AccuBoom™ Spray Zone Map Examples
The following screens are examples of AccuBoom maps displayed on the Envizio Pro or Envizio Pro II field
computers.
Field Review Mode While Recording a Boundary
FIGURE 1.
Field Review Mode with Completed AccuBoom™ Field Boundary and No-Spray Zone
FIGURE 2.
162
No-Spray Zone
Envizio Pro and Envizio Pro II Installation and Operation Manual
Spray Zone
Field Boundary
