Calibration & Operation Manual
OmniSeed™
Viper Pro™ Software Version 3.10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OmniSeed Viper Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Raven OmniSeed Viper Pro

Summary of Contents for Raven OmniSeed Viper Pro

  • Page 1 Calibration & Operation Manual OmniSeed™ Viper Pro™ Software Version 3.10...
  • Page 2 GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the accuracy, integrity, continuity, or availability of these services and cannot guarantee the ability to use Raven systems, or products used as components of systems, which rely upon the reception of these signals or availability of these services.

  • Page 3: Table Of Contents

    Table of Contents Calibration Reference Sheet ....................ix Unit Definitions and Conversions ....................x Unit of Measure Definitions ....................x Unit of Measure Conversions ....................x Chapter 1 Important Safety Information..........1 Safety Information ........................1 Hydraulic Safety ........................2 Electrical Safety ........................
  • Page 4 ..................74 Main and Job Screen Displays ..................74 Controller Status Screen ....................84 Chapter 5 Using the OmniSeed Viper Pro System......87 Overview of Job Files and Features ..................87 Overview of Job Types ...................... 88 Overview of Job Features ....................88 Starting a New AgX Job ......................
  • Page 5 Table of Contents Pausing and Resuming Jobs ....................102 Pause a Job ........................102 Resume a Paused Job ....................102 Application Rates Area ......................102 Tabs ............................105 Main Tab .......................... 105 Guide Tab ........................106 Rx+Cov+Scout Tab ......................106 Rx Tab ..........................
  • Page 6 Table of Contents Chapter 7 Advanced Settings and Features........139 Overview ..........................139 Advanced Product Control Settings and Features ..............139 Section Assignments ....................... 140 Fan and Pressure Cal ...................... 140 Miscellaneous Settings Area ................... 140 Feature Settings Area for Granular Products ..............
  • Page 7 Table of Contents Chapter 8 OmniSeed Section Control ..........187 Section Control Setup Screen ....................188 Turn-Off % Coverage ...................... 189 Configuring Automatic Section Control ................189 Enabling Section Control Override .................. 190 Switch Box Setup ......................191 Section Control Aggressiveness Factor ................
  • Page 8 Table of Contents Chapter 11 File Maintenance and Editing Reports ......211 Overview ..........................211 File Maintenance ........................211 Preparing a USB Flash Drive for File Maintenance ............212 Flash Drive File Structure ...................... 214 RDE Folder ........................214 Viper Folder ........................
  • Page 9 Table of Contents APPENDICES Appendix A System Diagrams..............237 Appendix B Calculating the Calibration Values........245 Appendix C Testing Extension Cables ..........265 Appendix D Updating CAN Nodes via the Viper Pro ......269 Appendix E Using the Front Panel Program with the Viper Pro System ..............
  • Page 10 Table of Contents viii OmniSeed™ Viper Pro™ Calibration & Operation Manual...

  • Page 11: Calibration Reference Sheet

    Calibration Reference Sheet Record the settings and calibration values used when programming the field computer and keep this sheet for future reference or when contacting a service technician. Circle the setting selected on the field computer for the following options: US (Acres) SI (Hectares) Turf (1000 Square Feet)

  • Page 12: Unit Definitions And Conversions

    Unit Definitions and Conversions Unit of Measure Definitions Abbreviation Definition Abbreviation Definition Gallons per Minute Pounds per 1,000 square feet L/min Liters per Minute Millimeters dL/min Deciliters per Minute Centimeters Pounds per Square Inch Decimeters Kilopascal Meter Gallons per Acre Miles per Hour L/ha Liters per Hectare...

  • Page 13: Important Safety Information

    • Follow all safety information presented within this manual. • If you require assistance with any portion of the installation or service of Raven equipment, contact a local Raven dealer for support. • Follow all safety labels affixed to the system components. Be sure to keep safety labels in good condition and replace any missing or damaged labels.

  • Page 14: Hydraulic Safety

    Ensure that the power cable is the last cable to be connected. • Disconnect the Viper Pro field computer before jump-starting the vehicle. • Disconnect the Viper Pro field computer and any other Raven systems before welding any component of the machine. OmniSeed™ Viper Pro™ Installation & Operation Manual...

  • Page 15: Introduction

    Congratulations on the purchase of the Viper Pro™ precision application management system! The Raven Viper Pro is a multi-purpose precision tool offering the latest technology in precision agriculture with features including product application control, field mapping, and application reports, as well as in-field guidance via a connected DGPS (Differential Global Positioning System) receiver.

  • Page 16: Viper Pro Features

    The guidance feature offers straight (A-B) line, last pass, fixed contour and pivot swath patterns to match the field and application. In addition, GPS information may be sent to an optional Raven external light bar. See Chapter 6, Viper Pro Guidance, for more detailed operation. OmniSeed™ Viper Pro™ Installation & Operation Manual...

  • Page 17: Agx™ Compatibility

    Viper Pro system. The Viper Pro is also capable of integrating into many Raven CANbus control systems or with Raven standard serial interface control consoles and virtually any new or existing DGPS receiver.

  • Page 18: The Viper Pro Interface

    Chapter 2 The Viper Pro Interface The following sections offer an overview of the user interface features of the Viper Pro field computer. Active Matrix Transflective Touch Screen Active Matrix Transflective touch screen technology offers clear visibility across a range of lighting conditions and even in direct sunlight while the touch screen functionality places menus and options literally at the operator’s finger tips.

  • Page 19: Front Panel

    Introduction Front Panel The front panel of the Viper Pro provides easy access to the power button and the USB connection. The following is a description of the front panel features of the Viper Pro: Viper Pro Front Panel FIGURE 2. Touch Screen Power USB Port...

  • Page 20: File Transfer

    4 GB of storage and should be used to manually transfer files to and from the field computer. USB flash drives may be purchased directly from Raven Industries (4 GB USB Flash Drive P/N 524-0002-065) as well as many retail locations.

  • Page 21: Rear Panel

    Introduction Rear Panel The following is a brief introduction to the ports and connectors available on the back of the Viper Pro field computer. The rear panel offers additional USB ports as well as an ethernet port for wireless capabilities using an optional Slingshot Field Hub.

  • Page 22: Viper Pro Care And Use

    Chapter 2 Viper Pro Care and Use Refer to the following guidelines for proper care and use of the Viper Pro field computer. CAUTION • Do not apply any type of liquid or glass cleaner directly to the surface of the touch screen. Harsh chemicals may damage the touch screen.

  • Page 23: Updates

    + 12 V Ignition Radar Out + 12 V Switched Battery Positive Updates Updates for Raven manuals as well as software updates for Raven consoles are available at the Raven Applied Technology Division web site: Manual No. 016-3001-015 Rev. C...
  • Page 24 Chapter 2 www.ravenhelp.com At Raven Industries, we strive to make your experience with our products as rewarding as possible. One way to improve this experience is to provide us with feedback on this manual. Your feedback will help shape the future of our product documentation and the overall service we provide.

  • Page 25: Installation, Start Up, And Registration

    I nstallation, Start Up, CHAPTER C h a p t e r 3 and Registration Overview of the Installation Process The following sections are intended as an overview of the Viper Pro installation process. These instructions cover basic installation of the Viper Pro field computer and supplied components and cabling. Note: For instructions on installing additional hardware with the Viper Pro, refer to instructions provided with the additional or optional component(s).

  • Page 26: Mounting The Field Computer

    Chapter 3 Mounting the Field Computer Refer to the following sections for detailed instructions on mounting the Viper Pro field computer and Switch Box and connecting the required cables. Mounting the Switch Box Note: The following instructions illustrate mounting the switch box below the Viper Pro field computer. The mounting bracket (P/N 107-0171-847) also may be used to mount the switch box above the computer.

  • Page 27: Mounting The Viper Pro And Switch Box In The Cab

    Installation, Start Up, and Registration Use the eight flat head screws to fasten the mounting bracket to the Viper Pro field computer. Match up the two mounting posts on the back of the switch box with the smaller flange of the mounting bracket.

  • Page 28: Dgps Receiver Connection

    Five product control nodes can be connected to the Viper Pro control system for any combination of liquid, granular, chemical injection, or spinner control applications. Review the Raven CANbus Installation Manual for details on building a CANbus network or adding a control channel to an existing product control system.

  • Page 29: Power Connection

    Installation, Start Up, and Registration Power Connection CAUTION The power leads should be connected after all other installation instructions have been completed. Reversing the power leads may cause damage to the field computer. Ensure that the Viper Pro has been properly mounted and all component cabling has been connected before connecting the chassis cable to power.
  • Page 30 Chapter 3 Raven OmniSeed Tow Behind System Cabling Diagram (D/N 054-5002-001) FIGURE 1. OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 31 Installation, Start Up, and Registration Raven OmniSeed Tow Between System Cabling Diagram (D/N 054-5002-001 cont.) FIGURE 2. Manual No. 016-3001-015 Rev. C...

  • Page 32: Start Up

    Chapter 3 Start Up Note: Before connecting or using any additional or optional components with the Viper Pro precision application management system, be sure to follow any installation instructions and verify proper installation. Before powering up the Viper Pro, check that the field computer is properly mounted and all power and cable connections have been installed properly as instructed in the previous sections.
  • Page 33 • Sprayer/Spreader to launch the Viper Pro precision application management system in a liquid or granular applicator mode. Refer to the Raven Viper Pro Installation and Operation Manual for more information on operation of the field computer in this mode.

  • Page 34: Touch Screen Calibration Wizard

    Chapter 3 If the Viper Pro is set as the CAN Controller, the Viper Pro will attempt to establish communication with the CANbus system. The CAN Initialization Results screen displays the results of CANbus detection. If the status of the CAN nodes is displayed properly, touch the Start Viper button to finish the start up sequence.

  • Page 35: Registering The Viper Pro

    Note: The Air Seeder activation key is required to control systems using the Gran 4 control mode which is required for interfacing with the Raven OmniSeed system. Manual No. 016-3001-015 Rev. C...

  • Page 36: Activation Key Request

    Weather Module The Viper Pro is capable of reading information from an external weather station and recording this information into the application report. See Appendix G, Weather Station, or contact a local Raven dealer for more information. AgX Prepopulated Jobs AgX recommendations can be transferred onto the Viper Pro field computer for pre-populated job and product information for product control and application.
  • Page 37 Installation, Start Up, and Registration Write down the Machine ID and Validation Code from the Viper Pro field computer on the Registration Code sheet; an example is shown below. Machine ID and Validation Code FIGURE 3. Registration Code This is the Registration Code for a Viper. Do not misplace this paper or you will not be able to register your product. 3M8828-000102-03667-0102-000L To register your product and receive an Activation Key go to www.ravenprecision.com, select the Support tab and choose Product Registration.
  • Page 38 Chapter 3 On a home or office computer, go to the Raven Applied Technology Division web site at: www.ravenhelp.com and click on the “Activation Key Request” link. Fill in the requested information and then click Next. OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 39 Installation, Start Up, and Registration The Registration Code screen displays. Fill in the machine ID, validation code, and registration code from the registration code sheet. Click the Next button. If the registration was processed successfully, a prompt similar to the following will be displayed. Locate the product Activation Key.
  • Page 40 Chapter 3 Back on the ‘Key 1’ screen on the Viper Pro, use the on-screen keyboard to enter the activation key received from the Raven web site (see step 8). Note: If the Viper Pro has been registered previously, touch the Menu button on the main screen and select Setup, then Reg.

  • Page 41: Initial Set Up And Navigation

    I nitial Set Up and CHAPTER C h a p t e r 4 Navigation Detecting CANbus Nodes The Viper Pro must be able to communicate with the CANbus system to make sure product is being applied correctly. Viper Pro should automatically establish communication with the switch box node, drill node, seed blockage node, scale nodes (if present), and product nodes 1 through 5.

  • Page 42: Can Initialization Results

    Each of these nodes is capable of providing up to five control channels for the OmniSeed system. Since the Raven Viper Pro is only capable of controlling five control channels, if both the air cart and product controller nodes will be connected to the OmniSeed system, each node must be properly configured to ensure that the nodes control products properly.
  • Page 43 Initial Set Up and Navigation Disable Control Channels. Initially, the air cart node is configured to provide five control channels for the OmniSeed system. It is recommended to remove control channels to configure the node for the maximum number of bins used with the air seeder system or to make control channels available for a product controller node to control liquid product application with the OmniSeed system.
  • Page 44 Chapter 4 Select one of the desired control channels to disable and touch within the Product Control Settings area as indicated in the image below. For example, select Node 5 and touch within the Product Control Settings area to display the first node settings screen for control channel 5.
  • Page 45 Initial Set Up and Navigation When the Program Selection Menu screen displays, select the Air Seeder option to restart the Viper Pro application. The CAN Initialization Results screen will display again. Verify that the appropriate control channels are displayed. If the air cart node will be the only node used to control product application with the OmniSeed system, select the Start Viper option to begin the air seeder control system.
  • Page 46 Chapter 4 Select one of control channels currently assigned to the air cart node and touch within the Product Control Settings area. The first node settings screen for the selected control channel will be displayed. Touch the Next button along the right side of the screen to display the second node settings screen. Touch the displayed valve cal value.
  • Page 47 The optional product controller node may be added to the OmniSeed system to control liquid product application during seeding operations. When adding the product controller node to the Raven CANbus, the network may need to be readdressed to properly detect and address the node on the network.
  • Page 48 Chapter 4 Touch the Finish button to finish re-addressing nodes on the CANbus. The Viper Pro will re-initialize the CANbus system using the new node addresses and display the CAN Initialization Results screen. The “AccuBoom Node” entry indicates that the field computer has recognized the product controller node. Touch the Config.

  • Page 49: Initial Set Up

    Initial Set Up and Navigation Initial Set Up The first time the Viper Pro is powered up, the field computer will require the operator to input information about the machine and the type of applications, products and setup any additional features connected to the system.

  • Page 50: Product Control Type

    Viper Pro to control application of a product during a field application. If the Viper Pro will be connected to a separate Raven rate control console via a serial cable, select the specific rate controller from the list of controller model options.
  • Page 51 Values, for instructions on refining the speed cal value. Note: The GPS speed over CANbus feature is only available with specific Raven speed sense nodes. This feature utilizes NMEA speed over ground data transmitted over the CAN network which eliminates the need for a separate, external speed sensor.

  • Page 52: Application And Control Valve Type(S)

    Typically used to control a hydraulic motor to a spreader apron. Note: When controlling an air seed system with the OmniSeed Viper Pro, be sure to configure product channels controlling air cart bins with a PWM close type control valve to ensure proper operation of the OmniSeed system.
  • Page 53 An optional OmniSeed authorization key is required for Gran 4 and Gran 5 application types to enable the field computer to control air seeder control systems. Contact a local Raven dealer for purchasing information and refer to the Activation Key Request section on page 24 to enter the activation code to unlock the Gran 4 and Gran 5 application type selections.

  • Page 54: Rate Cal(S)

    Chapter 4 Rate Cal(s) Touch within the Product Control area at the bottom of the main screen. Make sure that Node 1 is selected on the CAN Controller Status screen and touch within the second data display, or Product Control Settings area, on the CAN Controller Status screen.Touch the Rate Cal value displayed on the screen and use the on-screen keypad to enter the desired target rate for a product application.

  • Page 55: Bin Level Sensor Calibration

    Initial Set Up and Navigation Bin Level Sensor Calibration Capacitive Bin Level Sensors The Raven OmniSeed system utilizes capacitive low bin level sensors to ensure products are available in each bin for the seeding operation. Note: The field computer monitors the capacitive low bin level sensors for low bin alarm conditions. If the field computer does not display an alert, the low bin level sensors may require recalibration.

  • Page 56: Optional Bin Pressure Sensor

    An optional bin pressure sensor may be installed to monitor the air cart bin pressures during operation. The Raven OmniSeed system monitors the bin pressure while seeding to help ensure that product in each bin is metering properly. The field computer is capable of displaying an on-screen alert if any of the bin pressure sensors detect pressure in the bin falls below a set threshold.
  • Page 57 Initial Set Up and Navigation The CAN Controller Status screen will display. Select the desired product bin to calibrate the corresponding sensor. If multiple bin pressure sensors are installed on a multi-bin air cart, the following steps will need to be repeated to calibrate each sensor individually.
  • Page 58 Chapter 4 Cal. Proceed to the Bin Pressure Sensor Calibration section on page 47 to complete the bin pressure sensor calibration. Low Limit. Enter a value for the low limit to activate an alarm if the bin pressure (AIR) falls below the set value. High Limit.
  • Page 59 Initial Set Up and Navigation Bin Pressure Sensor Calibration The Viper Pro field computer is capable of monitoring pressures in PSI [kPa] with the OmniSeed system. To ensure that the field computer properly monitors the air cart bins, each pressure transducer should be recalibrated at least once a day to ensure the sensor is monitoring pressure in the bins correctly.

  • Page 60: Meter Cal(S)

    Note: When operating with the Raven hydraulic drive system in a direct drive configuration, use a meter cal value of 60. For systems with a high or low rate kit installed with a dual sprocket setup, multiply...
  • Page 61 Initial Set Up and Navigation Toggle the master switch on. WARNING The metering rollers will begin turning during the priming procedure. Keep away from moving components and alert anyone around the air cart when performing the priming process. Use the INC/DEC switch to adjust the roller speed while priming the roller. Be sure that the product being calibrated is selected before toggling the INC/DEC switch in the application control screen.

  • Page 62: Valve Cal(S)

    Touch the Next button to view additional settings for the selected product node or control channel. Touch the displayed valve cal value and use the keypad to enter the calibration value for the installed control valve. Note: Raven recommends the following initial valve cal values: Valve Type Calibration Value Standard Valve...

  • Page 63: Dual Loop Control Cals

    Initial Set Up and Navigation Valve Cal 2 (Optional) The valve cal 2 value may be used to fine tune control valve response and reduce application rate oscillations when using a Fast Close, PWM or PWM Close control valve. Fast Close Valves. When using a fast close valve to control product application, valve cal 2 is utilized to enable a high resolution rate control for lower application rates.

  • Page 64: Fan Cal

    Sgain value until the system stabilizes. Fan Cal The OmniSeed Viper Pro must be calibrated to monitor the fans used to provide air flow for product bins on the air cart.

  • Page 65: Section Setup

    Fan Calibration screen. Section Setup The OmniSeed Viper Pro must be configured for the specific vehicle and drill being used for seeding applications. To ensure the best possible results, the Section Setup Wizard should be completed if any part of the seeding system (i.e.
  • Page 66 Chapter 4 Tractor Setup The tractor setup screens configure the relative locations of the GPS antenna, the control point or hitch, and the pivot point. These points may be different for the specific tractor type selected. See the Conventional Tractor Setup section on page 54, Tracked Tractor section on page 55, or Articulated Tractor section on page 55 for detailed instructions on locating and measuring these points.
  • Page 67 Initial Set Up and Navigation Tracked Tractor Note: The pivot point of a tracked tractor is in the center of the track length on the center-line of the vehicle. Pivot/Control Point GPS Antenna Fore/Aft Distance Measurement GPS Antenna Left/ Right Measurement Enter the left/right offset of the GPS antenna from the pivot point.
  • Page 68 Chapter 4 To determine the offset direction, at the pivot point and facing toward the front of the vehicle, is the antenna in front (fore) or behind (aft) of the pivot position? Select the direction of the fore/aft offset. Measure the distance from the pivot point to the center of the front axle. Measure the distance from the pivot point to the center of the rear axle.
  • Page 69 Initial Set Up and Navigation Four Wheel Cart Setup Note: A four wheel cart has two pivot points at the center of each cart axle. Enter the length from the cart hitch to the pivot point on the first cart axle. The hitch length must be measured perpendicular to the cart axle.
  • Page 70 Chapter 4 Select the direction of the opener offset from the implement pivot point. To determine the offset direction, at the drill pivot point and facing toward the front of the vehicle, are the openers in front (fore) or behind (aft) of the drill pivot position? Select the direction of the fore/aft offset. Enter the number of sections on the drill.
  • Page 71 Initial Set Up and Navigation Section Settings Configuring sections on the field computer is critical for the OmniSeed system to control products and liquid sections correctly during seeding operations. To properly map coverage for each product and shutoff sections, the Viper Pro requires that sections be programmed from the left to right side of the implement based upon the section midpoint.
  • Page 72 Chapter 4 For Example: The OmniSeed system controls granular products across the full implement width. When programming granular sections, enter the full implement width for each granular section controlled with the air cart node. Liquid products may be controlled in multiple sections across the implement width. When programming liquid application sections, enter the measured section width for each liquid section on the implement.
  • Page 73 The Map Sections to Wiring screen requires the operator to program the section wiring for each of the products and also allows the operator to set the desired on-screen display character and the Raven CAN switch box switch number for controlling the section or product.
  • Page 74 Continue entering the “Display Character” value for any remaining granular sections. Complete the mapping of granular sections, enter the switch number associated with each product on the Raven CAN switch box. Touch the “Switch Number” value for the first granular product section and use the on-screen keypad to enter a value of ‘1.”...
  • Page 75 Initial Set Up and Navigation For Example: Given the following drill configuration as shown in Figure 5 on page 63: • Overall implement width equals 600 in. [1524 cm]. • Three granular bins (three sections at the full implement width centered at the middle of the implement).
  • Page 76 Chapter 4 Mapping Liquid Sections for Switch Box Controls Note: It is recommended to create a diagram for the specific implement section configuration and refer to this diagram while mapping sections. Mapping sections on the OmniSeed system is a two part process. Complete the following procedures for the granular product sections and any liquid shut-off sections as necessary before proceeding to the Section Selection section on page 68.
  • Page 77 Initial Set Up and Navigation For Example: The following mapping was completed for granular sections in the previous section (review the Mapping Granular Sections for Switch Box Controls section on page 61 for information on mapping granular product sections). The granular product sections currently occupy ‘Wired As’ values 1, 2 and 3. Therefore, the first liquid section must be mapped to ‘Wired As’...
  • Page 78 Use the on-screen keypad to enter the desired Switch Number for sections or section groups. The Raven CAN switch box only provides 10 section switches for OmniSeed section control functions from the cab. For systems controlling multiple sections with liquid products, it will be necessary to group sections to the same switch.
  • Page 79 Initial Set Up and Navigation Touch the Next button on the Mapping Sections to Wiring screen to display the Blockage Loup 1 Sensor Setup screen or OK to finish mapping sections on the implement to the OmniSeed system. To complete the implement configuration, proceed to the Section Selection section on page 68.
  • Page 80 Chapter 4 Section Selection The section settings and mapping procedures discussed earlier in this chapter have configured the section widths and locations for each granular and liquid section controlled by the OmniSeed system. The final part of section configuration on the OmniSeed system consists of populating how each of the configured sections and available control channels will create coverage maps and affect coverage area and product volume totals.
  • Page 81 Initial Set Up and Navigation To set up the Section Select screen: Note: It may be helpful to deselect all sections and products before beginning the following procedure. For most OmniSeed systems, most sections will not be associated with each product on the Section Select screen.
  • Page 82 Chapter 4 To assign the first liquid product to the correct boom sections, start at the top of the first liquid product column. Starting with the lowest available section value, begin assigning the first liquid product with the sequential section values from top to bottom of the liquid product column. To assign any subsequent liquid products and sections, return to the top of the product column for the next liquid product and assign the product to the next sequence of available sections.

  • Page 83: Profiles

    Initial Set Up and Navigation Profiles Once the initial set up is complete for the machine settings, it is recommended to save a machine profile. The profile stores many of the settings previously set during the initial set up procedure as well as any communication port settings, customized section configurations and guidance feature settings.

  • Page 84: Powering Down The Viper Pro

    Chapter 4 Profile Changes If any of the settings saved within a profile are changed during operation of the field computer, the Viper Pro will prompt the operator to save the current profile settings before the field computer is powered down. To save the current set up in a new profile, type in a new profile name and touch OK.
  • Page 85 Refer to the Start Up section on page 20 for details on the Program Selection Menu options. If a Job is in progress when the exit button is selected, the Viper Pro will display a warning alerting the operator. Raven recommends closing any open jobs before exiting the Viper Pro application to avoid losing job information.

  • Page 86: Navigating The Viper Pro Interface

    Chapter 4 Navigating the Viper Pro Interface The following sections provide an overview to navigation of the Viper Pro user interface and may be used to familiarize operators to various information displays on the Viper Pro touchscreen and for help navigating through settings screens and menus.
  • Page 87 • If ‘CAN’ is displayed in the speed area, the Viper Pro is registering speed from the Raven CANbus control system. The Viper Pro is also using the displayed speed value for speed compensated product rate control. •...
  • Page 88 Refer to Chapter 5, Using the OmniSeed Viper Pro System, for more details about the information displayed using the tab views.
  • Page 89 Initial Set Up and Navigation Map Tools Several screen navigation tools are located directly below the Maps area on the Viper Pro main screen. A red box appears around an active screen tool. To use a tool, simply touch the desired tool icon and touch the area of the Map to perform the selected action.
  • Page 90 Chapter 4 Icon Description The Map Extents tool quickly adjusts the map zoom to display all map features or field information. Use this tool to avoid using the zoom and pan tools to return to a complete field map or to display all field boundary areas currently stored on the Viper Pro regardless of current GPS location.
  • Page 91 Initial Set Up and Navigation Wireless Communication Status The status of wireless communications is displayed on the Viper Pro main screen in the tool bar below the map. Wireless Communication Status Icon Note: For more information on using the wireless communication features with the Viper Pro, see Appendix H, Wireless Communications and Remote Service.
  • Page 92 The status indicator will display in green during normal operation. Touch the Product Control Status or indicator to view the CAN Controller Status screen and access the Node Setup screens when connected to a Raven CANbus system. Note: See the Controller Status Screen section on page 84 for an overview of the settings and information areas displayed on the CAN Controller Status screen.
  • Page 93 Initial Set Up and Navigation GPS Status Display The current status of DGPS reception, as well as the current source for differential corrections is displayed in this area on the main screen. Note: This indicator is not necessarily the status of the GPS Receiver or the availability of DGPS reception.
  • Page 94 Chapter 4 Packing Pressure If the drill node is connected to the CANbus, the current pressure applied to the packer gauge wheels will be displayed at the bottom of the main display. Touch the Packing Pressure display to access the Packing Pressure Information screen. The following information and settings are displayed on the Packing Pressure Information screen: Calibrate Sensor.
  • Page 95 Refer to Chapter 10, Seed Blockage Sensors, for details on set up and operation of the seed blockage system with the OmniSeed Viper Pro. Menu Various configuration and feature settings for the Viper Pro control system are accessible via the ‘Menu’ button in the lower, right corner of the Viper Pro display.

  • Page 96: Controller Status Screen

    When connected to a separate product rate control console, the Viper Pro Controller Status screen displays boom section and product rate information provided by the rate controller. Refer to the Raven Viper Pro Installation and Operation Manual for more information about using the Viper Pro field computer with an external rate control console.
  • Page 97 Initial Set Up and Navigation • The Miscellaneous Settings Area displays an overview of current selections for the display units, speed sensor and current vehicle speed, etc. Information about the CANbus nodes is also accessible by touching within this area. Refer to the Miscellaneous Settings Area section on page 140 for more information. •...
  • Page 98 Chapter 4 OmniSeed™ Viper Pro™ Installation & Operation Manual...

  • Page 99: Using The Omniseed Viper Pro System

    Viper Pro. Note: To ensure memory resources are available, Raven recommends performing file maintenance periodically to remove unused job files from the memory on the field computer. Refer to Chapter 11, File Maintenance and Editing Reports for more information.

  • Page 100: Overview Of Job Types

    The SST Summit software is required to utilize the AgX pre-populated job files and recommendations on the Viper Pro. Contact a local Raven dealer for more information or to acquire an activation code for the AgX features on the Viper Pro field computer.
  • Page 101 A multi-product variable rate key must be purchased and authorized in order to provide multi- product VRA within a job. Contact a local Raven dealer to acquire the activation key and refer to the Registering the Viper Pro section on page 23 for assistance entering the activation code on the Viper Pro field computer.

  • Page 102: Starting A New Agx Job

    Viper Pro will display a prompt. Contact a local Raven dealer to acquire an AgX activation code or refer to AgX File Maintenance section on page 224 for assistance transferring recommendations from a USB flash drive to the Viper Pro.
  • Page 103 Using the OmniSeed Viper Pro System The Select Field screen will be displayed. Select the Grower, Farm and Field to use for the job. Note: Select the Order by Nearest option at the top of the screen to display pre-populated jobs closest to the current vehicle location at the top of each list.

  • Page 104: Assign Recommendations To Product Channels

    Chapter 5 When the correct recommendation is selected, touch the Next button to display the Assign Recommendation to Channel screen. This screen displays the available control channels and any recommendations available for the selected field. For instructions on completing the job set up process, continue to the Assign Recommendations to Product Channels section on page 92.

  • Page 105: Booms

    Using the OmniSeed Viper Pro System Assigning Recommendations Note: While recommendations are not required, product control channels selected on this screen should have a recommendation assigned before the job is started. A single recommendation may be assigned to multiple channels if more than one channel will apply the same product.

  • Page 106: Conversion Factor

    Chapter 5 Conversion Factor Rate Conversions may be used to calibrate a prescription map recommendation for the application or a different product. For Example: Enter a value of ‘2’ to double the prescription rates on the selected prescription map or a value of “0.8” to apply 80% of the prescribed rate.

  • Page 107: Starting A Standard Job

    Using the OmniSeed Viper Pro System Starting a Standard Job To begin a standard job and use the Viper Pro to enter all product and job information: Select Menu, then Start Job. Select New Job. The New Job screen displays.
  • Page 108 Chapter 5 If Swath Guidance was selected, select the guidance pattern best suited to the field area and application. Refer to the Swath Guidance Patterns section on page 126 for details on the available patterns and using guidance during a job. Touch Next.

  • Page 109: Product Setup

    Using the OmniSeed Viper Pro System Touch Next. If Product Application was selected, the Product Selection screen displays. CAN nodes are controlled in a sequential manner and each single product node provides one product control channel. The operator may only enable the number of control channels currently available on the machine when setting up a new job.
  • Page 110 Chapter 5 Touch Browse to display a list of folders or prescription maps stored in the Viper Pro file structure. Note: If an AgX recommendation is available on the Viper Pro, the AgX prescription map files can be loaded into a standard job by accessing the AgXRec folder on the above screen. Prescription map files within the AgXRec folder will have several data fields associated with the file.

  • Page 111: Prescription Rate Conversions And Default Rates

    Using the OmniSeed Viper Pro System Prescription Rate Conversions and Default Rates When product setup is complete for each enabled product, the Rate Conversion screen will be displayed if any prescription maps have been assigned to products. Rate Conversions may be used to calibrate prescription maps for the application. Enter a value of ‘2’ to double the prescription rates on the selected prescription map or a value of “0.8”...

  • Page 112: Existing Jobs

    Chapter 5 Existing Jobs Jobs previously created on the Viper Pro may be reopened to complete report information or to resume a field operation. The following options are available when opening an existing job file: • View the existing job •...

  • Page 113: Using An Existing Field Boundary

    Using the OmniSeed Viper Pro System Using an Existing Field Boundary On the Main tab, select the Information icon displayed below the Map area and touch within the field boundary displayed on the screen. A preview of the selected job and field boundary area is displayed.

  • Page 114: Pausing And Resuming Jobs

    Chapter 5 Pausing and Resuming Jobs While a job is in progress, the Viper Pro is continuously logging GPS location and other equipment status information. This may not be desired at all times during an operation such as refilling tanks or bins or if the machine will not be moving for a brief period.
  • Page 115 Using the OmniSeed Viper Pro System Bin Level The level of product remaining in each air cart bin is displayed as a percentage of the total bin height. If the bin displays “Ready” for the bin level, the ultrasonic sensor may need to be calibrated.
  • Page 116 Chapter 5 Smart Cal The Smart Cal feature allows the operator to continually calibrate and refine the seed system cal weight(s) during seeding operations by monitoring a bin load cell and the calculated amount of seed or product applied in the field.

  • Page 117: Tabs

    Using the OmniSeed Viper Pro System Tabs The tabs displayed along the right side of the screen allow the vehicle operator to select the information displayed in the map area. The tabs may be used during field operations to toggle coverage, scouting or guidance information at any time and can be used to help the vehicle operator manage the various operations and systems during an application.

  • Page 118: Guide Tab

    Chapter 5 Guide Tab If the swath guidance feature is enabled during the job setup process, touch the Guide tab during the job to access the swath guidance tools and features or to toggle between the available guidance patterns. Note: Refer to Chapter 6, Viper Pro Guidance, for detailed information on using the guidance features on the Viper Pro field computer.

  • Page 119: Rx Tab

    Using the OmniSeed Viper Pro System Rx Tab The Rx tab is only accessible if a prescription map is loaded for at least one product during the job setup process. The Rx tab displays the target, or the total, area of the prescription map.

  • Page 120: Cov Tab

    Chapter 5 Cov Tab The Cov tab displays the area covered by active boom sections which create the coverage map for each product. The coverage map displays covered area in green (default) if the actual application rate matches the target or prescription rate. Any areas where the actual application rate does not meet the expected target range will be highlighted in the colors assigned for the rate high and rate low values.

  • Page 121: Scout Tab

    Contact a local Raven dealer for more information about available GPS correction sources and services which may help avoid issues with GPS drift and scout maps.

  • Page 122: Section Control Tab

    Chapter 5 Section Control Tab The Section Control tab is not available for standard zone mapping applications. The Section Control tab displays the current Zone map for liquid shutoff sections. See Chapter 8, OmniSeed Section Control, for more information about using the automatic section control feature.

  • Page 123: How To Mark A Field Boundary

    Using the OmniSeed Viper Pro System Group of Points. Select this option to allow the operator to quickly plot multiple points of the same type during an active job. For example, select the ‘Group of Points’ option and a custom entry for “Rocks.” During the job application, the operator can access the Scout tab and touch the “Rocks Point”...
  • Page 124 Chapter 5 Auto Point Entry. The Viper Pro automatically records points along the driven path to create the boundary in real-time. The field computer will also automatically close the field boundary when the vehicle comes within one boom or implement width of the starting point. The operator may also close the boundary manually if desired.

  • Page 125: Importing A Field Boundary

    Using the OmniSeed Viper Pro System Importing a Field Boundary If a boundary has been recorded previously and is in the shapefile format (.shp), the boundary may be imported into the current job. Note: Shapefiles must contain only one polygon. For help using the File Maintenance feature, see Chapter 11, File Maintenance and Editing Reports.

  • Page 126: Tally Registers

    Chapter 5 Select a file from the list and touch OK. The Viper Pro will import a compatible shapefile into the job in progress. Tally Registers The tally registers feature of the Viper Pro may be used to track area and volume totals over the course of a field application or over the course of an application season.

  • Page 127: Resetting The Tally Registers

    Using the OmniSeed Viper Pro System The Tally Registers screen displays the following for each product node or control channel: • Total Volume (Ttl Vol) • Field Volume (Fld Vol) • Tank Volume (Tnk Vol) • Total Area (Ttl Area) •...

  • Page 128: Setting Or Resetting Distance And Individual Nodes

    Chapter 5 Setting or Resetting Distance and Individual Nodes To reset an individual node, or the Viper Pro odometer from the main screen: Touch the Product Control area at the bottom of the main screen. Touch the Tally Registers button at the bottom of the CAN Controller Status screen. Touch the Next button on the Tally Registers screen to display the Viper Pro Odometer screen.

  • Page 129: Alarms

    Using the OmniSeed Viper Pro System Alarms If the Viper Pro is configured as the CANbus controller, the field computer will display a specific warning prompt for any configured alarm conditions encountered. Any new warning conditions encountered by the field computer will be displayed automatically when the condition is detected and will contain information to assist the machine operator with addressing the alarm condition.
  • Page 130 Chapter 5 To acknowledge the warning, but keep the warning information accessible, touch the OK button. To clear the warning condition from the Viper Pro, touch the Clear Alarms button. Note: Touching the Clear Alarms button will clear the current alarm prompts from the Viper Pro display. However, the alarm condition may still be present in the application system and the condition may need to be corrected.
  • Page 131 Using the OmniSeed Viper Pro System The following table discusses the alarms and the conditions that will set off an alarm for products 4 or 5. Alarm Condition This alarm activates when the actual application rate differs from the specified percentage rate for more than five seconds, This alarm activates only when the system is in Auto mode.

  • Page 132: Creating Application Reports

    Chapter 5 Creating Application Reports When a field operation is completed, the operator may have the Viper Pro create a job report with the coverage map and application or coverage data collected within the open job. The job report may then be transferred to a home or office computer for viewing and archiving or printed as a visual report for a customer.
  • Page 133 Using the OmniSeed Viper Pro System Field Information Use the Field Information screen to enter field information and the crop type if applicable. The Viper Pro will store field and crop information entered on the field computer. Select a field name or crop type entered during a previous operation and the field computer will automatically enter the information from the previous job.
  • Page 134 Chapter 5 Applicator Information Use the Applicator Information screen to enter the operator or custom applicator address and license number. The Viper Pro will store any applicator information entered on the field computer. Select the operator name from the drop down list to automatically enter the applicator information for future jobs. Touch the Next button to display the Vehicle Information screen.
  • Page 135 Using the OmniSeed Viper Pro System Product Information Note: The Product Information screen(s) will not be available if the Product Application option is not selected during the job setup process. Skip to the Report Notes Information section on page 124 to finish entering report notes.
  • Page 136 Chapter 5 After the last ingredient in the chemical mixture is entered, touch the OK button. The following screen will be displayed. Select the View button to review the entered product mixture information. Note: Refer to the Single Color Coverage Map section on page 123 for information on the “1 Color Coverage Map”...

  • Page 137: Viper Pro Guidance

    Viper Pro. Contact a local Raven dealer for additional assistance with compatible receiver options. Non-Raven DGPS receivers may also be used with the Viper Pro. To avoid issues with connection and compatibility, contact the receiver manufacturer or a local dealer for additional information and receiver capabilities before purchasing.

  • Page 138: Swath Guidance Patterns

    Chapter 6 Swath Guidance Patterns If ‘Swath Guidance’ is enabled during the start job process, the operator must select a swath pattern to use during the job. The following swath patterns are available. Pattern Description Straight A-B A straight A-B line pattern for parallel guidance. Pivot A 360 degree (or circle) pattern.

  • Page 139: Set A-B Line By Heading

    Viper Pro Guidance Drive to the end of the swath and touch the Set B button on the screen. Once the B point is set, Viper will create a straight guidance line displayed in blue. Set A-B Line by Heading An A-B Line can also be created by using the Set B by Heading feature.

  • Page 140: Setting The Fixed Contour Pattern

    Chapter 6 The A point is set when the ‘Set B by Heading’ icon is selected. The Set A-B Line By Heading screen will display. Select one of the following to enter the heading for the A-B Line: Touch one of the compass heading arrows to set the heading along a compass heading. Touch the Use Current Heading button to use the current vehicle heading shown in the center of the compass display.

  • Page 141: Setting The Last Pass Pattern

    Viper Pro Guidance Setting the Last Pass Pattern If Swath Guidance is enabled, the Viper Pro will automatically display the ‘Guide’ tab when a job is opened. Turn Around Lock The last pass pattern provides guidance based upon the nearest covered area so the operator does not need to set points or record a swath path.

  • Page 142: Setting The Pivot Pattern

    Chapter 6 Setting the Pivot Pattern If Swath Guidance is enabled, the Viper Pro will automatically display the ‘Guide’ tab when a job is opened. To begin swath guidance with the pivot pattern: Start with the machine located at a point on the outside of the center pivot area and touch the ‘Set A’ button on the screen.

  • Page 143: Using The Guide Tab

    Viper Pro Guidance Using the Guide Tab Viper Pro will automatically display the Guide tab when a job is opened. The map area displays a Course Direction Indicator in the form of an arrow with the arrow pointing in the direction of travel of the vehicle. The operator may access additional guidance information and features by selecting the displayed areas or on- screen buttons.
  • Page 144 Chapter 6 Swath Number The Swath Number displays the number of passes completed by the vehicle. Alternate Swath Pattern Button The Alternate Swath Pattern Button displays the alternate guidance pattern available for the current job. Alternate View Button The Alternate View button allows the operator to toggle back and forth from ‘Down Field View’ to ‘Bird’s Eye View.’...

  • Page 145: Screen Icons

    Viper Pro Guidance ReCal A-B Button When using the Straight (A-B) Line guidance pattern, touch the Guidance Menu icon to access the Recal A-B button. Touch the Recal A-B button to recalibrate the displayed A-B line to the current machine location. Reset A-B Button When using the Straight (A-B) Line guidance pattern, touch the Guidance Menu icon to access the Reset A-B button.

  • Page 146: Saving An A-B Line

    Chapter 6 Saving an A-B Line During the job setup, select Straight A-B or Fixed Contour as the swath pattern. Once the job is started: Touch Set A to start the first swath path. Drive to the end of the first swath. Touch Set B.

  • Page 147: Loading An A-B Line

    Viper Pro Guidance Loading an A-B Line During the job setup, select straight A-B or fixed contour for the swath pattern. Once the job is started: Touch the Guide Menu icon in the guidance screen. Touch the Load A-B button. The Select A-B Line File screen will display. Available A-B Lines Filtering Options If several A-B lines are saved on the Viper Pro, the following filtering options may be used to help locate a...

  • Page 148: Nudge Feature

    Chapter 6 Show within distance. Select the distance filter option to locate an A-B line within a set distance of the current GPS position. The operator may select the distance to use as a filter up to a maximum of 10 miles [16 km] (straight A-B) or 2 miles [3.2 km] (fixed contour).

  • Page 149: Using The Nudge Feature

    Viper Pro Guidance Select Adjust Nudge to display the Nudge Settings screen. Use the on-screen keyboard to enter the nudge value for the Nudge 1 and 2 values. Select the ‘inches’ or ‘feet’ option to set the units for the entered nudge value. Select the ‘Save these settings as default for future jobs’...
  • Page 150 Chapter 6 OmniSeed™ Viper Pro™ Installation & Operation Manual...

  • Page 151: Advanced Settings And Features

    A dvanced Settings CHAPTER C h a p t e r 7 and Features Overview This chapter contains descriptions of advanced settings and features available when controlling a CANbus product control system with the Viper Pro field computer. The following settings and features are not required for operation of the Viper Pro system and are intended to assist with various operations using the Viper Pro field computer.

  • Page 152: Section Assignments

    Chapter 7 Section Assignments When connected to the OmniSeed system, the Section Select screen is required to complete the initial calibration of the implement or drill. Refer to the Section Selection section on page 68 for details on assigning products to sections on the OmniSeed system. Fan and Pressure Cal The Fan RPM area displays the current RPM of the air cart fans.
  • Page 153 Advanced Settings and Features The following information displays are for reference and monitoring purposes only: Fan/Pump RPM Display. The fan or pump RPM is a display only. This read out displays the fan RPM if a fan sensor is being used with a granular application or a pump RPM if a pump sensor is equipped for a liquid application.
  • Page 154 Chapter 7 Audible Alarm. When the audible alarm setting is enabled, the Viper Pro will sound a five second alarm tone if an alert condition or alarm setting is detected on the CANbus (i.e. low tank or bin, zero speed, off rate percent etc.).
  • Page 155 Advanced Settings and Features Default Capacity Button. Touch the Default button on the Miscellaneous Settings screen to reset the Maximum volume per minute value to 10,000. Load Cell. Touch the Load Cell button if a Digi-Star load cell will be used for calibration of product remaining in a bin.

  • Page 156: Feature Settings Area For Granular Products

    Chapter 7 Feature Settings Area for Granular Products The information displayed in the Feature Settings area is an overview of the alarm and feature settings for the selected product control node. For granular product nodes or control channels, the following settings will be displayed in the Feature Settings area: •...
  • Page 157 Advanced Settings and Features Node Feature Settings Screen (Page 1) Touch within the Feature Settings area to view the first screen of settings for the selected product node or control channel. Note: Touch the Next button to access additional alarm and feature settings for the selected product node or control channel.
  • Page 158 Chapter 7 Node Feature Settings Screen (Page 2) From the CAN Controller Status screen, touch within the Features Settings area to display the first Node Settings screen and select the Next button to access the following alarm and feature settings. Note: The following sections offer descriptions of the various options and settings used with granular products.

  • Page 159: Feature Settings Area For Liquid Products

    Area for Granular Products section on page 144. If the OmniSeed system will be used with a Raven AccuFlow™ system, the anhydrous system must be assigned to product channel 4 on the Viper Pro to ensure valve shut off is performed correctly using the switch box inputs.
  • Page 160 Chapter 7 To modify the feature or alarm settings for the above features, touch within the feature settings area on the CAN Controller Status screen. Status Screen Example (Liquid) Note: Before changing any of the feature or alarm settings, be sure to select the correct product node or control channel by touching the corresponding radio button displayed at the top of the feature settings area.
  • Page 161 Note: The dual flow percent is replaced with a FER Cal value when operating a Raven Sidekick Pro™. Refer to the Sidekick Pro Installation and Operation Manual for more information about operation with the Viper Pro field computer.
  • Page 162 Note: Contact a local Raven dealer for information on injection systems or bin level sensors. Flow/Shaft Alarm. Enable the flow/shaft alarm to display an alert if the field computer does not detect a signal from the pump shaft encoder or flow switch. This alarm may be used to help troubleshoot flow errors with a CAN motor control node.
  • Page 163 257 for additional information on performing calibration or adjustments for PWM type control valves. Low PSI Alarm. When controlling a Raven Sidekick Pro™ direct injection system, the ‘Low PSI Alarm’ feature will be displayed on the Node Settings screen. When enabled, this alarm indicates that the injection pressure is below the carrier line pressure.

  • Page 164: Product Control Settings Area For Granular Products

    Chapter 7 Product Control Settings Area for Granular Products The Product Control Settings area displays an overview of the following calibration settings and values used by the control system to monitor or adjust the rate of product application: • • •...
  • Page 165 Advanced Settings and Features Node Control Settings Screen (Page 1) Touch within the Product Control Settings area to view the first screen of settings for the selected product node or control channel Note: Touch the Next button to access additional product control settings for the selected product node or control channel.
  • Page 166 Chapter 7 Node Control Settings Screen (Page 2) Touch within the Product Control Settings area and then select the Next button on the first Node Settings screen to access the following settings. Valve Cal. The valve cal value is used by the field computer to make adjustments to a product or hydraulic control valve connected to the CANbus system.

  • Page 167: Product Control Settings Area For Liquid Products

    Settings Area for Granular Products section on page 152. If the OmniSeed system will be used with a Raven AccuFlow™ system, the anhydrous system must be assigned to product channel 4 on the Viper Pro to ensure valve shut off is performed correctly using the switch box inputs.
  • Page 168 Chapter 7 To modify product control settings for the above features, touch within the product control settings area on the CAN Controller Status screen. Status Screen Example (Liquid) Note: The selected product control node appears with a check mark in the corresponding radio button at the top of the Feature Settings Area.
  • Page 169 Spreader. The current spreader constant value used by the Viper Pro control system. Refer to the Raven Viper Pro Installation and Operation Manual for details on adjusting the spreader constant for the gate height or belt travel measurements and adjustments.
  • Page 170 Chapter 7 Valve Cal and Valve Cal 2. The valve cal value is used by the field computer to make adjustments to a product or hydraulic control valve connected to the CANbus system. Refer to the Valve Cal(s) section on page 50 for information on the recommend initial valve cal and valve cal 2 values.
  • Page 171 Advanced Settings and Features Node Control Settings Screen (Page 3) Standby Pressure. When controlling a liquid product with a PWM valve selected (not PWM close), the standby pressure value sets the pressure which the system will maintain in the product lines when the master or all boom sections are toggled off.

  • Page 172: Dual Pressure Area

    Chapter 7 Dual Pressure Area Note: The pressure displays calibrated in this area are designed for monitoring product pressures via a product control node. Refer to the Optional Bin Pressure Sensor section on page 44 to calibrate bin pressure sensors used with seeding systems. Liquid product pressures monitored by the Viper Pro, via electronic pressure transducers, are displayed as P1 (Pressure Transducer 1) and P2 (Pressure Transducer 2) on the Viper Pro main screen.

  • Page 173: Gps Status Screens

    Advanced Settings and Features GPS Status Screens The GPS Status area provides a quick reference for DGPS signals transmitted to the Viper Pro from the connected DGPS receiver. To view additional information and access features for the DPGS information on the Viper Pro field computer, touch the GPS Status area on the main screen.

  • Page 174: Smartrax Settings Screens

    Chapter 7 Touch the Rev Sense button to display the Reverse Sense screen. Review the on-screen feature description and select the desired mode of operation. When the Rev Sense feature is enabled, the field computer will prompt the operator for the direction of travel each time the field computer is powered up. While travelling at least 2 mph [3.2 km/h], select the current direction of travel to calibrate the Viper Pro for automatic reverse detection.

  • Page 175: Wireless Communication Status

    If a Job is in progress when the exit button is selected, the Viper Pro will display a warning alerting the operator. Exit the Viper Pro application without closing the job, touch Yes. Raven recommends closing any open jobs before exiting the Viper Pro application to avoid losing job information.

  • Page 176: About Button

    Chapter 7 About Button From the Viper Pro main screen, touch Menu and select the About button to view the current software and build version installed on the Viper Pro. The About Viper screen also displays the space remaining on the Viper Pro internal memory.
  • Page 177 Advanced Settings and Features Adjust Brightness Touch the Adjust Brightness button at the bottom of the About Viper prompt to display the Adjust Brightness settings. Mode Selection Button - Mode Selection Button - Day Mode Enabled Night Mode Enabled The Adjust Brightness settings prompt displays the following: Day/Night Mode Selection Button.

  • Page 178: Web Button

    Chapter 7 Web Button If the Slingshot Field Hub, or similar hardware, is connected to the ethernet port on the back of the Viper Pro, touch Menu, and select the Web button to access the world wide web on the Viper Pro touch screen. Web Address On-Screen Web Keyboard...

  • Page 179: Setup Button

    Advanced Settings and Features Setup Button Touch Menu and select the Setup button to access the following menu items: • • • Registration Keys Maps Local • • • Communication Ports Product Control Light Bar • Sect (Sections) Note: See the Setup Menus section on page 168 for a description of the features accessible through the Setup Menu.

  • Page 180: Start Job

    The job file automatically logs coverage information for reference at a later date and creates coverage reports for viewing on a home or office PC. Refer to Chapter 5, Using the OmniSeed Viper Pro System, for detailed information about using the Viper Pro during field applications.

  • Page 181: Maps

    Advanced Settings and Features Maps Coverage, scout and prescription (Rx) map displays may be customized to suit the equipment operator or application through the map option in the setup menu. To set map display options from the Viper Pro main screen, touch Menu and select Setup and Maps. The following actions may be performed through the Maps setup menu: •...
  • Page 182 Chapter 7 To Download Street Maps Create a folder on the computer in which to store the download files. ® Access the TIGER/Line web page at: http://www.census.gov/cgi-bin/geo/shapefiles2013/main From the Select a layer type drop-down list, select the Features-Roads option. Click Submit. The Roads page displays. From the All Roads drop-down list, select the desired state, then click Submit.

  • Page 183: Scout Maps

    Advanced Settings and Features To Delete Street Maps Street maps not used frequently may be removed to clear up internal memory for job data and other information. To delete a street map from the Viper Pro: Select Menu, then Setup, Maps, Street Map, Delete Streets, and OK. Viper deletes the .sct files from the field computer.

  • Page 184: Coverage Maps

    Chapter 7 Touch the corresponding Color button. The Feature Colors screen displays. Select a color for the feature and touch OK. Viper assigns the color to the feature and returns to the Enter Feature Names and Colors screen. To setup more field features, repeat step 2 through 4. Touch OK to finish configuring features and return to the main screen.
  • Page 185 Advanced Settings and Features Customizing the Coverage Map Displays To customize the coverage map display from the Viper Pro main screen, touch Menu and then select Setup, Maps, and Cov Map. The Coverage Maps Colors screen displays. Touch within the maximum rate OK field and use the on-screen keyboard to enter the maximum percentage of the target application rate acceptable for the application.

  • Page 186: Prescription (Rx) Maps

    In order to control multiple products according to a prescription map, a multi-product activation key must be entered on the Viper Pro. Contact a local Raven dealer to obtain a multi-product VRA activation key and refer to the Registering the Viper Pro section on page 23 for information on entering activation keys on the Viper Pro field computer.
  • Page 187 For best results, prescription maps used with the Viper Pro should contain as few rate zones as possible. Maps with too many zones may affect performance of the field computer during the application. Raven recommends that the smallest zone(s) contained within the prescription map should be no smaller than the width of the boom or implement applying product.
  • Page 188 Chapter 7 Prescription (Rx) Map Colors The rate zone colors displayed on a prescription map may be customized for different applications or to suit the equipment operator’s preferences. Note: If no color template is selected by the operator, the Viper Pro will use the default colors. Adding a Prescription (Rx) Map Color Template To add or create a prescription map color template from the Viper Pro main screen, touch Menu, then Setup, Maps, Rx Maps, and Rx Colors.
  • Page 189 Advanced Settings and Features Touch Next. The Rate Range and Color Selection screen will display. In the top field, enter the maximum rate for the lowest rate range displayed on a prescription (Rx) map. Any rate zone within the range between the minimum prescription rate and the value entered in this field will be displayed as the color selected in the following step.
  • Page 190 Chapter 7 Editing a Rx Color Template Touch Menu, then Setup, Maps, Rx Maps, and Rx Colors. The Select Rx Map Colors Template prompt will display. Select Edit. The Select Existing Rx Color Template screen displays. Select an existing template from the list to edit and touch OK. Use the on-screen keyboard to rename the prescription map color template.

  • Page 191: Local Settings

    Advanced Settings and Features Local Settings The Local settings allow the operator to set up preferences for: • Language • Profile Configuration • Units Configuration • Time Zone Configuration Refer to the Initial Set Up section on page 37 for detailed information on setting up these settings and saving a machine profile.

  • Page 192: Serial Communication Port Setup

    Viper Pro and the connected DGPS receiver. The following presets are available to help configure the GPS Comm Port Setup screen: • Generic GPS - for RPR 410, Phoenix 300 and non-Raven receivers or with an optional guidance or steering component (e.g. TM-1 Tilt Module, SmarTrax, etc.) connected between the receiver and field computer •...
  • Page 193 Advanced Settings and Features Generic (Non-Raven) GPS Setup Select the Generic GPS option to configure the Viper Pro to communicate with the following receivers: • Raven RPR 410 • Raven Phoenix 300 • a non-Raven DGPS receiver • if an optional guidance or steering component (e.g. TM-1 Tilt Module, SmarTrax, etc.) is connected between...
  • Page 194 Viper Pro main screen. Note: If the Viper Pro is unable to receive GPS messages from the Raven receiver, refer to Chapter 12, Troubleshooting the Viper Pro System, or contact a local Raven dealer for assistance. OmniSeed™ Viper Pro™ Installation & Operation Manual...

  • Page 195: Console Comm Port Setup

    If the Viper is connected to a CANbus system, skip to the Auxiliary Comm Port Setup section on page 184. Select the following communication settings to communicate with a separate Raven control console: • Baud = 9600 •...

  • Page 196: Auxiliary Comm Port Setup

    Access the Auxiliary Comm Port Setup screen to configure the Viper Pro for communication through the auxiliary port. Note: The Viper Pro will automatically configure the auxiliary comm port settings for an external Raven ® light bar or the Spectrum Technologies WatchDog Sprayer Station.

  • Page 197: Light Bar Guidance

    Light bar guidance features of the Viper Pro may be used to display guidance information on the Viper Pro touch screen or to send guidance information to an external Raven light bar connected to the auxiliary comm port connector on the auxiliary interface cable. The Light Bar Setup screen offers the ability to quickly configure the Viper Pro for either, or both, of these light bar guidance options.

  • Page 198: Configuring The Light Bar Display

    Chapter 7 Configuring the Light Bar Display When the on-screen or external light bar options are enabled, the Viper Pro field computer may be used to configure the light bar display. These settings can help the operator set the accuracy of the light bar for different operations or display preferences.

  • Page 199: Omniseed Section Control

    C h a p t e r 8 Control The Raven automatic section control feature with the OmniSeed system allows the Viper Pro field computer to automatically control section shut off for a single seed section or multiple liquid sections on an air seeder implement.

  • Page 200: Section Control Setup Screen

    Chapter 8 Section Control Setup Screen Touch within the Section Status area on the main screen to begin setting up the system. The Section Control Setup screen will be displayed. Turn-On/Turn Off Look-Ahead Depending upon the type of valve used to control products, control valves may take several seconds to adjust when opening or closing.

  • Page 201: Turn-Off % Coverage

    OmniSeed Section Control Automatic Section Control Override Sec The automatic section control Override feature allows the operator to momentarily apply product to a previously applied area while in a job. The override feature is useful to ensure product application in small unapplied areas near irregular headlands and previously applied areas.

  • Page 202: Enabling Section Control Override

    Using the on-screen keypad, enter a value, in seconds, in the Section Control Override Sec field. During application, toggle the master switch on the Raven CAN switch box to the ‘OVERRIDE’ position. Note: The override feature affects all enabled products. The time set as the override seconds does not start until the master switch returns to the on position.

  • Page 203: Switch Box Setup

    OmniSeed Section Control Switch Box Setup When used with the OmniSeed system, the Raven CAN switch box must be properly configured to control granular and liquid sections appropriately. To check the Raven CAN switch box setup: Touch the Product Control status indicator in the lower, left corner of the main screen.

  • Page 204: Section Control Zone Mapping

    Chapter 8 To set the section control aggressiveness: Touch the Section Status Area on the main screen. From the Section Control Setup screen, touch Next until the Section Control Aggressiveness screen is displayed. Toggle the Section Control Aggressiveness on or off by selecting the radio button on the screen. Touch OK to accept the aggressiveness setting and return to the main screen.

  • Page 205: Create Section Control No-Apply Map Method

    OmniSeed Section Control Create Section Control No-Apply Map Method This method allows the operator to define apply and no-apply zones during the job. The apply/no-apply zones may be created using the scouting features of the Viper Pro field computer. If this method is selected, the Viper Pro prompts the operator to name the zone map that will be created.

  • Page 206: Create Map From Field Boundary Method

    Chapter 8 Create Map From Field Boundary Method This method allows the operator to select an existing field boundary to use in creating a no-apply field boundary. When the Next button is selected, a new screen is displayed showing the names of the fields stored on the Viper internal memory.

  • Page 207: Section Control Apply/No-Apply Maps

    OmniSeed Section Control Section Control Apply/No-Apply Maps A section control apply/no-apply map may be created on the Viper Pro before an actual job or product application using the scouting function or the map may be created during the application. The first step in creating a section control apply/no-apply map is to define the apply and no-apply zones within a field.
  • Page 208 Chapter 8 Once a zone is created, it can be viewed on the Scout tab and on the Section Control tab. The Section Control tab will show all finished zones as well as allow the operator to create the finished zone map when all zones have been defined.

  • Page 209: Remote Calibration Console

    R emote Calibration CHAPTER C h a p t e r 9 Console Overview and Connection The optional tank calibration kit (P/N 117-0171-302) allows the operator to perform all the necessary calibration operations from the air cart making calibration of the OmniSeed system quick and convenient. The remote tank console allows the operator to prime metering rollers and perform the catch test while watching the air cart operation which can help the operator make correct system adjustments prior to starting a seeding operation in a field.

  • Page 210: Console Connection

    Console Power Press the blue power button to power up the remote tank console. Power Button If the console does not power up, check that all connections are secure and that the OmniSeed Viper Pro is powered on. Note: The current program and software version numbers will be displayed while the console initializes during power up.

  • Page 211: Remote Tank Console Operation

    Remote Calibration Console Remote Tank Console Operation The remote tank console allows the operator to prime metering rollers, adjust valve response, perform a catch test and enter the cal weight all while observing operation of the air cart to ensure proper operation of the OmniSeed system.

  • Page 212: Catch Test And Cal Weight

    Chapter 9 Note: The PWM Output, or metering roller speed, will also be used for the catch test procedure, however, the output may not be adjusted during the calibration. Be sure to set the PWM Output during the priming process to ensure the best results. A catch test may now be performed with the primed bin.
  • Page 213 Remote Calibration Console Cal Weight The Metered Weight Page will display automatically at the end of the catch test procedure. This screen displays the number of metering roller revolutions detected during the catch test and allows the operator to enter the weight of product dispensed to calibrate the OmniSeed system. To enter the cal weight value: Use the Left and Right keys to move the cursor below the bin cal weight value to the first digit of the measured cal weight and press the Enter key.

  • Page 214: Using The Remote Tank Console To Adjust Settings

    Chapter 9 Using the Remote Tank Console to Adjust Settings The following settings may be entered using the remote tank console. Settings will be stored in the appropriate nodes on the OmniSeed system and will be registered by the Viper Pro when starting the OmniSeed application for seeding operations.
  • Page 215 Remote Calibration Console Press the Next key on the cal weight option to advance to the next settings screen. Note: The second settings screen is only accessible if the valve type for the selected product bin is set to PWM or PWM close. Refer to the Application and Control Valve Type(s) section on page 40 for detailed information on valve type selections.

  • Page 216: Troubleshooting

    Chapter 9 Troubleshooting Issue Possible Cause Solution • • Remote tank Viper Pro not Power on the Viper Pro and access the Program console will not powered on Selection Menu screen. power on • • Power not provided Check and reconnect 6-pin Deutsch connector. to remote tank •...

  • Page 217: Seed Blockage Sensors

    S eed Blockage CHAPTER C h a p t e r 1 0 Sensors System Overview With the optional seed blockage sensor system, the Viper Pro can be used to monitor seed or product flow during seeding operations. If an obstruction is detected, the field computer will display information from the sensors to help the operator quickly locate the obstruction.

  • Page 218: Seed Blockage Node Detection

    If the seed blockage node is not displayed on this screen during start up, check the node connections and touch the Retry CAN Init button before starting the Viper Pro application. If the node is still not detected, contact a local Raven dealer for assistance. Configuring Blockage Sensor Loops To properly monitor the seed delivery system, the Viper Pro must be configured for the number of seed blockage sensors installed in each section of the drill.

  • Page 219: Seed Monitor Setup

    Seed Blockage Sensors Touch the Number Sensors field and use the on-screen keypad to enter the number of sensors in loop 1 for each configured section of the drill. Note: Only enter values for the number of configured sections on the drill. Leave the value at zero for any unused sections.
  • Page 220 Chapter 10 Sensitivity. Use the sensitivity value to set the approximate number of seeds per second which each sensor in the loop should detect when the system is operating normally. If a sensor does not detect the set value for seeding rates, the system will display a blockage or obstruction and indicate which sensor is detecting the error.

  • Page 221: Setting The Sensitivity

    Seed Blockage Sensors Setting the Sensitivity Refer to the following table to set and adjust the sensitivity setting for each loop for a specific seeding operation. Sensitivity Seeds per Second Sensitivity Seeds per Second (cont.) (cont.) Loop off 1 seed every 30 seconds 1 seed every 20 seconds...
  • Page 222 Chapter 10 OmniSeed™ Viper Pro™ Installation & Operation Manual...

  • Page 223: File Maintenance And Editing Reports

    F ile Maintenance and CHAPTER C h a p t e r 1 1 Editing Reports Overview File Maintenance can be defined as the process of archiving specific files from the Viper Pro and deleting files that are no longer needed. It is recommended that the user perform this maintenance at the end of each day. If this is not possible, maintenance should be performed at least once a week.

  • Page 224: Preparing A Usb Flash Drive For File Maintenance

    Chapter 11 If a Slingshot Field Hub is connected to the Viper Pro, files may also be transferred wirelessly to the Slingshot web site. A user account will be required to access files transferred to the Slingshot web site on a home or office PC.
  • Page 225 File Maintenance and Editing Reports The following screen will display. Select Initialize External Storage. The following screen will display. Touch OK. The necessary file folders will be loaded onto the thumb drive. Touch OK to return to the File Maintenance main menu. The USB flash drive will now be populated with the necessary file folders needed by the Viper Pro.

  • Page 226: Flash Drive File Structure

    Chapter 11 Flash Drive File Structure The USB flash drive will be populated with the following file folder structure. Note: If the USB flash drive was initialized with an older version of software, an Rbin folder may also be available. This folder would contain any Rbin files from the Viper Pro. This file is not used with newer software versions and may be deleted if desired.
  • Page 227 File Maintenance and Editing Reports AutoBoom Alarms Sub-folder. Not used with a seeder control system. BoundaryShp. The boundaryShp folder contains any shapefiles for field boundaries created using GIS software and transferred to the Viper Pro field computer. Note: Field Boundaries created using the Viper Pro are saved as a part of the job file. Clone.

  • Page 228: Performing File Maintenance

    Chapter 11 Performing File Maintenance Viper Pro provides flexible options for managing and maintaining files stored on the Viper Pro field computer. To access the File Maintenance feature: Touch Menu on the Viper Pro main screen. Select File Maint. The following file maintenance options will be displayed. OmniSeed™...

  • Page 229: Wireless File Transfer

    This feature is not supported at this time. Job Notifications If the field computer is registered with a Raven Slingshot account capable of receiving job notifications, the field computer may be enabled to send notifications of job events to a third party (e.g. office data management server) via the Slingshot server.

  • Page 230: Uploading Prescription Maps From A Usb Flash Drive

    Chapter 11 Web Notifications If the field computer is registered with a Raven Slingshot account capable of sending web notifications, the field computer may be enabled to receive web notifications from a third party (e.g. office data management server) via the Slingshot server.

  • Page 231: Usb File Transfer And Advanced File Maintenance

    File Maintenance and Editing Reports USB File Transfer and Advanced File Maintenance The USB File Transfer feature allows the machine operator to select specific files to copy, move or delete from a connected USB drive or internal memory. Note: Completed job files transferred to a USB flash drive may be uploaded to the Slingshot web site using a free user account.
  • Page 232 Chapter 11 Selecting an Operation to Perform Once the type of file is selected, the Select Operation to Perform selection displays. Select: • Copy - Makes a copy of the selected file on the destination storage location. Copied file is retained on the source storage location.

  • Page 233: Initialize External Usb Flash Drive

    File Maintenance and Editing Reports Selecting File Selection Method Next, select the method to select specific files. • By Age - Select the “by Age” option to set an age for files which the action will be performed upon. The operation will be automatically selected and copied, moved, or deleted. •...

  • Page 234: Automatic File Maintenance

    Chapter 11 Automatic File Maintenance Note: Do not use the Automatic File Maintenance feature to create reports for a Slingshot account. The Automatic File Maintenance feature does not export the types to a USB flash drive necessary for creating Slingshot reports and will remove job data from the Viper Pro. Job data transferred using the Automatic File Maintenance feature cannot be reinstalled onto the field computer for export to Slingshot.

  • Page 235: Clone Or Restore Settings

    File Maintenance and Editing Reports Clone or Restore Settings The Clone or Restore Settings feature can be used to save all settings and files from the Viper Pro field computer to external memory. These clones can then be reloaded to restore settings to the same Viper Pro or transferred to another Viper Pro.

  • Page 236: Agx File Maintenance

    Note: The AgX File Maintenance button will not be displayed unless an AgX activation key has previously been entered on the Viper Pro. Contact a local Raven dealer for more information or to acquire an activation key. Select the AgX File Maintenance option to transfer AgX recommendations to the Viper Pro from a connected USB flash drive or to delete recommendations currently stored on the Viper Pro field computer.

  • Page 237: Uploading Reports To The Slingshot Web Site

    Using the Slingshot Field Hub If a Slingshot Field Hub is connected to the Viper Pro, completed job files may be transferred to the Raven Slingshot web site wirelessly. Refer to the Wireless File Transfer section on page 217 for details on setting up file transfer options.

  • Page 238: User Account Sign-Up

    Chapter 11 User Account Sign-up To set up a free user account: Access the Raven Slingshot web site: www.ravenslingshot.com Note: To request a form for multiple user accounts, send an email request to: info@ravenslingshot.com Select the desired language in the upper, left corner of the site.

  • Page 239: Uploading Job Reports From A Usb To The Slingshot Web Site

    Slingshot. Refer to the USB File Transfer and Advanced File Maintenance section on page 219 for instructions on outputting the necessary file types. Insert the USB flash drive into a home or office PC and login to the Raven Slingshot web site at: www.ravenslingshot.com Select the desired language in the upper, left corner of the site.
  • Page 240 Chapter 11 OmniSeed™ Viper Pro™ Installation & Operation Manual...

  • Page 241: Troubleshooting The Viper Pro System

    T roubleshooting the CHAPTER C h a p t e r 1 2 Viper Pro System This chapter contains information on troubleshooting the Viper Pro system. Please read through all sections in this chapter before contacting technical support, as many common questions are answered here. Viper Pro Troubleshooting Information This section contains information about possible issues and solutions for the Viper Pro system.

  • Page 242: Setup Issues

    Chapter 12 Issue Possible Cause Solution • GPS cable disconnected • Check the cable between the GPS receiver and the Viper Pro. Red DGPS Status • No power to the GPS • Check power to the GPS receiver. indicator on the receiver Main Screen •...

  • Page 243: Job Issues

    Troubleshooting the Viper Pro System Job Issues Issue Possible Cause Solution • Section switches are • Turn section and master switch on. turned off Section numbers • Section control enabled are gray • Move the machine out of the applied zone. but machine not moving •...

  • Page 244: Rx Map Issues

    Possible Cause Solution Only one • A multi-product VRA prescription map registration is not • Purchase a multi-product registration from a local Raven dealer. available loads The prescription map does not • Wrong datum type • Use WGS-84 decimal degrees when creating an Rx map.

  • Page 245: Error Messages

    The Activation key is • Incorrect Activation key • Re-enter the Activation key. If this still does not work, entered contact a local Raven representative. not valid • Scout file for one of the • Touch OK to bypass. jobs is missing Scout file error •...

  • Page 246: Job Error Messages

    Chapter 12 Job Error Messages Issue Possible Cause Solution • For non-VRC (Variable Rate Control) jobs, Open New Job error DGPS coverage must be • Check for GPS signal. available before starting the job No GPS Coverage Warning: You must •...

  • Page 247: Gps Error Messages

    Troubleshooting the Viper Pro System Issue Possible Cause Solution • VRC was selected for the No Rx file chosen product during the • Un-select the VRC selection or load an Rx map for the product setup, but no Rx product. for this product map was loaded •...

  • Page 248: Can Troubleshooting

    Chapter 12 CAN Troubleshooting Although the control algorithm is located within the CAN node, all of the same troubleshooting techniques used in a traditional hard-wired system still apply to a CAN system. CAN allows for modularization of the control system, but the behavior of the system remains the same. Flow and speed sensors, as well as the control valve and section valves, are used in the same fashion.
  • Page 249 The following diagrams may show optional features or components not required for operation and will not apply to all systems if the required hardware has not been installed. Contact a local Raven dealer for purchasing or more information on components shown in the following diagrams.
  • Page 250 Appendix A OmniSeed System Diagram (3 Bin) (D/N 054-5010-003) FIGURE 1. OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 251 OmniSeed System Diagram (3 Bin) (D/N 054-3001-026) FIGURE 2. Manual No. 016-3001-015 Rev. C...
  • Page 252 Appendix A Raven Product Controller Node Multi-Product Control System (1 of 2) (D/N 054-5100-004) FIGURE 3. OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 253 Raven Product Controller Node Multi-Product Control System (2 of 2) (D/N 054-5100-004) FIGURE 4. Manual No. 016-3001-015 Rev. C...
  • Page 254 Appendix A Seed Blockage Sensor Cabling (Less than 60 Sensors) (D/N 054-5002-002) FIGURE 5. OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 255 Seed Blockage Sensor Cabling (More than 60 Sensors) (D/N 054-5002-002) FIGURE 6. Manual No. 016-3001-015 Rev. C...
  • Page 256 Appendix A OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 257 Note: The GPS speed over CANbus feature is only available with specific Raven speed sense nodes. This feature utilizes NMEA speed over ground data transmitted over the CAN network which eliminates the need for a separate, external speed sensor.
  • Page 258 Appendix B Touch within the Miscellaneous Settings area on the CAN Controller Status screen. The Miscellaneous Settings screen will display. Touch the Calibration Assistance button on the Miscellaneous Settings screen. The Speed Calibration screen will appear. Mark off the physical distance to be driven for the test. Enter a measured test distance, in feet [meters], in the Test Distance box.
  • Page 259 Drive the test distance. At the end of the measured test distance, touch the End Cal Run button. The new speed cal value will be calculated automatically. Touch Yes and the new speed cal will be applied. Note: Touch No to discard the calculated speed cal and continue using the existing value. Verification of the Speed Cal Value The following procedure may be used to verify the speed cal currently entered on the field computer.
  • Page 260 Appendix B Touch the Reset button next to the Distance display on the Tally Registers screen. Drive a known distance: Re-run the same test distance driven during the Calibration Assistance procedure. Drive a test distance of 1 mile [1 km]. Note: Accelerate and decelerate slowly.
  • Page 261 Wheel Drive Speed Sensor Mark the tire on which the speed sensor is installed using chalk or a piece of tape as shown below. Mark the corresponding spot on the ground. Count 10 full revolutions of the wheel while traveling in a straight path. The mark must stop with the chalk or tape in the same orientation that it began at the starting point.
  • Page 262 Appendix B Boom Cal or Section Width Calibration Use the following formulas to calculate the section width(s) of a boom or implement. The section width is used by application control systems to adjust product rates for active sections during application. Calculate the boom section width with the formula: ×...
  • Page 263 Touch the Next button if necessary to display ‘Wired As’ and ‘Display Character’ settings for sections 6 through 10. Use the ‘Wired As’ column to set the actual boom sense wired connection for each configured section. Note: Raven boom sense wires are color coded as follows: Section Lead Wire Section...
  • Page 264 Appendix B Boom Mapping Example TABLE 1. Display Logical Wired As Character The “Switch Number” column to assign section control to a specific switch on a connected CAN switch box. Multiple sections may be assigned to the same switch to allow the operator to control multiple sections. Touch OK to return to the Boom Setup Summary screen.
  • Page 265 Advanced Section Setup The standard boom setup covered in the Section Setup section on page 53 is sufficient for a standard boom configuration with the sections end-to-end with no overlap or skips. The advanced section settings allow the operator to customize boom or implement sections individually to reflect specialized configurations with overlaps, skips or offset sections.
  • Page 266 Appendix B Touch the Fore/Aft offset value and use the on-screen keypad to enter the distance of the section midpoint from the GPS antenna. If the section is behind the GPS antenna, enter a negative value for the Fore/Aft offset value. Touch Next to advance to the next boom or implement section to the right or Prev to go back to the previous section to the left.
  • Page 267 Valve Cal To ensure that the proper amount of product is being applied, the valve cal must be programmed for the type of control valve(s) connected to the control system. The field computer uses the valve calibration number to adjust the response time of the control valve motor to changes in the vehicle speed. The following control valve calibration numbers are recommended for the valves listed: Control Valve Type Valve Cal...
  • Page 268 Appendix B Flow Cal (Dual Loop Control Mode) The flow cal value has two components which may be used to adjust the response of the application system. Dead Band Percentage Flow System Gain Note: It is recommended to set the Sgain value prior to making any adjustments to the flow cal value. Flow System Gain.
  • Page 269 PWM Control Valve Tuning The Viper Pro field computer provides three methods for fine tuning a PWM or PWM close valve used for controlling product application: PWM Manual Calibration The operator may enter the known values for the following PWM valve calibration settings within the Product Control Settings area: •...
  • Page 270 Appendix B Touch Next. Note: The PWM Manual Cal and Auto Cal buttons will be displayed only if a PWM or PWM Close is the selected valve type. See the Application and Control Valve Type(s) section on page 40 for more information on the valve type selection.
  • Page 271 Touch the Set Min PWM button to enter the minimum PWM setting. Note: It is recommended to reduce the PWM minimum value by 10 to allow a small dead band during actual field applications. Touch the Next button. The Max PWM Calibration screen will display. Liquid Granular The Max PWM Calibration screen will display the current maximum PWM value as well as the current...
  • Page 272 Appendix B PWM Automatic Calibration The automatic calibration mode will allow the field computer to automatically adjust the PWM output and attempt to determine the minimum, maximum and preset values. WARNING The PWM valve output will increase and decrease during the calibration process. Keep away from areas where product may be expelled and moving components and alert anyone around the equipment when performing...
  • Page 273 The following procedure should be performed more frequently if the flow meter is used with harsh chemicals or in anhydrous ammonia. Remove the flow meter from the application system and flush with clean water. If necessary, dismantle the flow meter housing. Remove the turbine hub and turbine from the flow meter.
  • Page 274 Appendix B Dispense exactly 10 gallons [38 L] through the flow meter as measured by the calibrated catch container. Important: Do not rely on graduation markings/numbers molded into the applicator tank. Toggle the section or master switch off. Read the value displayed on the field computer Total Volume button. This value should be within ± 3% of the meter cal value printed on the flow meter tag.
  • Page 275 Rate Cal The product rate cal value is entered in gallons per acre [L/ha] for liquid application systems or in pounds per acre [kg/ha] for granular applications. Liquid Applications and Spray Nozzles Enter the desired target volume per minute of liquid product for the application. Refer to Unit of Measure Conversions section on page x or contact a local sprayer or chemical supply dealer for more assistance.
  • Page 276 Appendix B Verifying Flow Rate Limits The target rate for an application must be within the range of that specified for the Raven flow meter installed. Average Meter Flow Meter Model Flow Range Cal Value RFM 5 0.05 - 5 GPM [0.2 - 18.9 lit/min]...
  • Page 277 T esting Extension APPENDIX A p p e n d i x C Cables Speed Sensor Extension Cable Verify that the system is in the Wheel Speed Sensor mode while testing the cable. Disconnect the extension cable from the speed sensor assembly cable. Hold the extension cable connector so that the keyway is pointing in the 12 o’clock position as shown below.
  • Page 278 Appendix C Testing the Speed Sensor Cable Press Product Control. Press the Miscellaneous box. Enter 1000 as the Speed Cal and touch OK. Press OK to return to the CAN Controller Status screen. Press Tally Registers. Press the Reset button next to the Distance box. With a small jumper wire (or paper clip), short between 10 o’clock and 6 o’clock sockets with a ‘short-no- short’...
  • Page 279 Flow Meter/Encoder Extension Cables Before starting this test, disconnect the flow meter cable from the flow meter. Hold the flow meter cable so that the keyway is pointing in the 12 o’clock position as shown below. Flow Meter Extension Cable Pin Diagram FIGURE 2.
  • Page 280 Appendix C Note the ‘Ttl Vol’ (total volume) column and the registered values for each control channel. Toggle the section switches and the master switch on. With a small jumper wire (or paper clip), short between the 2 o’clock and 6 o’clock sockets with a ‘short-no- short’...
  • Page 281 To retain settings and calibration data, be sure to write down all settings stored by the node(s) being updated. The CAN Update program and node updates are available on the Raven web site: www.ravenhelp.com To Update CAN Nodes Start the Viper Pro and access the Program Selection Menu screen.
  • Page 282 Appendix D On the Program Selection Menu screen, select the option labeled “Update CAN Nodes” to begin the CAN Update Program. The Update CAN Nodes screen displays a list of available node updates. This screen also displays the firmware version to which each node will be updated if the update is applied. Available Node Updates Firmware Version...
  • Page 283 To start the node update: If a non-product node (i.e. Raven Switch Box, Drill Cart) is selected, touch the Start button in the lower right corner of the screen to begin the update.
  • Page 284 Appendix D OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 285 A p p e n d i x E Program with the Viper Pro System The Front Panel Program may be used to configure Raven DGPS receivers only (e.g. Invicta 110, 115, or Phoenix 200™). Initializing the Front Panel Program Press Front Panel from the Program Selection Menu.
  • Page 286 Viper Pro touch screen. Note: Refer to the Operation Manual or Quick Start Guide for the specific Raven receiver used with the Viper Pro field computer. These documents may also be found on the Raven Applied Technology Division web site: www.ravenhelp.com/...
  • Page 287 L oad Cells APPENDIX A p p e n d i x F The Viper Pro is capable of interfacing with Digi-Star load cell systems to monitor the weight of product remaining in a bin during field operations. To configure the Digi-Star load cell system: Touch the Product Control area at the bottom of the Viper Pro main display screen.
  • Page 288 Appendix F Setup Number. Refer to the Digi-Star load cell system documentation for information on the setup number. Calibration Number. Refer to the Digi-Star load cell system documentation for information on the calibration number. Node ID. Displays the Digi-Star scale link node identification number. Scale ID.
  • Page 289 In order to use the weather station with the Viper Pro system, the weather module activation key (P/N 077-0180-030) must be purchased from a Raven dealer. Once the key has been purchased and registered on-line, the activation key must be entered into the Viper Pro. See Chapter 3, Installation, Start Up, and Registration, for help with registering and entering this information.
  • Page 290 Console’ connector on the Viper Pro main interface or chassis interface cable. If the Viper Pro is connected to an external Raven serial controller, the weather station must be connected to ‘COM 3/Light bar’ on the Viper Pro auxiliary interface or chassis interface cable.
  • Page 291 To view weather information, touch the Display Data button on the lower right hand side of the Viper, and then touch in the data area to toggle to the weather information. Note: If the Wind Direction heading displayed in the Weather Information does not appear as expected, re-initialize the Weather Station as described in the Comm Port Configuration section on page 278.
  • Page 292 Appendix G OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 293 W ireless APPENDIX A p p e n d i x H Communications and Remote Service The Viper Pro field computer, with a Slingshot Field Hub, allows the operator to wirelessly transfer application data back to the home or office and transfer prescription data from the office to the field without the hassle of driving back and forth between locations.
  • Page 294 Appendix H The following icons may be displayed in the wireless status area: No Device Connected - No supported wireless device is connected to the ethernet port on the Viper Pro. This icon is also displayed if wireless communication is unavailable or has been lost.
  • Page 295 The service technician will be able to determine whether a remote service session is necessary to assist with any issues encountered with the Viper Pro field computer. Contact a local Raven dealer or technical service provider before starting the remote service feature.
  • Page 296 Appendix H Comm. Status Tab The connection status tab displays the following information: • Current Alarms - Any current communication errors or alerts are displayed in this area. • Signal Strength - Displays bars to represent the current strength of wireless signal. Four bars represent a strong signal.
  • Page 297 File Manager Tab Access the File Manager tab to view a history of files recently transferred to or from the Viper Pro field computer. Use the up or down arrows to scroll through the history of files sent from, or received by, the Viper Pro. Touch a file from one of the lists to view file information such as the file type and size as well as the date and time the file was sent or received.
  • Page 298 Appendix H Registration Tab The Registration tab is used to register the Field Hub with the Slingshot web service and activate the various features of wireless communication on the Viper Pro field computer. Note: If the Field Hub has been registered previously, the Viper Pro will display the registration status above the “Registration Code”...
  • Page 299 Touch the “Registration Code” button to register the device on the Slingshot site. A registration code will automatically be sent to the Slingshot site. After Slingshot receives the code, the device is registered. www.ravenslingshot.com Note: Be sure to enable the Remote Service and Web Access features if desired (recommended). These features may be enabled later by accessing the Slingshot site.
  • Page 300 Appendix H OmniSeed™ Viper Pro™ Installation & Operation Manual...
  • Page 301 Comm Port Setup Console 183 Comm Port Setup 180 GPS 180 DGPS Receiver Connection 16 Console Comm Port Setup Error Messages 235 Generic (Non-Raven) GPS Setup 181 Cov Tab Raven GPS Setup 182 Coverage Maps Status Display 81 Accessing Information 108 Guidance...
  • Page 302 Index Hydraulic Off-Swath Direction Safety 2 Off-Swath Distance On-Screen Lightbar, Configuring Overview Important Safety Information Electrical 2 Hydraulics 2 Performing File Maintenance Importing a Field Boundary Power Connection Initial Set Up and Navigation Preparing a USB Thumb Drive Installation, Start Up & Registration for File Maintenance Introduction Prescription (Rx) Maps...
  • Page 303 Index Program Selection Menu Swath Programming Number 132 Patterns 126 Edit Mode x Swath Guidance 152, 155 System Diagrams Re-Addressing Product Nodes Tabs Rear Panel Tally Registers ReCal A-B Button Resetting 115 Registration Keys and Feature Activation Testing the Flow Meter Cables Reset A-B Button Testing the Speed Sensor Extension Cable...
  • Page 304 Index OmniSeed™ Viper Pro™ Calibration & Operation Manual...
  • Page 305 Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval. The freight cost to Raven Industries will be the customer’s responsibility. The Return...
  • Page 306 How Can I Get Service? Bring the defective part and proof of purchase to your Raven dealer. If the dealer approves the warranty claim, the dealer will process the claim and send it to Raven Industries for final approval.
  • Page 308 Fax: 605-331-0426 www.ravenprecision.com www.ravenhelp.com Notice: This document and the information provided are the property of Raven Industries, Inc. and may only be used as authorized by Raven Industries, Inc. All rights reserved under copyright laws. ©Raven Industries, Inc. 2009, 2011, 2014...

Table of Contents

Save PDF
