Service Manual
Series 40 M46 Variable Pumps

Torque chart

Fastener size and torque chart

Item Fastener
920 Servo piston cover screws
921 Servo piston cover screws
130 Front cover screw
163 Front cover screws
1506 Rear cover screws
806 Filtration cover screw
115 Lock/seal nut
927 Displacement limiter lock/seal nut
1213 Control handle nut
1210 Screw

Plug size and torque chart

Item O-ring plug
102 3/4 16 UNF
107 1-1/16 12 UNF
110 9/16 18 UNF
111 9/16 18 UNF
158 7/16 20 UNF
810 9/16 18 UNF
1001 5/8 18 UNF
1101 1-5/16 12 UNF
1102 1-5/16 12 UNF
44 | © Danfoss | September 2017
Wrench size
3/8 hex
3/8 hex
T50 Torx
T55 Torx
9/16 hex
1/2 hex
11/16 hex
9/16 hex
1/2 hex
3/8
Wrench size
1 inch hex
9/16 internal hex
11/16 hex
11/16 hex
9/16 hex
11/16 hex
5/8 hex
1-1/4 hex
1-1/4 hex
Torque
15 N•m [11 lbf•ft]
15 N•m [11 lbf•ft]
58 N•m [43 lbf•ft]
91 N•m [67 lbf•ft]
77 N•m [57 lbf•ft]
30 N•m [22 lbf•ft]
37 N•m [27 lbf•ft]
19 N•m [14 lbf•ft]
15 N•m [11 lbf•ft]
14 N•m [10 lbf•ft]
Torque
108 N•m [80 lbf•ft]
115 N•m [85 lbf•ft
37 N•m [27 lbf•ft]
37 N•m [27 lbf•ft]
20 N•m [15 lbf•ft]
37 N•m [27 lbf•ft]
20 N•m [15 lbf•ft]
176 N•m [130 lbf•ft]
176 N•m [130 lbf•ft]
11026743 | AX00000027en-US0202
