Beretta IDRA DS 300 Installation Manual

Solar storage cylinder
Hide thumbs Also See for IDRA DS 300:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installer and User Manual
STORAGE
CYLINDER
SOLAR
IDRA DS
INSTALLATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Beretta IDRA DS 300

Summary of Contents for Beretta IDRA DS 300

  • Page 1 STORAGE CYLINDER SOLAR IDRA DS INSTALLATION MANUAL...
  • Page 2 Range MODEL CODE IDRA DS 300 1150409 IDRA DS 400 1150419 IDRA DS 500 1150429 IDRA DS 1000 20001400 IDRA DS 1500 20002597 IDRA DS 2000 20002598 IDRA DS 3000 20002599...
  • Page 3 Dear Installer, Thank you for choosing a Beretta IDRA DS solar storage cylinder. You have purchased a modern, quality product that is designed to give dependable and safe service, and to provide comfort in the home for many years to come. Arrange for the storage cylinder to be serviced regularly by an authorised Beretta Technical Assistance Centre.

  • Page 4: Table Of Contents

    Contents GENERAL Safety precautions page 5 General safety information “ Product description “ Identification “ Design “ Technical specifications “ Accessories “ Water circuit “ INSTALLATION Unpacking the product pag. 12 Dimensions and weight “ Handling “ Fitting the insulation "...

  • Page 5: Safety Precautions

    Safety precautions As soon as you open the packaging, check imme- This storage cylinder must be serviced at least once diately that the contents are all present and unda- a year. maged. Contact the reseller from whom you pur- chased the product if you notice any problems. If the solar storage cylinder is not going to be used for an extended period of time, prepare it for shut- This IDRA DS solar storage cylinder must be instal-...

  • Page 6: Product Description

    IDRA DS solar storage cylinders are identified by two plates: – Data plate – Product identification plate This lists the technical specifications and performance of the product. This bears the name of the product. Beretta Caldaie Via Risorgimento, 13 23900 Lecco (LC) SOLAR STORAGE CYLINDER Serial...

  • Page 7: Design

    Design 1000 1500 Model Models Models 2000 and 3000 Models 1 - First magnesium anode 2 - Boiler probe well 3 - Auxiliary probe well 4 - Solar controller probe well 5 - Cylinder inspection flange 6 - Flange cover 7 - Bottom coil 8 - Polyurethane insulation 9 - Top coil...

  • Page 8: Technical Specifications

    Technical specifications IDRA DS DESCRIPTION 1000 1500 2000 3000 Storage cylinder type Vitrified non vitrified Cylinder layout Vertical Heat exchanger layout Vertical Storage cylinder capacity 1450 2054 2959 External diameter 1200 1300 1450 Height 1542 1535 1800 2050 2120 2405 2665 Insulation thickness 51,5...

  • Page 9: Water Circuit

    Water circuit 1000 1500 Model Models Models 2000 and 3000 Models UAC - Domestic hot water outlet MC - Outlet from boiler BOILER RC - Return to boiler - Outlet SOLAR - Return - DHW recirculation EAF - Domestic cold water inlet - Storage cylinder drain IDRA DS storage cylinders are delivered without a filling pump.
  • Page 10 TOP COIL pressure drop IDRA DS 300 IDRA DS 400 IDRA DS 500 FLOW RA TE (m PORTATA (m BOTTOM COIL pressure drop IDRA DS 500 IDRA DS 400 IDRA DS 300 0,25 0,75 1,25 FLOW RA TE (m PORTATA (m...
  • Page 11 TOP COIL pressure drop 2000 1900 1800 IDRA DS 3000 1700 1600 1500 1400 IDRA DS 2000 1300 1200 IDRA DS 1000 1100 1000 IDRA DS 1500 FLOW RA TE (m PORTATA (m BOTTOM COIL pressure drop 3200 3000 2800 IDRA DS 3000 2600 2400...

  • Page 12: Unpacking The Product Pag

    300 - 400 - 500 1000 - 1500 a wooden pallet. Models IDRA DS 300, 400 and 500 are packaged in car- dboard boxes, while model 1000-1500 comes in a foam rubber impact-proof wrapping). Models...

  • Page 13: Dimensions And Weight

    Dimensions and weight Ø IDRA DS DESCRIPTION 1000 1500 2000 3000 H - Height 1542 1535 1800 2050 2120 2405 2665 Ø - Diameter 1200 1300 1450 Net weight Gross weight (with packaging) Position (not for models IDRA DS 1000, 1500, 2000 and 3000) of the WATER RETURN GROUP. (**) Position (not for models IDRA DS 1000, 1500, 2000 and 3000) of the CONTROL BOX SUN 2.

  • Page 14: Handling

    Handling Once you have removed the outer packaging, proceed Models as follows to unpack and handle the solar storage cylin- 300 - 400 der. 500 - 1000 IDRA DS 1500: Cut the straps (1) to remove the cylinder from the pallet.The straps are located under the insula- tion at the hinges.

  • Page 15: Fitting The Insulation

    Fitting the insulation (IDRA DS 2000 and 3000) Once the storage cylinder is correctly positioned inside the room where it is to be installed, proceed to fit the insulation and the accessories to complete the cylinder. Proceed as follows: - Unpack all the material from the second package. - Fit the anodes (1) and (2).

  • Page 16: Place Of Installation

    Place of installation IDRA DS solar storage cylinders can be installed in any room where there is no specific requirement for an electrical protection rating higher than IP X0D. The room where the appliance is installed must, however, be dry to prevent the formation of rust. Respect the minimum specified installation distances to ensure correct installation and access for maintenance.

  • Page 17: Water Connections

    Water connections IDRA DS solar storage cylinders can be connected to even previously installed hot water generators provided they are of adequate output power, but care must be taken to ensure correct water flow directions. They can also be easily inte- grated in solar water heating systems based on SC-B 06 solar collectors with their corresponding fixing system, water control group, expansion vessel and thermostatic mixer valve.
  • Page 18 1000 1500 Model Ø i IDRA DS DESCRIPTION 1000 1500 - Domestic hot water outlet 1" 1/4 M 1" 1/2 F Ø - Outlet from boiler 1" 1/4 F Ø - Return to boiler 1" 1/4 F Ø - Collector outlet 1"...
  • Page 19 2000 - 3000 Models Ø i IDRA DS DESCRIPTION 2000 3000 - Domestic hot water outlet 1" 1/2 F Ø - Outlet from boiler 1" 1/2 F 1" 1/4 F Ø - Return to boiler 1" 1/2 F 1" 1/4 F Ø...
  • Page 20 Typical installation schematic Outlet Uscita °C Ingresso Inlet Water control system Gruppo idraulico 1 - Solar collector 10 - Drain - Mixer valve 2 - Storage cylinder 11 - Expansion vessel UAC - Domestic hot water outlet 3 - Collector probe 12 - Pump MC - Boiler outlet 4 - Isolating valves...

  • Page 21: Location Of Probes

    Location of probes 400-500 1000-1500 2000-3000 Model Models Models Models Pozzetto Well for SONDA BOILER Pozzetto Well for CALDAIA PROBE SONDA BOILER CALDAIA Well for Well for Pozzetto Pozzetto PROBE BOILER BOILER SONDA SONDA PROBE CALDAIA PROBE CALDAIA Pozzetto Pozzetto Pozzetto Pozzetto Well for...

  • Page 22: Checks During And After Initial Start-Up

    Checks during and after initial start-up Once the system has been started up, perform the fol- lowing checks: - Check that the flow rate in the solar heating circuit is equivalent to 30 l/h for each m of collector area. - Check that the solar heating circuit has been properly bled.

  • Page 23: Preparing For Extended Periods Of Disuse

    Preparing for extended periods of disuse If the solar storage cylinder is not going to be used for an extended period of time, perform the following ope- rations: - Drain the solar water circuit. - Close the shut-off cocks for the domestic hot water circuit.

  • Page 24: Cleaning And Removing Internal Components

    NOTE: Tighten the anode plug to a torque of 25-30 Nxm. Cleaning inside the storage cylinder For models IDRA DS 300 - 400 - 500: - Unscrew the four screws (4) and remove the cover (5)
  • Page 25 - Remove the flange cover (6) For ALL models: - Unscrew the nuts (7) securing the flange (8) and remo- ve the flange complete with its seal. - Clean inside the cylinder and remove any residues through the access hole. Once cleaned, refit all components, following the above steps in the reverse order.

  • Page 26: Troubleshooting

    Troubleshooting CAUSE CORRECTIVE ACTION PROBLEM Solar heating system is There is air in the circuit. Bleed the circuit. inefficient. The flow rate is too low or too Make sure that the flow rate cor- high. responds to about 30l/h per m Check that the cold pressure of Pressure is low.
  • Page 28 Via Risorgimento, 13 - 23900 Lecco (LC) Servizio Clienti 199.13.31.31* Assistenza Tecnica Numero Unico 199.12.12.12* www.berettaclima.it The manufacturer strives to continuously improve all products. Appearance, dimensions, technical specifications, standard equipment and accessories are therefore liable to modification without notice.

This manual is also suitable for:

Idra ds 400Idra ds 500Idra ds 1500Idra ds 2000Idra ds 3000Idra ds 1000
