Appendix B. I/O Address Map

• I/O Address Map
I/O Address Map
000-01F
020-021
040-05F
060-06F
070-07F
080-0BF
0A0-0BF
0C0-0DF
0F0-0F0
0F1-0F1
0F8-OFF
170-1F7
278-27F
2E8-2EF
2F8-2FF
376-376
378-37F
3B0-3DF
3E8-3EF
3F2-3F5
3F8-3FF
443
843
DMA Controller #1
Interrupt Controller # 1, Master
System Timer
Standard 101/102 keyboard Controller
Real time Clock, NMI Controller
DMA Page Register
Interrupt Controller # 2
DMA Controller # 2
Clear Math Coprocessor Busy
Reset Math Coprocessor
Math Coprocessor
VIR BUS Master PCI IDE Controller
Parallel Printer Port 2 (LTP3)
Serial Port 4
Serial Port 2
VIR BUS Master PCI IDE Controller
Parallel Printer Port 1
Standard AGP Graphic Adapter
Serial Port 3
Floppy Disk Controller
Serial Port 1
Watch dog timer enable
Watch dog timer disable
Description
29
