  • Page 1 Picture in Picture Converter (NTSC Only) ID# 821 Operation Manual...
  • Page 2 Introduction Picture in Picture box with built-in TV receiver which allows you to watch two video inputs at the same time, on the same display. The unit will display a main picture, and a sub-picture. This unit is suitable only with NTSC type signals.
  • Page 3 Rear Panel RF input : Input connector for CATV cable or TV antenna. A /V out pu t: Ou tp ut conn ec t ors f or Vi de o/ Au di o out . A/V inputs: Input connectors for Video/Audio 1 source. A/V inputs: Input connectors for Video/ Audio 2 source.
  • Page 4 Specifications DC Power 15V/600 mA /NTSC OR (15V/1.5A/PAL Ω RF input NTSC 75 , Coaxial cable 50m Vp-p Audio input 300 mVp-p Ω Video output 2 Vp-p, 75 Audio output 300 m Vp-p Weight 500 g Dimensions 290 (W) X 180.5 (D) X 48.8 (H) mm Connection and Installation...
  • Page 5 TV Frequency Table (U.S) Air Channel Pix Carrier Pix Carrier Channel Channel (MHz) ( MHz) 55.25 603.25 61.25 609.25 67.25 615.25 77.25 621.25 83.25 627.25 175.25 633.25 181.25 639.25 187.25 645.25 193.25 651.25 199.25 657.25 205.25 663.25 211.25 669.25 471.25 675.25 477.25 681.25...
  • Page 6 CATV Frequency Table (U.S.) Cable Channel Pix Carrier Pix Carrier Channel Channel (MHz) ( MHz) 73.25 277.25 55.25 283.25 61.25 289.25 67.25 295.25 77.25 301.25 83.25 307.25 175.25 313.25 181.25 319.25 187.25 325.25 193.25 331.25 199.25 337.25 205.25 343.25 211.25 349.25 121.25 W+10...
  • Page 7 CATV Frequency Table (U.S.) Cable Channel Pix Carrier Pix Carrier Channel Channel (MHz) ( MHz) 469.25 97.25 475.25 103.25 481.25 109.25 487.25 115.25 493.25 649.25 499.25 655.25 505.25 661.25 511.25 667.25 517.25 673.25 523.25 679.25 529.25 685.25 535.25 691.25 541.25 697.25 547.25 703.25...
