1.1 Specifications :

The ROCKY-058HV Pentium w/ VGA Single Board Computer
provides the following specifications:
•
CPU : Pentium® MMX up to 233Mhz, AMD K5/K6/K6-2/K6-3
processor up to 400Mhz, Cyrix 6x86MX processor
•
Bus Interfac
•
Bus Sp
•
DMA Channels : 7
•
Interrupt Levels : 15
•
Chipset : SIS 5598
•
VGA : Built-in the SIS 5598 Chipset
•
Real-time clock / calendar : SGS M4T28 or equivalent device.
•
RAM memory : up to 128MB SDRAM
•
Second Cache memory : 512KB Pipelined Burst SRAM on board
•
Ultra DMA/33 IDE Interface : up to two PCI Enhanced IDE hard
drives. The Ultra DMA/33 IDE can handle data transfer up to 33MB/s.
The compatibility with existing ATA-2 IDE specifications is its best
advantage, so there is no need to do any change to users current
accessories.
•
Floppy disk drive interface : Support up to two floppy disk drives,
5.25"(360KB and 1.2MB) and/or 3.5" (720KB, 1.44MB, and 2.88MB) .
•
Series ports : Two RS-232 ports with 16C550 UART ( or compatible)
with 16-byte FIFO buffer. Support up to 115.2Kbps. Ports can be
individually configured to COM1, COM2 or disabled.
e : ISA bus
eed : ISA 8MHz
Resolution : 1280x1024,256 colors,75Hz
1024x768, 64K colors,75Hz
800x600,full colors,90Hz
More information : www.sis.com.tw
