Summary of Contents for Eneo TER-12N040200A
-
Page 1: User Manual
User Manual Hybrid Video Recorder, HD-TVI, 4-16 Chan- nels, 1920x1080, 960H, SD TER-Series... -
Page 2: Safety Information
User’s Manual | 2 Safety Information The safety information is provided for the wellness of the equipment and for the safety of the operator. Please review and observe all instructions and warnings in this manual. Note : Keep this manual handy every time you operate this equipment. Also, check with your dealer for further assistance and for the latest revision of this manual. -
Page 3: Table Of Contents
3 | Full HD Digital Video Recorder Contents DVR U ANUAL ETTING TARTED 1.1 Checking Supplied Items 1.2 Connecting Peripheral Device 1.3 System Startup and Shutdown XPLANATION FOR UNCTION 2.1 Front Panel 2.2 Rear Panel PERATION 3.1 User Log-in 3.2 Live Display Mode 3.3 PTZ Operation 3.4 Playback of Recorded Video 3.5 Search Recording Image... - Page 4 User’s Manual | 4 DVR U ANUAL...
-
Page 5: Getting Started
5 | Full HD Digital Video Recorder ETTING TARTED 1.1 Checking Supplied Items Make sure that you have the following items supplied with your DVR. If any of these items are missing or damaged, notify your vendor immediately. Keep the packing utilities for moving or storage purposes afterwards. Items Photo Quantity... - Page 6 User’s Manual | 6 Remote control 1 pcs Rack mount 1U size 1set Rack mount 1.5U size 1set...
-
Page 7: Connecting Peripheral Device
2.5~3U (1U=1.75 inch or 4.45 cm) space for proper ventilation. Install the system in a location with good ventilation to prevent overheating. TER-12N040200A Dimensions: 11.0” W x 1.9” H x 9.6” D TER-22N080300A Dimensions: 14.1” W x 2.6” H x 14” D... - Page 8 User’s Manual | 8 TER-22N160300A Dimensions: 14.1” W x 2.6” H x 14” D ※When connecting power cord to the system, it is strongly recommended first to plug the power cord to ARNING the system and then plug the other side of power cord into the wall socket.
-
Page 9: Camera Connection
9 | Full HD Digital Video Recorder CAMERA CONNECTION Example 1) All TVI 1080P/720P Example 2) All AHD 1080P/720P or Analog 960H Example 3) CH 1, CH 2 : TVI 1080P/720P CH 5, CH 6 : TVI 1080P/720P CH 3, CH 4 : AHD 1080P/720P or Analog 960H CH 7, CH 8 : AHD 1080P/720P or Analog 960H TVI only Type - Please refer to the example 1) AHD only Type - Please refer to the example 2) -
Page 10: System Startup And Shutdown
User’s Manual | 10 1.3 System Startup and Shutdown 1.3.1 System Startup After connecting peripheral devices such as cameras, monitors and a mouse to the DVR, power up the DVR by connecting DC12V 3A adaptor to the power jack on the rear panel. The boot log will display as shown below. Please wait until the boot process completes. - Page 11 11 | Full HD Digital Video Recorder 1.3.2 System shutdown and change password Option 1. Click the Shutdown button and input password on pop-up to power off the DVR Option 2. Click the right button on the mouse and select the Shut Down to power off the DVR. It is not recommended to disconnect the power cable abruptly from the back of the DVR because it may affect the DVR and Hard Drive.
-
Page 12: Explanation For Each Function
User’s Manual | 12 XPLANATION FOR UNCTION 2.1 Front Panel TER-12N040200A Front Panel TER-22N080300A / TER-22N160300A Front Panel Items Functions System status LED indicators Green = The system is powered and ON. LED Indicator Red = The system is currently recording... -
Page 13: Rear Panel
13 | Full HD Digital Video Recorder USB Port USB Port (Ver. 2.0) for Mouse Operation, Backup Device or Firmware Update 2.2 Rear Panel TER-12N040200A Rear Panel TER-22N080300A Rear Panel TER-22N160300A Rear Panel... - Page 14 User’s Manual | 14 Name Description Video-In Camera inputs (Supports NTSC/PAL) Audio-In Audio Input Device (with Amplifier) Audio-Out Audio Output Device (with Amplifier) USB Port USB 2.0 Port for Mouse Operation, Backup Device, or Firmware Update HD OUTPUT HD OUTPUT LAN Port 1 x 10/100/1000M Power Input...
-
Page 15: Operation
15 | Full HD Digital Video Recorder PERATION 3.1 User Log-in The DVR has various setting categories. The administrator can set the system password and <User> to prevent unauthorized changes to setting values and alteration of recorded file. Enter the <Admin> or <User> password which had been set by using the virtual keyboard. 1) <LOGIN>... -
Page 16: Live Display Mode
User’s Manual | 16 3.2 Live Display Mode 3.2.1 Full HD(1080p) Live Display Full HD Live Display can be supported in live mode by using its HD output. In playback mode, the maximum resolution is 1080P. <Full HD Live Display>... -
Page 17: Channel Selection
17 | Full HD Digital Video Recorder 3.2.2 Channel Selection Channel selection can be done by following one of the steps below: CH1~CH16 buttons in the IR Remote Control. 1~16 virtual buttons at the bottom of the GUI display. The display mode can be changed by pressing the ‘MODE’ button on the DVR’s front panel. The live images can be displayed in real-time in 1, 4, 9, 16 screen splits. - Page 18 User’s Manual | 18 3.2.3 Icons The live mode display’s icons or messages will be indicated on the screen to indicate the system mode or status. Below are the icon categories that are indicated on the monitor: Icon to be shown Icon to be shown at Left-upper corner on each channel screen at Left-bottom corner on full screen.
- Page 19 19 | Full HD Digital Video Recorder 3.2.4 Pop-up Menu User can click the right button of the mouse to pop up sub-menu as shown below. DISPLAY- Select the display split from the available options: - 1 Screen- Single channel. Automatically displays CH1. If 1 Screen is selected again, next chronological channel will be displayed.
- Page 20 User’s Manual | 20 As the Admin user, you can seup up multiple users with different levels of authorization. If a certain user is not allowed to view a certain camera in live or playback, then no image will appear on the display screen. To create, delete, or modify users, go to the main menu and select system settings.
-
Page 21: Ptz Operation
21 | Full HD Digital Video Recorder 3.3 PTZ Operation Before starting PTZ control, please make sure the camera you wish to control is a supported PTZ camera and is installed and configured properly. See section 4.2.6 PTZ for setup information. To enter PTZ mode, follow one of the options below: Right-click on the screen and select PTZ Control. -
Page 22: Playback Of Recorded Video
User’s Manual | 22 User can automatically switch PTZ camera positions according to defined presets by using the GUARD TOUR function. The connected PTZ camera must support touring functions. “GUARD TOUR” on the pop-up menu can be enabled only in full screen mode. -
Page 23: Button Function
23 | Full HD Digital Video Recorder The picture below shows the system playing back a video. In playback screen, user can make various playback modes, make an instant manual backup (archive), go to calendar search mode, change channel, and change screen modes. By clicking the left mouse button in the colored-time bar, the user can jump to a different time in the recording. -
Page 24: Search Recording Image
User’s Manual | 24 3.5 Search Recording Image 3.5.1 Date/Time Search To search your recorded data by date/ time, follow one of the options below: Click the quick Menu button at the left side of the menu bar, select Search Date/ Time Right-click anywhere on the screen, select Search ... -
Page 25: Event Log
25 | Full HD Digital Video Recorder the network. If “SENSOR” is disabled in the “DEVICE” menu, and recording mdoe is set to “CONT + SENS”, the system will record with continuous recording even when a sensor is triggered. To view video from the selected time, follow one of the options below: Use the manual hour option to view specific hours of the day. -
Page 26: System Log
User’s Manual | 26 3.5.3 System Log The system log search allows you to search for any changes made to the system, quickly and easily, displaying the search results in a detailed table format. To open System Log Search, perform one of the following options: Click quick menu button, select Search... -
Page 27: First Data
27 | Full HD Digital Video Recorder 9 numbers of log record will be shown on one page of the <System Log> and <Event Log> window. User can click the arrow icon to search the log records on another page. 3.5.4 First Data Go to the first screen of the recorded video. -
Page 28: Dst Setting
User’s Manual | 28 3.6 DST Setting DST starts at 2:00 local time on 2 Sunday of March, and ends at 2:00 DST on 1 Sunday of November. During DST (Daylight Saving Time) period, DVR time clock has to be adjusted according to regional time zone. That is, the DVR time clock will be shifted by one hour after the DST settings start, and the DVR will restore the time clock back to normal after DST finishes. -
Page 29: Screen Saver
29 | Full HD Digital Video Recorder When user click on such overlapped period, a message titled “Recorded video Selection” will pop up. The user can then select whether to play DST data or Non-DST data. Click OK to play DST image. Click CANCEL to play Non-DST image. -
Page 30: Setting
User’s Manual | 30 ETTING General setting structure consists of “System”, “Device”, “Record”, “Network”, “Backup,” and ‘Quick Setup” as shown below. <SYSTEM> <DEVICE> <RECORD> <NETWORK> <BACKUP> <Q-SETUP> Main Classification Sub Classification SYSTEM INFO USER SYSTEM EXPORT/IMPORT FACTORY DEFAULT CAMERA AUDIO SENSOR DEVICE MOTION ALARM... -
Page 31: System
31 | Full HD Digital Video Recorder 4.1 System The system menu button is selected by clicking “TOOL” on the menu bar or clicking the right mouse button. Users can move mouse pointer from “System” through “Quick Setup” to instantly look around the sub-menus on the menu screen. - Page 32 User’s Manual | 32 Date/ Time- manually enter the DVR’s date and time, time zone, and enable/ disabled DST. Using the available options, manually adjust the date and time from the calendar, select the display mode for the time, and the date, and select the appropriate time zone.
- Page 33 33 | Full HD Digital Video Recorder Schedule Reboot- Reboot the DVR on a designated date and time. During the long time working, refresh the DVR automatically Click the Schedule Reboot button> Check the 'USE' >Select week>Select day. NTP Setup- Setup the DVR to automatically sync with a Network Time Protocol.
- Page 34 User’s Manual | 34 4.1.2 User Master user of this system is always Admin with factory default of No password. This user cannot be deleted. It is recommended that the Admin change the password for extra security. Admin can designate a new user with different permission levels by: functions, menu access, and live & playback. “Function”...
- Page 35 35 | Full HD Digital Video Recorder 4.1.3 Export/Import Users can copy and paste the system configuration values in this menu. “Export” allows the user to copy the settings for this system to USB memory devices. “Import” allows the user to recall the settings saved from other systems using USB memory devices.
-
Page 36: Factory Default
User’s Manual | 36 4.1.5 Factory Default With an authorized password, users can get the system back to factory default configuration. Upon clicking “Start” button and entering the admin password, all the configuration values made by the user will be deleted. The system setting will be sent to factory defaults. The recorded video data will not be erased. -
Page 37: Device
37 | Full HD Digital Video Recorder 4.2 Device There are sub menus in the Device menu, such as Camera, Audio, Sensor, Motion Alarm, Extra Alarm, and PTZ. Users can easily move to the “Device” menu by selecting the icon on the top right of the menu screen. - Page 38 User’s Manual | 38 4.2.2 Audio Users can select the audio input and output during live display and match the audio input to a designated channel. (Please refer to Section 4.3.1 Camera Record). Adjust the audio volume using the volume control panel, enable or disable audio recording for each channel, and enable or disable audio during live video.
- Page 39 39 | Full HD Digital Video Recorder Preset- User can select the camera to move to a preset position, once the sensor is triggered. (User should setup preset position in PTZ menu 4.2.6 in advance). In addition, users can set multi-preset with a single PTZ camera.
-
Page 40: Motion Alarm
User’s Manual | 40 4.2.4 Motion Alarm Select Motion alarm to record only when motion detection is triggered by DVR S/W upon user’s defined motion area. An alarm signal is sent via the selected sensor-out channel. COPY SETTINGS Upon pressing Copy Settings button, Copy Settings popup will appear. In this popup, choose the camera the user wants to copy from at the “From”... - Page 41 41 | Full HD Digital Video Recorder 4.2.6 PTZ 1) Connect PTZ Full control and setup of supported PTZ cameras is available in this menu. For more information on controlling PTZ cameras in live mode, see section 3.4 PTZ. Use this setup menu to setup a PTZ camera, adjust the camera’s zoom, focus and iris (on supported models), adjust the pan, tilt and zoom control speed, or setup presets pan, tour and guard schedules.
- Page 42 User’s Manual | 42 PTZ Control mode If it checked on the control, it keep move on the way. Control any supported PTZ cameras by moving the mouse pointer. Focus Iris Select the preset number and ‘Set’ button, ‘Move’ button is move to setting area Activate the PTZ menu Enter Zoom In/Out...
-
Page 43: Record
43 | Full HD Digital Video Recorder 4.3 Record Users can configure various record settings such as Continuous, Event, and Panic for each individual camera channel in the Record Setup Menu. Network Stream settings are independently configured from the Record settings in this menu as well. Therefore, the user can optimize the bandwidth used by configuring the resolution, FPS, and image quality separately. - Page 44 User’s Manual | 44 Users also have the option to configure Panic Record settings. The Panic Record setting is intended to be used under emergency situations. You engage Panic recording by pressing the “Instant Record” button on the frontal keypad, or clicking the icon from the control panel in live mode.
- Page 45 45 | Full HD Digital Video Recorder 4.3.2 Schedule You can set up the record schedule by applying a various record modes to each date and time. Simply select a record mode by mouse and drag it to the desired date and time. 4.3.3 Holiday Users can setup a specific day of a month or day of week as a holiday as shown below.
-
Page 46: Network
User’s Manual | 46 4.4 Network 4.4.1 Network The system has built-in web server. ETHERNET - DVR network system - ETHERNET LAN port Network Type Select network connect type. Select either LAN for fixed (Static) IP or DHCP for dynamic IP. If DHCP is selected, click ‘IP DETECT’... - Page 47 47 | Full HD Digital Video Recorder DVR-04 DVR-05 DVR -06 Simply double click on the desired icon. Then, it will open an internet browser that connects to the DVR via the remote control software as shown below. Please type in your User ID and Password to login and click ‘Connect’ button to connect. ...
- Page 48 User’s Manual | 48 4.4.2 DDNS The User has to mark the “Use DDNS” check box to use it. DDNS Server Joinip.net or joinip2.net is the fixed domain name of DDNS server User cannot change the DDNS name. The standard DDNS domain name is joinip.net, and users can use joinip2.net or dyndns.com by drop-down list.
- Page 49 49 | Full HD Digital Video Recorder 4.4.3 Notification Remote Notify The system can notify an alarm message to the IP address of CenPro Software over the network. User can choose from a selection of different kinds of alarms by pressing “ADD.” Alarms can be generated by Sensor, Motion Detection, Disk Full, Admin PW Changed, Video Loss, and System Start.
-
Page 50: Health Check
User’s Manual | 50 4.4.4 Health Check The DVR offers a uniquely true DVR health monitoring, with pop-up messages and e-mail notification on video loss, recording failure, and HDD failure. To setup: 1. Check the box next to "Enable Health Check" 2. -
Page 51: Backup
51 | Full HD Digital Video Recorder 4.5 Backup 4.5.1 Backup Users can archive a video clip recorded for a certain period on a selected channel or channels as shown below. Connect an appropriate USB memory device, like USB thumb drive, USB HDD, or a built-in CD or DVD burner and press “SCAN”... - Page 52 User’s Manual | 52 4.5.1 Backup Video Retrieve There will be a single file after archiving, if “Auto Player” was selected. User can double click “Player.exe” file to open the video data file (PSF format) in the folder. User can print out, capture a still image, zoom out, or make an ASF file format, by using the icons located on top of the player window.
-
Page 53: Quick Setup
53 | Full HD Digital Video Recorder 4.6 Quick Setup Quick Setup helps user make simple configuration for recording resolution, entire recording speed by frame, recording mode, and recording periods. The system will put the first priority for configuration on this quick setup and will follow this rule regardless of configurations set in other menus. -
Page 54: Web Surveillance
User’s Manual | 54 URVEILLANCE The DVR has a built-in web server. Using an ordinary web-browser over a network, users can always stay connected to the system for live monitoring, playback, or remote configuration without installing any remote client software. 5.1 Web Login The user is required to input the correct IP address in the web browser after making the web port available in the router. -
Page 55: Web Configuration
55 | Full HD Digital Video Recorder 5.2 Web Configuration Menu of Web Configuration Main Classification Sub Classification SYSTEM INFO USER SYSTEM DEFAULT CAMERA AUDIO DEVICE SENSOR MOTION ALARM EXTRA ALARM RECORD SETUP RECORD PANIC RECORD SCHEDULE NETWORK DDNS NETWORK NOTIFICATION HEALTH CHECK QUICK SETUP... - Page 56 User’s Manual | 56 [Record] [Network] [Quick Setup] This web CGI screen is directly supported from the built-in web server in the DVR, regardless of Internet connection. <System Reboot> enables user to reboot the system without any changes to the setup. When the network is disconnected due to abnormal operation of the system, user can use this function and try to reconnect.
-
Page 57: Web Monitoring
57 | Full HD Digital Video Recorder 5.3 Web monitoring The first time you access your DVR via the Web viewer, you will be asked to install Active-X file before monitoring live video. Please follow the installation process to complete the Active-X installation. Without it, you will not be able to view video from any of the DVR’s channels. - Page 58 User’s Manual | 58 ⑭ ⑬ ① ② ③ ④ ⑫ ⑪ ⑩ ⑤ ⑥ ⑦ ⑨ ⑧ Title Function Connection Mode Select to view the DVR in Live or Playback Mode. Connection Option Select to Connect or Disconnect from the DVR. PTZ control options, including: virtual direction arrows, zoom and focus, and preset.
- Page 59 59 | Full HD Digital Video Recorder User can monitor live video in 1, 4, 9 or 16 screen modes. If user wants to see single channel in full screen, user can double-click on the left mouse button when the cursor is positioned on the live video screen. User can change to single mode by clicking the mode icon located at the bottom left.
-
Page 60: Web Playback
User’s Manual | 60 5.4 Web Playback Users can remotely playback the DVR images by clicking “SEARCH” button in the middle of bottom window. In order to connect to DVR, the user has to click “ Connect ” button which is located at the top left corner. ... -
Page 61: Appendix : Network Setup For External Usage
61 | Full HD Digital Video Recorder PPENDIX ETWORK ETUP FOR XTERNAL SAGE Please note: The following information are general guidelines. These may vary by networkand router specifications. Contact your installer or ISP for additional information. If you are not connecting to your DVR from within the same network, you will have to perform port forwarding on your router to be able to access the DVR externally, via the internet. -
Page 62: Ppendix Pecification
User’s Manual | 62 PPENDIX PECIFICATION Model TER-12N040200A Front Image Compression H.264 HDD Interface 1 x SATA Operation System Embedded Linux Input 4BNC Video Output 1 x HD Output (1080p Live Display) Video Mode NTSC/PAL Display Speed 120fps@1080P Screen Split... - Page 63 63 | Full HD Digital Video Recorder Model TER-12N040200A Central Management System Remote Web(IE) Live monitoring, Playback & System Configuration Management Internal Backup Device Local backup by USB memory stick (2ea) , External Network backup by CenPro support Multi-Language, System Upgrade by USB & Network,...
- Page 64 User’s Manual | 64 Model TER-22N080300A TER-22N160300A Front Image Compression H.264 HDD Interface 2 x SATA Operation System Embedded Linux Input 8BNC 16BNC Video Output 1 x HD Output (1080p Live Display), 1 x VGA Output Video Mode NTSC/PAL Display Speed 240fps@1080P 480fps@1080P Screen Split...
- Page 65 65 | Full HD Digital Video Recorder Model TER-22N080300A TER-22N160300A CenPro Software Remote Web(IE) Live monitoring, Playback & System Configuration Management Internal Backup Device Local backup by USB memory stick (2ea) , External Network backup by CenPro support Multi-Language, System Upgrade by USB & Network, Help menu on Major Function Advanced Function Import &...
- Page 66 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Fax +49 (0) 6074 / 888-100 Technical changes reserved www.videor.com...
