Installation Guide
IP-DECT Base Station & IP-DECT Gateway
Power Distribution
The IPBS1 can be powered using the following methods:
• Power over Ethernet, IEEE 802.3af
• A local AC-adapter
NOTE: For more information about power distribution, see
page 25.
Software
The software in the IPBS1 can be updated by downloading new software without
disconnecting the equipment. The new software is stored in flash memory. For
information on how to update the software in the IPBS1, see the applicable Installation
and Operation Manual for the IPBS1.
Connectors
• Two 8-pin RJ45 modular jacks for LAN/PoE and powering
• A 6-pin RJ12 modular jack for factory testing
LEDs
Status of LED1 (lower LED)
Steady Green
Flashing fast amber
Steady Amber
Alternating red/green
Status of LED2 (upper LED)
Not lit
Steady green
Flashing slow green
Flashing red
Flashing fast red
Alternating red/green
15 October 2014 / Ver. B
Description
Operational
Download of firmware in progress.
TFTP mode
No Ethernet connection
Description
IPBS1 operational and no traffic on the IPBS1.
IPBS1 operational and traffic on the IPBS1.
Fully occupied with traffic.
No air synchronization - searching for air sync
candidates.
Download of RFP software in progress.
RFP not initialized.
TD 92989EN
3.3 Power the Base Station on
