Installation and Operation Manual
IDRA N DS
Solar | solar storage cylinder
EN
Installation and Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDRA N DS 1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Beretta IDRA N DS 1500

  • Page 1 Installation and Operation Manual IDRA N DS Solar | solar storage cylinder Installation and Operation Manual...
  • Page 3: Table Of Contents

    Thank you again, and keep up the good work, Beretta CONFORMITY storage cylinders conform to DIN 4753-3/UNI and UNI EN 10025 standards. RANGE MODEL CODE IDRA N DS 1500 20136241 IDRA N DS 2000 20136242 IDRA N DS 2600 20086803 ACCESSORIES For a complete list of accessories and details of their compatibility, refer to the Catalogue.
  • Page 4: General

    GENERAL GENERAL SAFETY INFORMATION PRECAUTIONS The operation of any appliance that uses electrical power Check that the product is complete, undamaged and demands that a number of fundamental safety precautions as ordered as soon as you receive it. Report any dis- be respected.
  • Page 5: Description Of The Appliance

    Boiler temperature sensor socket Top coil Auxiliary temperature sensor socket (for models 1500) Il clima di casa Auxiliary temperature sensor socket (for models 2000 Model: IDRA N DS 1500 Code: 20052790 - 2600) Serial Number: K4LH3800001 Cylinder body Sleeve for electric heating element (not supplied) 20052790K4LH3800001 Capacità...
  • Page 6: Technical Specifications

    GENERAL TECHNICAL SPECIFICATIONS IDRA N DS DESCRIPTION 1500 2000 2600 Type of storage cylinder Vitrified Storage cylinder layout Vertical Heat exchanger layout Vertical Storage cylinder capacity 1390 1950 2572 Useful non-solar volume (Vbu) 1000 Diameter with insulation 1200 1300 1450 Diameter of storage cylinder without insulation 1000 1100...
  • Page 7: Location Of Sensors

    GENERAL Pressure drops TOP COIL PRESSURE DROP (mbar) 2000 1500 2600 1000 2000 3000 4000 5000 6000 FLOW RATE (l/h) Pressure drops BOTTOM COIL PRESSURE DROP (mbar) 1000 2000 1500 2600 1000 2000 3000 4000 5000 6000 FLOW RATE (l/h) LOCATION OF SENSORS The installer is responsible for making all necessary connections to the boiler and solar collectors Install-...
  • Page 8: Overall Dimensions And Water Fittings

    GENERAL OVERALL DIMENSIONS AND WATER FITTINGS storage cylinders can also be connected to previously installed hot water sources provided heat output IDRA N DS is suitable and care is taken to ensure correct water flow directions. Psc2 Psc1 IDRA N DS DESCRIPTION 1500 2000...
  • Page 9: Installer

    MODELS IDRA N DS 2000 storage cylinders come in two separate IDRA N DS packages: MODELS IDRA N DS 1500 - The first contains the painted cylinder, protected by a storage cylinders are delivered in a single IDRA N DS plastic bag and supported on a wooden pallet.
  • Page 10: Handling

    The following items are delivered in a plastic bag inside the ing material in compliance with applicable legislation. packaging: - Instruction manual MODELS IDRA N DS 1500 - Bar code labels Cut the strap (1) located under the insulation at the zips to - Hydraulic test certificate remove the cylinder from the pallet.
  • Page 11: Installing The Magnesium Anodes

    INSTALLER 11 INSTALLING THE MAGNESIUM MODELS IDRA N DS 2000 To remove the storage cylinder from the pallet, first remove ANODES the insulation then secure lifting cables to the lifting points on the top of the cylinder, and lift with care. Proceed as follows to install the magnesium anodes: - Remove the protective plugs - Fit the two magnesium anodes in the fittings (1) and...
  • Page 12: Fitting The Insulation

    INSTALLER 12 FITTING THE INSULATION MODELS IDRA N DS 2000 to 2600 Once the storage cylinder is correctly positioned inside the room where it is to be installed, proceed to fit the insulation and the accessories to complete the cylinder. Proceed as follows: - Unpack all the material from the second package - Wrap the insulation (3) around the storage cylinder,...
  • Page 13: Place Of Installation

    INSTALLER 13 PLACE OF INSTALLATION 14 INSTALLATION IN OLDER SYSTEMS AND SYSTEMS storage cylinders can be installed in any IDRA N DS REQUIRING MODERNISATION room where there is no specific requirement for an electri- cal protection rating higher than IP X0D. When installing storage cylinders in old IDRA N DS...
  • Page 14: Technical Assistance Centre

    TECHNICAL ASSISTANCE CENTRE 15 PUTTING INTO SERVICE 16 TEMPORARY SHUTDOWN It is essential to perform the following checks before start- If you are going away for a short period of time like a week- ing up or testing the functioning of the storage cylinder. In end or a short holiday, etc., and outdoor temperatures are particular, check that: going to remain above ZERO, proceed as follows.
  • Page 15: Maintenance

    TECHNICAL ASSISTANCE CENTRE 18 MAINTENANCE - Use a 45 mm wrench to unscrew the anode plug (3). Scheduled maintenance is essential for the safety, efficien- cy and long working life of your storage cylinder. Proper maintenance also reduces energy consumption and en- sures reliability over time.
  • Page 16: Recycling And Disposal

    TECHNICAL ASSISTANCE CENTRE 20 RECYCLING AND DISPOSAL At the end of its useful working life, do not abandon the storage cylinder in the environment, but dispose of it through the proper channels in accordance with applicable legislation. 21 TROUBLESHOOTING SUPPLEMENTARY HEATING CIRCUIT FAULT CAUSE SOLUTION...
  • Page 17: End User

    END USER END USER INSTRUCTIONS Refer to the GENERAL SAFETY INFORMATION and PRECAUTIONS section for safety-related information 22 START-UP 23 TEMPORARY SHUTDOWN The storage cylinder must be put into service for the first To reduce to the environmental impact and save energy, time by personnel from the manufacturer’s Technical As- in case of brief absences, week-ends, short trips, etc., and sistance Centre.
  • Page 18 END USER...
  • Page 19 END USER...
  • Page 20 Via Risorgimento, 23 A 23900 - Lecco (LC) www.berettaboilers.com The manufacturer strives to continuously improve all products. Appearance, dimensions, technical specifications, standard equipment and accessories are therefore liable to modification without notice.
