Alliance Laundry Systems CP040PMN1 Programming

Alliance Laundry Systems CP040PMN1 Programming

Washer-extractors pocket hardmount variable-speed ps40 control
Hide thumbs Also See for CP040PMN1:
Table of Contents

Advertisement

Quick Links

See also: Operation & Maintenance Manual , Installation Operation & Maintenance
www.groupdynamics-laundry.com
sales@groupdynamics.lv
Washer-Extractors
Pocket Hardmount Variable-Speed
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Refer to Page 9 for Model Identification
1
2
3
PS40
4
5
6
7
8
9
0
www.alliancelaundry.com
PS40 Control
RUN
PROG
PHM1398C
PHM1398C
Part No. F8112301R3
August 2015
