(4) Scan type selection (scan-type only)
This item selects one of the following scan functions.
Channel scan and channel resume scan search 5
channels around a user selected channel or search
all ITU channels in the band when an ITU channel is
selected.
Programmed scan (optional) searches signals within
the frequency range and activates slowly while
squelch is open and fast while squelch is closed.
(5) Scan speed (scan type only)
Selects scan speed as follows:
(unit: msec./ch)
Selection 1 2 3 4 5 6 7 8 9
Channel scan
130
260 520 1040 2080 4160 8320 16460 33280
Channel resume
scan (sec./ch)
1 2 3 4 5 6 7 8 9
Programmed scan
(squelch open*)
10 20 40 60 90 140 210 320 480
*squelch closed: 10 ms/ch -Fast speed Slow speed-
(6) Channel name and frequency
The lower half of the display can be set to display a
programmable channel name or a receive frequency
according to an operator's needs.
(7) CW/FSK narrow filter
This item selects the passband width for A1A (CW),
FSK or J2B mode.
~
NOTE: When "on" is selected without optional
~
filter installation, the Marine and General versions
~
do not function on these modes. The GMDSS
~
versions can use "on" as standard.
(8) FSK shift frequency
Several shift frequencies (the difference between the
mark and space frequency) are used for FSK opera-
tion. This item allows you to select a shift frequency
for almost any FSK system.
