2. Details of Menu Items in Adjustment
Settings for Skilled Operators

Menu Items and Functions

[Machine: Image Position]
For details about the following items, see page 23 "[Machine: Image Position]".
No.
0101 [Adjust Image Position With
Feed Direction]
0102 [Adjust Image Position
Across Feed Direction]
0107 [Adjust Erase Margin With
Feed Direction]
[Machine: Image Quality]
For details about the following items, see page 28 "[Machine: Image Quality]".
No.
0201 [Adjust Image Density/
DEMS]
0202 [Image Density Adjustment
Execute Interval]
0203 [Adjust Maximum Image
Density]
0204 [Adjust Line Width]
0205 [Adjust Density Difference
Across Feed Direction]
Item
Adjust the horizontal position of the print image.
Adjust the vertical position of the print image.
Adjust the mask width at the leading edge, trailing edge,
left edge, or right edge of the image.
Item
Execute image density control manually.
DEMS can reduce the variations in thickness that occur in
the intervals between the photoconductor and
development sleeve operations.
Specify the number of sheets the machine prints in full
color before it automatically adjusts image density.
Specify the adhesion of toner to the drum surface and
intermediate transfer belt when image density adjustment
is executed.
Adjust the intensity of the laser for transferring image
data to the drum.
Adjust the image density difference between the top and
bottom of the image.
Description
Description
17
