4 AT Commands, S-Registers, and Result Codes
+MS=? Reports supported options in the format: +MS: (list of sup-
ported <mod> values), (list of supported <automode>
values),(list of supported <min_rate> values),(list of supported
<max_rate> values), (list of supported <x_law> values), (list of
supported <rb_signaling> values)
Example: +MS: (0,1,2,3,9,10,11,56, 64,69),(0,1),(300-33600),(300-
56000),(0,1),(0,1)
Subparameters
<mod> A decimal number that specifies the preferred modu-
lation (automode enabled) or the modulation to use in origi-
nating or answering a connection (automode disabled). See
the following table:
<mod> Modulation
0 V.21
1 V.22
2 V.22bis
3 V.23
9 V.32
10 V.32bis
11 V.34
2
12 V.90
3
56 K56flex
64 Bell 103
69 Bell212
Notes:
1. See optional <automode>, <min_rate>, and <max_rate> subparameters.
2. Selects V.90 modulation as first priority. If a V.90 connection cannot be established,
the modem attempts K56flex, V.34, V.32bis, etc.
3. Selects K56flex modulation as first priority. If a K56flex connection cannot be
established, the modem attempts V.90, V.34, V.32bis, etc. (Default.)
<automode> An optional numeric value that enables or dis-
ables automatic modulation negotiation using V.8 bis/V.8 or
V.32 bis Annex A. The options are:
0 = Disable automode
1 = Enable automode (default)
<min_rate> An optional number that specifies the lowest rate
at which the modem may establish a connection. The value is
decimal coded in units of bps, e.g., 2400 specifies the lowest
rate to be 2400 bps. See "Possible rates" in the <mod> table.
The default is 300 for 300 bps.
<max_rate> An optional number that specifies the highest
rate at which the modem may establish a connection. The
value is decimal coded, in units of bps, e.g., 14400 specifies the
1
Possible rates (bps)
300
1200
2400 or 1200
1200
9600 or 4800
14400, 12000, 9600, or 7200
33600, 31200, 28800, 26400, 24000, 19200, 16800, 14400,
12000, 9600, 7200, 4800, or 2400
56000, 54667, 53333, 52000, 50667, 49333, 48000, 46667,
45333, 44000, 42667, 41333. 40000, 38667, 37333, 36000,
34667, 33333, 32000, 30667, 29333, or 28000
56000, 54000, 52000, 50000, 48000, 46000, 44000, 42000,
40000, 38000, 36000, 34000, or 32000
300
1200
