ICP Electronics ROCKY – 058HV Manual page 11

• JP8 CPU Core Voltage Setting :
CPU Core
Voltage
3.5V(P54C/CS)
VRE
3.4V(P54C/CS)
STD
3.3V
3.2V
3.1V
3.0V
2.9V
2.8V (P55C)
2.7V
2.6V
2.5V
2.4V
2.3V
2.2V
2.1V
2.0V
• JP7 Dual / Single CPU Voltage setting :
Vcore & VIO
Pentium
(P54C)
Pentium MMX
AMD K6
Cyrix 6x86MX
Dual Voltage
JP8 JP8
1-2 3-4
CLOSE CLOSE
OPEN CLOSE
CLOSE OPEN
OPEN OPEN
CLOSE CLOSE
OPEN CLOSE
CLOSE OPEN
OPEN OPEN
CLOSE CLOSE
OPEN CLOSE
CLOSE OPEN
OPEN OPEN
CLOSE CLOSE
OPEN CLOSE
CLOSE OPEN
OPEN OPEN
1-3 2-4
OPEN OPEN
CLOSE CLOSE
9
JP8 JP8
5-6 7-8
CLOSE CLOSE
CLOSE CLOSE
CLOSE CLOSE
CLOSE CLOSE
OPEN CLOSE
OPEN CLOSE
OPEN CLOSE
OPEN CLOSE
CLOSE OPEN
CLOSE OPEN
CLOSE OPEN
CLOSE OPEN
OPEN OPEN
OPEN OPEN
OPEN OPEN
OPEN OPEN
3-5 4-6
CLOSE CLOSE
OPEN OPEN
