Bi-directional Parallel Port : Configurable to LPT1, LPT2, LPT3 or
disabled. Supports EPP/ECP/SPP
•
IrDA port : Supports Serial Infrared(SIR) and Amplitude Shift
Keyed IR(ASKIR) interface.
•
USB port : Supports USB port for future expansion.
•
Watch-dog timer : can be set by 1~255 seconds period. Reset or
NMI is generated when CPU does not periodically trigger the timer.
•
Flash Disk Socket: the DiskOnChip™ compatible 32-pin dip socket
is provided for Flash Disk ( DiskOnChip™ ) application which will let
users to use the Flash Disk with DOS command. without any extra
software utility.
•
Keyboard and PS/2 mouse connector : A 6-pin mini DIN connector
is located on the mounting bracket for easy connection to a keyboard
or PS/2 mouse. For alternative application, a keyboard pin header
connector is also available on board, located on CN13.
•
Power Consumption : +5V @ 6A ,+12V @ 170mA , -12V@60mA
( Pentium® MMX-200,32MB SDRAM)
•
Operating Temperature : 0 ° ~ 55 ° C ( CPU needs Cooler)

1.2 What You Have

In addition to this User's Manual , the ROCKY-058HV package
includes the following items:
•
ROCKY-058HV
•
One RS-232 and Printer Cable with bracket
•
One FDD Cable
•
One HDD Cable
•
One 6-pin Mini-Din converts to two 6-pin Din cables for
keyboard and mouse connection.
If any of these items are missing or damaged, contact the dealer
from whom you purchased the product. Save the shipping
materials and carton in case you want to ship or store the product
in the future.
