panel D387PE3A Screws Figure 44 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 135: Dryer Door Seal

    Refer to Figure 45. Door Seal Door Seal Inner Door Panel Slot Bottom Of Door Inner Door Panel H182SE3A Figure 45 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 136: Dryer Front Panel And Panel Seal

    Refer to Figure 40. Swing bottom of front panel away from dryer far enough to disengage hold-down clips and locators from cabinet top. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 137: Copyright, Alliance Laundry Systems Llc – Do Not Copy Or Transmit

    Door Clip Front Switch Panel Seal Locator Sticker Door Catch Nameplate Hinge Hole Plugs Door Front Panel Catch Screw Screw Locator Sticker Lower Access Panel © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774 Screw D288PE3A...

  • Page 138: Dryer Door Hinge

    Refer to Figure 47. f. Remove four screws holding four locators to Figure 48 access panel or front panel. Refer to Figure 47. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 139: Burner System Components (Gas Models)

    Screw Igniter Wires Disconnect Block Secondary Coil Lead-In Holding Pipe Booster Coil Sensor Valve Sensor Nipple Shut-Off Terminals Union Valve (Shown in closed position) D241SE3G Figure 49 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 140 (2) Remove screw holding sensor to burner of dryer. housing. Refer to Figure 49. Attaching Screw Igniter and Bracket White Ceramic Portion Burner Tube Burner Tube Shutter D242SE3A Figure 50 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 141: Burner Housing And Heat Shroud (Gas Models)

    Remove two screws holding heat shroud to heater box and remove heat shroud out through front of dryer. Burner Tube Screw Base Burner Screw Housing D244SE3B Figure 51 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 142: Limit Thermostat

    Disconnect wires from heater assembly. Refer to Figure 51. D324SE3C NOTE: When reassembling, be sure all wire Figure 52 connectors are tight on element terminals, thermal fuse and limit thermostat. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 143: Air Duct

    Open loading door and remove screw from end Screws of lint filter. Refer to Figure 43. Thermistor D325SE3C d. Lift lint filter out of air duct, paying close Figure 54 attention to orientation. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 144: Dryer Motor And Exhaust Assembly

    Refer to Figures 58 and 59. i. Remove two screws holding motor mounting bracket to dryer base. Refer to Figure 54. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 145 Be sure the belt has been installed slide out through front of dryer. on the correct side of the idler lever. Refer to Figure 55. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 146 (2) Pry two motor clamps off motor mounting bracket with screwdriver, then lift motor out of mounting bracket. Refer to Figure 56. Exhaust Housing Attaching Screws D249SE3A Figure 57 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 147 (with wire securely crimped in place) into back side of connection block. Push terminal into connection block until locking tab on terminal spreads and holds terminal in place. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 148: Dryer Front Bulkhead Assembly

    Screws Screws Cylinder Seal Cylinder Slot Glide Slot D394S Cabinet Attaching Cabinet Screw Duct Attaching Screw Rivets Cylinder Glide Bracket D256SE3B Figure 60 Figure 61 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 149 No. 22506P Sealant. This is accomplished by applying a bead of sealant around the entire flanged area where the felt seal contacts the bulkhead. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 150: Cylinder Belt

    Refer to Figure 64. to Figure 47. After installing belt, manually rotate cylinder counterclockwise to check that belt is properly aligned. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 151: Dryer Cylinder Assembly

    To reduce the risk of serious injury or death by carbon monoxide and other gases in gas dryers, carefully read and follow all instructions given in this section. W005 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 152: Dryer Rear Seal

    To reduce the risk of serious injury or death by carbon monoxide and other gases in gas dryers, carefully read and follow all instructions given in this section. W005 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 153 • Washer motor not grounded! Disconnect electric power before servicing motor. W502 Rear Outlet Seal Cover Rear Bulkhead Attaching Screws Rear Bulkhead Attaching Screws Cylinder Roller Cylinder Roller Heater Exhaust Duct Screw 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT D405S...

  • Page 154: Cylinder Rollers

    Pull cylinder forward allowing rear of cylinder D260SE3B to drop down exposing rollers. Refer to Figure 66 Figure 66. h. Refer to Figure 66 for removal of roller from bulkhead. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 155: Rear Bulkhead And Heater Box

    Refer to Figure 49. instructions given in this section. W005 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 156 (Refer to appropriate wiring diagram when l. Remove heater box from rear bulkhead. Refer rewiring terminal block.) to Figure 67. Rear Bulkhead Heater Attaching Screws Heater Attaching Screws Heater D261SE3A Figure 67 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 157: Terminal Block Or Power Cord

    NOTE: Refer to wiring diagram when rewiring when removing the block. Insulation must be in switch. place when reinstalling block. Cabinet Terminal Block Terminal Block Attaching Screw D353SE3A Figure 68 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 158 Ground Ground Wires 115±12 V.A.C. V.A.C. 115±12 V.A.C. Neutral Side Dryer Power Cord (120 VOLT, 60 HERTZ SHOWN) D354SE3A Figure 69 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 159: Section 6 - Adjustments

    W185 d. Place rubber feet on all four leveling legs. Refer to Figure 70. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 160: Washer Loading Door

    Refer to Figure 71. Door Bezel Inner Door and Glass Lockwasher Inner Door Glass Loading Door Attaching Hinge Screw H212SE1B Assembly Figure 71 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 161: Washer Motor Belt Tension

    Refer to Figure 72. Inner Basket Pulley Pivot Bolt Adjusting Belt Bolt 1/4 Inch Motor Mounting Bracket Motor Pulley Pivot Bolt Metal Wire Harness SWD1667S Adjusting Bolt Figure 72 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 162: Washer Door Catch

    Reinstall door bezel. Funnel Door Catch 685429 Door Lock Alignment of These Two Edges 685430 Catch H250SE3A SHOWN CLOSED Figure 73 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 163: Shipping Braces

    Removal of supports prior to final installation may cause Shock Absorber Shipping Support Shock Absorber Shipping Support Shipping Bracket FLW821S Figure 74 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 164: Burner Flame (Gas Models)

    Air Shutter Lockscrew Shut-Off Valve Handle Shutter 1/8 Inch Pipe Plug (For checking manifold pressure) D265SE3A Figure 75 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 165: Cleaning Non-Electronic Coin Drop

    Figure 76. Save pin for reinstallation when cleaning is complete. f. Move metal clip closer to sensor so that it comes off frame. Refer to Figure 76. DRY5B Figure 78 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 166 NOTE: If coin drop does not operate properly after above steps have been completed, corrosion of metal or vandalized components within coin drop may be preventing the coin drop from functioning correctly. Replace coin drop. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 167: Cleaning Electronic Coin Drop

    Clean the coin path with a soft brush and wipe exposed surfaces with an alcohol moistened cloth. Refer to Figure 83. Catch DRY2088N Figure 81 DRY2090N Figure 83 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 168 Cloth DRY2091N DRY2091N Figure 84 g. Clean light sensors with a soft brush or air spray duster. Refer to Figure 85. Light Sensors DRY2092N DRY2092N Figure 85 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 169: Section 7 - Dryer Test Procedures

    10,000 - 13,000 Ohms a. Remove motor and exhaust assembly. Refer to Paragraph 98. Motor Motor Switch Disconnect Block Motor and Exhaust Assembly Drive Motor D326SE3A Figure 86 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 170: Motor Switch

    Inoperative start F. Manually depress actuator. switch. Replace switch. Continuity exists between switch Refer to Section 5. terminal 1 and switch terminal 2. Motor switch checks O.K. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 171 Replace motor. orange or copper wire on back Paragraph 98 Refer to of switch and brown or blue wire in terminal 4. All motor windings check O.K. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 172 Refer to Figure 87. Mounting Thermal Overload Protector Motor Switch D029KE3A Figure 87 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...
  • Page 173 Step “b”. Refer to Figure 92. Thermal Overload Protector Plastic Clip Top Of Motor Switch Motor Switch D359SE3A Figure 88 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 174: Burner System Operation

    The is turned off. heat from the burner flame causes the sensor contacts (located on burner housing beside the © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 175: Electrical Circuit To Ignition System (Gas Models)

    NOTE: If meter registers any other readings than those listed above, the respective coil(s) should be replaced. Holding D270SE3A And Booster Coil GAS VALVE FOR SILICON CARBIDE IGNITION Figure 90 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 176: Sensor Check (Gas Models)

    NOTE: If meter does not read appropriate Ohms, then replace the igniter. IMPORTANT: Always examine all wires, terminals and connectors to be sure wiring is correct before replacing any components. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 177: Thermal Fuse (Electric Models)

    Set meter to read Ohms. Apply meter probes to the heater assembly terminals. Meter should read as follows: (Cold Ohms). Refer to Figure 51. 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...

  • Page 178: Door Switch

    Apply probes to terminals 1 and 2 with door closed. The meter should read “infinite”. g. Open door. Meter should read “infinite” between 1 and 3 and “zero” between 1 and 2. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

  • Page 179: Section 8 - Internal Wiring Of Dryer Motor Switch

    • Washer motor not grounded! Disconnect electric power before servicing motor. W502 MAIN START ORANGE/COPPER CUSTOMER CIRCUIT PUSH TO START LINE Motor Switch Attaching Screws SWITCH SHOWN IN START POSITION R.S.P.C. D329SE3D Figure 92 801774 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
  • Page 180 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801774...

This manual is also suitable for:

Htet17-n2802Htey17-n2802Htex17-n2802Htey17-n4064Htex17-n2902Htez17-n2802 ... Show all

Table of Contents
